Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HUNGSO
-
Model Number:
-
NA12B-10NG
-
Contact material:
-
Silver
-
Operation type:
-
momentary
-
Certificate:
-
CQC,CCC
-
Function:
-
Push On
-
application:
-
door bell doorbell
-
connection:
-
solder pin
-
button color:
-
black (other color available)
-
Certification:
-
CCC
Quick Details
-
Protection Level:
-
IP65/IP67/IP68
-
Max. Current:
-
2A
-
Max. Voltage:
-
220V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HUNGSO
-
Model Number:
-
NA12B-10NG
-
Contact material:
-
Silver
-
Operation type:
-
momentary
-
Certificate:
-
CQC,CCC
-
Function:
-
Push On
-
application:
-
door bell doorbell
-
connection:
-
solder pin
-
button color:
-
black (other color available)
-
Certification:
-
CCC
Product Description
Specification
|
Model
|
|
NA12B-10N/G
|
|
|
Terminal type
|
|
Screw terminal
|
|
|
Switch type
|
|
X(two terminal breakpoints slow moving contact)
|
|
|
Switch specification
|
|
36vdc/2A
|
|
|
Contact resistance
|
|
Less than 50m ohm
|
|
|
Insulation resistance
|
|
More than 1000M ohm
|
|
|
Dielectric strength
|
|
2000V AC
|
|
|
Operating temperature
|
|
-20 ~ +55 degree
|
|
|
Mechanical life
|
|
More than 1000000 times
|
|
|
Electrical life
|
|
More than 200000 times
|
|
|
Panel thickness
|
|
1~5mm
|
|
|
Torque
|
|
5~14Nm
|
|
|
Operating pressure
|
|
About 5N
|
|
|
Protection degree
|
|
IP65, IK08
|
|
|
Material
|
contact
|
Silver alloy
|
|
|
|
button
|
PBT
|
|
|
|
Button color
|
Red
|
|
|
|
Other available button color
|
green, blue, yellow, white, black.
|
|
|
|
(if need, please tell)
|
|
|
|
|
case
|
Zn-AL alloy
|
|
|
|
base
|
PBT
|
|
UNIT:MM
