Quick Details
-
Properties::
-
Rehabilitation Therapy Supplies
-
Place of Origin::
-
Shanghai, China
-
Model Number::
-
ZGZ-W04
-
motor::
-
Motor from Taiwan DC 24V 320W
-
Power Supply::
-
Power
-
controller::
-
PG VR2
-
Functional purposes:
-
Walk Standing + Folding + Outdoor
-
Specialty1::
-
power standing up
-
Specialty2::
-
power lifting seat
-
Specialty3::
-
PG lights system with all LED lights
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ZGZ
-
Model Number:
-
ZGZ-W04
-
Properties::
-
Rehabilitation Therapy Supplies
-
Place of Origin::
-
Shanghai, China
-
Model Number::
-
ZGZ-W04
-
motor::
-
Motor from Taiwan DC 24V 320W
-
Power Supply::
-
Power
-
controller::
-
PG VR2
-
Functional purposes:
-
Walk Standing + Folding + Outdoor
-
Specialty1::
-
power standing up
-
Specialty2::
-
power lifting seat
-
Specialty3::
-
PG lights system with all LED lights
It can power recline, power lay back, power lay down,power stand up. power sit down.
Electric wheelchair
Lifting wheelchair
Standing up wheelchair
Reclining wheelchair
Recline wheelchair
Electric handicapped wheelchair
Electric invalid wheelchair
Power wheelchair
Electric wheelchair
Lifting wheelchair
Standing up wheelchair
Reclining wheelchair
Recline wheelchair
Electric handicapped wheelchair
Electric invalid wheelchair
Power wheelchair
Product Description
|
Overall dimension
|
110*75*102cm(not include headrest height)
|
|
Total height when standing
|
170cm (not include headrest height)
|
|
Seat width-depth-height
|
49cm-45cm-52cm
|
|
Front tire/Rear tire
|
9" air tire/14" air tire
|
|
Weight capacity
|
120kg
|
|
Controller
|
PG(Imported from UK)
|
|
Motor
|
24V/320W*2(imported from Taiwan)
|
|
Battery
|
12V/70AH*2
|
|
Battery weight
|
9kg*6
|
|
Battery dimension(l*w*h)
|
15*10*10cm*6
|
|
Charger
|
24V/5A
|
|
Recharge time
|
8-10hrs
|
|
Gross weight
|
82kg
|
|
Net weight(with batteries)
|
60kg
|
|
Package
|
1pkg
|
|
Package size
|
|
|
Range
|
up to 45km per battery charge
|
|
Incline capability
|
12 degrees
|
|
Max.forward speed
|
9.5km/h
|
|
Qty of 20”FCL
|
30pcs
|
Production Process
After Sale Service
ONE-YEARS LIMITED WARRANTY
One years on all structural frame components
ONE-YEAR LIMITED WARRANTY
For one (1) year from the date of purchase, ZGZ will repair or replace at our option to tile original purchaser, free of
charge, any part or electronic component found upon examination by an authorized representative of ZGZ to be defective in
material and/or workmanship,
The battery is warranted by the battery manufacturer, The battery is not warranted by ZGZ, Warranty service can be performed
by ZGZ or by an authorized ZGZ Provider, Do not return faulty parts to ZGZ without prior consent, All transportation
costs and shipping damage incurred while submitting parts for repair or replacement are the responsibility of the original
purchaser.
ONE-YEAR WARRANTY EXCEPTIONS
TRANSAXLE: In cases where there is an increase in the operational noise level, the warranty does not apply,(The increase in
operational noise level usually occurs due to abusive and excessive strain on the scooter,)
MOTOR BRAKE: one-year warranty for the electrical function of the motor brake, Brake pads are a wearitem and are not warranted,
WARRANTY EXCLUSIONS
ABS plastic shrouds and footrest covers (wear items and not warranted)
Batteries (the battery manufacturer provides a limited warranty)
Tires and tire tubes (wear items and not warranted)
Upholstery and seating (wear items and not warranted)
Repairs and/or modifications made to any part of the scooter without specific and prior consent from ZGZ
Circumstances beyond the control of ZGZ
Damage caused by: battery fluid spillage or leakage, abuse, misuse, accident, or negligence, improper
operation, maintenance, or storage, commercial use or use other than normal
Labor, service calls, shipping, and other charges incurred for repair of the product
THERE IS NO OTHER EXPRESS WARRANTY
Implied warranties, including those of merchantability and fitness for a particular purpose, are limited to one (1) year from the
date of original purchase and to the extent permitted by law. Any and all implied warranties are excluded, This is the exclusive
remedy, Liabilities for consequential damages under any and all warranties are excluded,
Some states do not allow limitations on how long an implied warranty lasts or do not allow the exclusion of limitation of
incidental or consequential damages, So, the above limitation or exclusion may not apply to you.
Service Network
In this market the disabled and the elderly in the domestic, the quality of ZGZ's products has the higher reputation and good
customer service. We export our products all over the world, and every year, export around 10,000 pcs mobility scooters and power
wheelchairs. We are also capable of providing OEM and ODM high quality products with the most competitive prices.
ONE-YEARS LIMITED WARRANTY
One years on all structural frame components
ONE-YEAR LIMITED WARRANTY
For one (1) year from the date of purchase, ZGZ will repair or replace at our option to tile original purchaser, free of
charge, any part or electronic component found upon examination by an authorized representative of ZGZ to be defective in
material and/or workmanship,
The battery is warranted by the battery manufacturer, The battery is not warranted by ZGZ, Warranty service can be performed
by ZGZ or by an authorized ZGZ Provider, Do not return faulty parts to ZGZ without prior consent, All transportation
costs and shipping damage incurred while submitting parts for repair or replacement are the responsibility of the original
purchaser.
ONE-YEAR WARRANTY EXCEPTIONS
TRANSAXLE: In cases where there is an increase in the operational noise level, the warranty does not apply,(The increase in
operational noise level usually occurs due to abusive and excessive strain on the scooter,)
MOTOR BRAKE: one-year warranty for the electrical function of the motor brake, Brake pads are a wearitem and are not warranted,
WARRANTY EXCLUSIONS
ABS plastic shrouds and footrest covers (wear items and not warranted)
Batteries (the battery manufacturer provides a limited warranty)
Tires and tire tubes (wear items and not warranted)
Upholstery and seating (wear items and not warranted)
Repairs and/or modifications made to any part of the scooter without specific and prior consent from ZGZ
Circumstances beyond the control of ZGZ
Damage caused by: battery fluid spillage or leakage, abuse, misuse, accident, or negligence, improper
operation, maintenance, or storage, commercial use or use other than normal
Labor, service calls, shipping, and other charges incurred for repair of the product
THERE IS NO OTHER EXPRESS WARRANTY
Implied warranties, including those of merchantability and fitness for a particular purpose, are limited to one (1) year from the
date of original purchase and to the extent permitted by law. Any and all implied warranties are excluded, This is the exclusive
remedy, Liabilities for consequential damages under any and all warranties are excluded,
Some states do not allow limitations on how long an implied warranty lasts or do not allow the exclusion of limitation of
incidental or consequential damages, So, the above limitation or exclusion may not apply to you.
Service Network
In this market the disabled and the elderly in the domestic, the quality of ZGZ's products has the higher reputation and good
customer service. We export our products all over the world, and every year, export around 10,000 pcs mobility scooters and power
wheelchairs. We are also capable of providing OEM and ODM high quality products with the most competitive prices.
