Quick Details
-
Throat Depth (mm):
-
320 mm
-
Width of Working Table (mm):
-
180 mm
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Bamboo
-
Weight (KG):
-
6500
-
Motor Power (kw):
-
7.5 kw
-
Capacity:
-
100Ton
-
Controller:
-
Estun From China
-
Hydraulic System:
-
B osch Rexroth Germany
-
Main motor:
-
Siemens from Germany
-
Electrics:
-
Schneider from France
-
Tube:
-
EMB From Germany
-
Foot Switch:
-
Karcon from South Korea
-
Ball Screw:
-
Hiwn From Taiwan
-
Voltage:
-
220V/380V/400V
-
Nominal Pressure (kN):
-
1000
Quick Details
-
Machine Type:
-
Torsion Bar
-
Length of Working Table (mm):
-
4000
-
Slider Stroke (mm):
-
140 mm
-
Throat Depth (mm):
-
320 mm
-
Width of Working Table (mm):
-
180 mm
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Bamboo
-
Weight (KG):
-
6500
-
Motor Power (kw):
-
7.5 kw
-
Capacity:
-
100Ton
-
Controller:
-
Estun From China
-
Hydraulic System:
-
B osch Rexroth Germany
-
Main motor:
-
Siemens from Germany
-
Electrics:
-
Schneider from France
-
Tube:
-
EMB From Germany
-
Foot Switch:
-
Karcon from South Korea
-
Ball Screw:
-
Hiwn From Taiwan
-
Voltage:
-
220V/380V/400V
-
Nominal Pressure (kN):
-
1000
|
Model
|
WC67K-80Tx4000mm
|
|
Nominal Pressure
|
800KN
|
|
Length of Worktable
|
4000MM
|
|
Capacity
|
6mm*2500mm Steel Plate
|
|
Accuracy
|
0.5mm
|
|
Size(L*W*H)
|
2960mm*1600mm*2180mm
|
Main Features
●Totally EU streamlined design, Monoblock by welding robots & apparatus and stress relief process by Annealing treatment.
●Adopt integrated hydraulic system, more reliable and easy for maintenance. and the hydraulic system from Bosch-Rexroth, Germany
●Mechanical synchronous mechanism and the complex compensation are designed so as to raise the workpieces precision.
●The stroke and distance of the backgauge is adjusted by the motor and is well adjusted by hand, the adjustment is displayed by E21.
●Inch, single mode being designed for the machine and reversing and maintain time can be controlled by PLC.
●Safe fence and the electric interlocker have been designed for the machine to ensure the operation safety.
Safety Standards
EN 12622:2009 +A1:2013
EN ISO 12100:2010
EN 60204-1:2006+A1:2009
Front finger Protection(Safety light curtain)
South Korea Kacon Foot Switch(Level 4 of safety)
Back metal safe fence with CE standards
Safety relay with Monitor the pedal switch and safety protection
