Quick Details
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
1150*1360*1.8mm
-
Crystalline Silicon:
-
Monocrystalline Silicon
-
Maximum Power:
-
100W/120W/200W/300W
-
Maximum Operating Voltage (Vm):
-
18.0V/21V/42V
-
Open-Circuit Voltage (Voc):
-
21.6V/25.2V/50.4V
-
Maximum System Voltage:
-
600V
-
Operating Temperature Range:
-
-25°C~+60°C
-
Hail Pressure Test:
-
Fall from a height of one meter
-
Fill Factor:
-
75.00%
-
Solar Panel Dimensions(300W):
-
1150*1360*1.8mm
-
Solar Panel Weight:
-
7.19kg
Quick Details
-
Cell size:
-
1150*1360*1.8mm
-
Brand Name:
-
PowMr
-
Model Number:
-
POW-LTW 100W/120W/200W/300W
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
1150*1360*1.8mm
-
Crystalline Silicon:
-
Monocrystalline Silicon
-
Maximum Power:
-
100W/120W/200W/300W
-
Maximum Operating Voltage (Vm):
-
18.0V/21V/42V
-
Open-Circuit Voltage (Voc):
-
21.6V/25.2V/50.4V
-
Maximum System Voltage:
-
600V
-
Operating Temperature Range:
-
-25°C~+60°C
-
Hail Pressure Test:
-
Fall from a height of one meter
-
Fill Factor:
-
75.00%
-
Solar Panel Dimensions(300W):
-
1150*1360*1.8mm
-
Solar Panel Weight:
-
7.19kg
Product Description
INTRODUCTION
1. Internal: Monocrystalline silicon solar cells embedded in PET and EVA sheets.
2. Surface: Utilizes 0.2mm high molecular weight, water-resistant, and corrosion-resistant transparent or frosted PET materials.
3. Backsheet: Employs 0.2mm high molecular weight, water-resistant, and corrosion-resistant white or black PET materials.
4. After-sales Service: Within one year of purchase, in case of insufficient power output or material detachment (non-manual damage), our company provides free repair and replacement services for monocrystalline silicon solar panels.
Specification
|
MODEL
|
POW-LTW 100W
|
POW-LTW 120W
|
POW-LTW 200W
|
POW-LTW 300W
|
|||
|
Crystalline Silicon
|
Monocrystalline Silicon
|
|
|
|
|||
|
Maximum Power (Pm)
|
100Wp
|
120Wp
|
200Wp
|
300Wp
|
|||
|
Maximum Operating Voltage (Vm)
|
18.0V
|
18.0V
|
21V/42V
|
21V/42V
|
|||
|
Maximum Operating Current (Im)
|
5.55A
|
6.66A
|
9.52A/4.76A
|
14.8A/7.4A
|
|||
|
Open-Circuit Voltage (Voc)
|
21.6V
|
21.6V
|
25.2V/50.4V
|
25.2V/50.4V
|
|||
|
Short-Circuit Current (Isc)
|
6.1A
|
7.2A
|
10.28A/5.14A
|
15.98A/7.99A
|
|||
|
Solar Panel Dimensions
|
935*590*1.8mm
|
590*1160*1.8mm
|
780*1340*1.8mm
|
1150*1360*1.8mm
|
|||
|
Solar Panel Weight
|
2.49kg
|
3.08kg
|
4.835kg
|
7.19kg
|
|||
|
Maximum System Voltage
|
600V
|
600V
|
600V
|
600V
|
|||
|
Temperature Coefficient of Short-Circuit Current
|
0.065+/-0.015%/°C
|
0.065+/-0.015%/°C
|
0.065+/-0.015%/°C
|
0.065+/-0.015%/°C
|
|||
|
Temperature Coefficient of Open-Circuit Voltage
|
-(2.23+/-0.1)mv/°C
|
-(2.23+/-0.1)mv/°C
|
-(2.23+/-0.1)mv/°C
|
-(2.23+/-0.1)mv/°C
|
|||
|
Temperature Coefficient of Maximum Power
|
-(0.5+-0.05)/°C
|
-(0.5+-0.05)/°C
|
-(0.5+-0.05)/°C
|
-(0.5+-0.05)/°C
|
|||
|
Temperature Coefficient of Maximum Current
|
+0.1/°C
|
+0.1/°C
|
+0.1/°C
|
+0.1/°C
|
|||
|
Temperature Coefficient of Maximum Voltage
|
-0.38/°C
|
-0.38/°C
|
-0.38/°C
|
-0.38/°C
|
|||
|
Operating Temperature Range
|
-25°C~+60°C
|
-25°C~+60°C
|
-25°C~+60°C
|
-25°C~+60°C
|
|||
|
Power Tolerance
|
+/-5%
|
+/-5%
|
+/-5%
|
+/-5%
|
|||
|
Maximum Pressure the Module Surface Can Withstand
|
3m/s(20kg/sq.m)
|
3m/s(20kg/sq.m)
|
3m/s(20kg/sq.m)
|
3m/s(20kg/sq.m)
|
|||
|
Hail Pressure Test
|
Fall from a height of one meter
|
Fall from a height of one meter
|
Fall from a height of one meter
|
Fall from a height of one meter
|
|||
|
Junction Box Type
|
ABS
|
ABS
|
ABS
|
ABS
|
|||
|
Output Power Tolerance
|
+/-5%
|
+/-5%
|
+/-5%
|
+/-5%
|
|||
|
Standard Test Conditions
|
AM1.5 100mW/C㎡25’C
|
AM1.5 100mW/C㎡25’C
|
AM1.5 100mW/C㎡25’C
|
AM1.5 100mW/C㎡25’C
|
|||
|
Warranty
|
1-year
|
1-year
|
1-year
|
1-year
|
|||
|
Fill Factor
|
75.00%
|
75.00%
|
75.00%
|
75.00%
|
|||
|
Packaging
|
Carton
|
Carton
|
Carton
|
Carton
|
|||
