Quick Details
-
Model Number:
-
D6G
-
Weight:
-
1.9kg
-
Voice Coil Former:
-
CCAW
-
Power Handling (RMS):
-
60 Watts
-
Power Handling (max):
-
120 Watts
-
Impedance:
-
8 ohms
-
DC Resistance (Re):
-
6.5 ohms
-
Voice Coil Diameter:
-
3"
-
Resonant Frequency (Fs):
-
44 Hz
-
Overall Outside Diameter:
-
6.83"
-
Depth:
-
3.01"
Quick Details
-
Item Type:
-
Speaker Unit
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HiVi/Swans
-
Model Number:
-
D6G
-
Weight:
-
1.9kg
-
Voice Coil Former:
-
CCAW
-
Power Handling (RMS):
-
60 Watts
-
Power Handling (max):
-
120 Watts
-
Impedance:
-
8 ohms
-
DC Resistance (Re):
-
6.5 ohms
-
Voice Coil Diameter:
-
3"
-
Resonant Frequency (Fs):
-
44 Hz
-
Overall Outside Diameter:
-
6.83"
-
Depth:
-
3.01"
Details
| Nominal Impedance | 8Ω |
| Resonant Frequency | 44Hz |
| Nominal Power Handling | 60W |
| Max Power Handling | 120W |
| Sensitivity(2.83V/1M) | 85dB |
| Direct Current Resistance | 6.5Ω |
| Magnet System | Inner-magnet |
| Magnet | NdFeB |
| Gap Height | 6.0mm |
| Force Factor | 9.5N/A |
| Linear Excurion | 4.8mm |
| Suspension Compliance | 580uM/N |
| Mechanical Q | 4.08- |
| Electrical Q | 0.43- |
| Total Q | 0.38- |
| Moving Mass | 21.6g |
| Equivalent Air Volume | 12.1L |
Highlights
- Light and extremely rigid cone made from Kevlar/paper composite
- High loss rubber surround
- Shielded vented Neodymium magnet system
- Long-throw motor structure
- High linear excursion capability
- High-density aluminum die-cast frame
