Quick Details
-
Insulation Material:
-
Silicone rubber cable
-
Place of Origin:
-
Jiangsu, China
-
Rated voltage:
-
600V
-
Product name:
-
16awg twin Silicone rubber cable for RC model
-
Color:
-
Black Red
-
Material:
-
Silicone+Copper
-
MOQ:
-
200 Meters
-
Keyword:
-
Flexible Electrical Cable
-
Temperature range:
-
-60'C~ +200 'C
-
Certification:
-
CE ROHS
-
Feature:
-
High Resistance
-
Advantage:
-
High Conductivity
-
Diameter:
-
3MM*2
Quick Details
-
Application:
-
Lithium battery
-
Conductor Material:
-
Tinned Copper
-
Conductor Type:
-
soft
-
Insulation Material:
-
Silicone rubber cable
-
Place of Origin:
-
Jiangsu, China
-
Rated voltage:
-
600V
-
Product name:
-
16awg twin Silicone rubber cable for RC model
-
Color:
-
Black Red
-
Material:
-
Silicone+Copper
-
MOQ:
-
200 Meters
-
Keyword:
-
Flexible Electrical Cable
-
Temperature range:
-
-60'C~ +200 'C
-
Certification:
-
CE ROHS
-
Feature:
-
High Resistance
-
Advantage:
-
High Conductivity
-
Diameter:
-
3MM*2
Detailed Images
|
"Quality first, customer first" is our development policy, to provide customers with one-stop product supply program, and constantly improve our products and service system is the mission of the company. Specification table:
|
|
|
|
|
|
|
|
|
||||||||
|
Conductor
|
|
|
Iusulator
|
|
Rical Character
|
Sectional area |
Carrying current |
packing
|
||||||||
|
Spe (AWG)
|
Copper wire shares
(compos.NO./mm) |
Diameter (mm)
|
Jacket Thick
(mm) |
Overall diameter
(mm) |
Conductor resistance
(Ohm/km) |
Square millimeter(mm2)
|
(ampere)
|
(M/coils) |
||||||||
|
30AWG
|
11/0.08
|
0.30
|
0.55
|
1.20
|
331.00
|
0.05
|
0.80
|
200.00
|
||||||||
|
28AWG
|
16/0.08
|
0.36
|
0.55
|
1.30
|
227.20
|
0.08
|
1.25
|
200.00
|
||||||||
|
26AWG
|
30/0.08
|
0.46
|
0.55
|
1.50
|
123.00
|
0.14
|
3.50
|
200.00
|
||||||||
|
24AWG
|
40/0.08
|
0.61
|
0.55
|
1.60
|
97.60
|
0.20
|
5.00
|
200.00
|
||||||||
|
22AWG
|
60/0.08
|
0.78
|
0.55
|
1.70
|
88.60
|
0.33
|
8.73
|
200.00
|
||||||||
|
20AWG
|
100/0.08
|
0.92
|
0.55
|
1.80
|
62.50
|
0.50
|
13.87
|
200.00
|
||||||||
|
18AWG
|
150/0.08
|
1.19
|
0.55
|
2.30
|
39.50
|
0.75
|
22.00
|
200.00
|
||||||||
|
17AWG
|
210/0.08
|
1.33
|
0.80
|
2.70
|
21.40
|
1.00
|
31.00
|
200.00
|
||||||||
|
16AWG
|
252/0.08
|
1.53
|
0.80
|
3.00
|
24.40
|
1.27
|
35.00
|
100.00
|
||||||||
|
15AWG
|
336/0.08
|
1.69
|
0.80
|
3.10
|
20.02
|
1.68
|
42.00
|
100.00
|
||||||||
|
14AWG
|
400/0.08
|
1.78
|
0.90
|
3.50
|
15.60
|
2.07
|
55.60
|
100.00
|
||||||||
|
13AWG
|
500/0.08
|
2.06
|
0.95
|
4.00
|
12.50
|
2.50
|
65.00
|
100.00
|
||||||||
|
12AWG
|
680/0.08
|
2.48
|
1.00
|
4.50
|
9.80
|
3.40
|
88.40
|
100.00
|
||||||||
|
11AWG
|
800/0.08
|
2.59
|
1.00
|
4.60
|
7.38
|
3.96
|
100.00
|
100.00
|
||||||||
|
10AWG
|
1050/0.08
|
3.06
|
1.25
|
5.50
|
6.30
|
5.30
|
140.60
|
100.00
|
||||||||
|
8AWG
|
1650/0.08
|
3.75
|
1.50
|
6.80
|
4.20
|
8.29
|
200.00
|
100.00
|
||||||||
|
6AWG
|
3430/0.08
|
5.40
|
1.30
|
8.00
|
1.20
|
17.23
|
320.00
|
50.00
|
||||||||
|
4AWG
|
5000/0.08
|
6.50
|
1.75
|
10.50
|
0.84
|
25.00
|
120.00
|
|
||||||||
|
2AWG
|
7000/0.08
|
8.00
|
2.00
|
12.00
|
0.53
|
35.00
|
175.00
|
|
||||||||
Specification:
¤1) Conductor material : tinned copper
¤2) Insulator material : silicone Rubber
¤3) Rated Temperature : -60°C~+200°C
¤4) Single wire diameter : 0.08mm
¤5) Nominal Voltage : 600 V
¤6) Test Voltage : 2000 V
¤7) Colors : Black ; Red ; White ; Blue ; Yellow; Green;Brown,Green/Yellow
¤8) Our silicone wire are widely used in the consumption electric products like drone,plan model,car model,ship model,battery
adapter,network electrical equipment and all kind of instrument.
¤1) Conductor material : tinned copper
¤2) Insulator material : silicone Rubber
¤3) Rated Temperature : -60°C~+200°C
¤4) Single wire diameter : 0.08mm
¤5) Nominal Voltage : 600 V
¤6) Test Voltage : 2000 V
¤7) Colors : Black ; Red ; White ; Blue ; Yellow; Green;Brown,Green/Yellow
¤8) Our silicone wire are widely used in the consumption electric products like drone,plan model,car model,ship model,battery
adapter,network electrical equipment and all kind of instrument.
Our Company
• Changzhou Onlyoa Electronic Co., Ltd is a professional manufacturer of electronic connectors with and has more than 10 years of history.
• Our products are widely used in remote control models, toys, lithium battery system,audio,video equipment and so on.Customized service is our strength. DJI,YUNNER, INTER , Castle and WEG MOTOR are our regular clients.
• Our company has more than 40 employees and our professional trade team.
• we are all sincerely looking forward to establishing cooperative on the basis of equally,mutual benefit and exchange of needed goods.
Quality Assurance
• Most material suppliers own ROHS certification.
•Our management system is established based on the ISO9001 standard and passed ISO9001: 2008 certification.
•Experienced skilled workers, advanced production equipment.
•Professional quality testing department and 100% check before package.
Packing & Delivery
• Inner packing by PE bag.
• Outer packing by carton and protective film.
• Shipping: By Express,By Air,By Sea,By Railway.
• The best and cheapest way for you.
Our service
• Payment Method:L/C,T/T,D/A,D/P,Paypal
• Sample Order:Welcome
• OEM/ODM:Accepted
• 100% quality test to ensure higher quality.
• Reasonable prices for partners to create more profit margins.
• Personalized service to meet requirements of different partners.
• After-sales Service:Please check the amount and quality within 15 days after you receive all products,let us know as soon as possible if there is any problem.
