Quick Details
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
3.0KW/ 4.5KW/ 5.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LINTCNC
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3100*1850*1600mm
-
Power (kW):
-
3
-
Weight (KG):
-
1350
-
Warranty of core components:
-
9 months
-
Core Components:
-
Spindle
-
Control system:
-
NcStudio Control System/mach3
-
Spindle:
-
3.0kw water cooling spindle
-
Application:
-
Engraving
-
Name:
-
Woodworking Cnc Router
-
Motor:
-
Stepper Motor 450B
-
Working area:
-
1300x2500mm
-
Spindle power:
-
3.0KW
-
Software:
-
Ucancam / ArtCam/TYPE3
-
Transmission:
-
XY-axis:rack Z-axis:ball screw
Quick Details
-
Working Table Size(mm):
-
1300×2500
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
1 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
3.0KW/ 4.5KW/ 5.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LINTCNC
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3100*1850*1600mm
-
Power (kW):
-
3
-
Weight (KG):
-
1350
-
Warranty of core components:
-
9 months
-
Core Components:
-
Spindle
-
Control system:
-
NcStudio Control System/mach3
-
Spindle:
-
3.0kw water cooling spindle
-
Application:
-
Engraving
-
Name:
-
Woodworking Cnc Router
-
Motor:
-
Stepper Motor 450B
-
Working area:
-
1300x2500mm
-
Spindle power:
-
3.0KW
-
Software:
-
Ucancam / ArtCam/TYPE3
-
Transmission:
-
XY-axis:rack Z-axis:ball screw
Product Description
Machine details
Heavy duty stone CNC Router is at the service of customers who need to do engraving on stone.
overall structure is the most solid for large bearing capacity.
with tool cooling system and water-and -dust proof on three axes,
it is suitable for many kinds of stone carving.
overall structure is the most solid for large bearing capacity.
with tool cooling system and water-and -dust proof on three axes,
it is suitable for many kinds of stone carving.
|
Model
|
LT-1325 wood CNC Router
|
|
Working area
|
1300(X)*2500(Y)*200(Z)
|
|
Machine structure
|
Welded steel tube, cast iron vertical shafts and steel gantry
|
|
Table surface
|
Aluminum T-slot table with PVC
|
|
Spindle
|
3.0KW water cooling spindle
|
|
Spindle rotating speed
|
0-24000 rpm
|
|
Collect size
|
ER20
|
|
Guide rail
|
Taiwan Hiwin linear square guide rail
|
|
Driving method
|
X,Y axis by helical gear rack, Z axis by TBI ball screw
|
|
Motors and drivers
|
Stepper motor 450B and Leadshine drivers MA860H
|
|
Control system
|
NC studio control system
|
|
Inverter
|
Fuling inverter
|
|
Max. idling speed
|
25m/min
|
|
Max. working speed
|
12m/min
|
|
Working accuracy
|
<0.05/300mm
|
|
Instruction formate
|
G code *.u00 *.mmg *.plt
|
|
Working voltage
|
AC220V/AC380V,single phase/3 phase,50-60Hz
|
|
Standard software
|
Artcam2010
|
|
Compatible software
|
Type3/Castmate/Coreldraw/AutoCAD and other CAM/CAD software
|
|
Control cabinet
|
Independent
|
|
Other
|
Tool sensor; Oiling system; Water pump; Tool box,English manuals etc.
|
Feedback and Sample
1. Furniture Industry:
Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2. Advertising Industry: Advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
3. Mold Industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
2. Advertising Industry: Advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
3. Mold Industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
Feedback
Please
click
and view the feedback video from our customers.
Our services
1.Guarantee:
3 years guarantee of the whole machine+1.5 years warranty for motor and spindle
2.Software issue:
Supply technical support for machine lifetime free.
3.Hardware issue:
Main parts(excluding the consumables) shall be replaced/ repaired free of charge if there is any problem during the warranty period.
4.Support online:
our engineer give 1 hours to solve question online.
5.Training in LINTCNC factory:
We are able to train your staff after placed order in our factory for free.
6.Oversea service:
We are able to send technician to your workshop to do the installation and training. You will need bear the
related costs. (flight,visa,hotel,training costs, etc.)
2.Software issue:
Supply technical support for machine lifetime free.
3.Hardware issue:
Main parts(excluding the consumables) shall be replaced/ repaired free of charge if there is any problem during the warranty period.
4.Support online:
our engineer give 1 hours to solve question online.
5.Training in LINTCNC factory:
We are able to train your staff after placed order in our factory for free.
6.Oversea service:
We are able to send technician to your workshop to do the installation and training. You will need bear the
related costs. (flight,visa,hotel,training costs, etc.)
