I. ASME Code
|
|
|
|
|
|
|
||||||
|
Capacity
|
38.3m³
|
46m³
(with pump)
**
|
47.5m³
|
55m³
|
58m³
|
60m³
(with pump)
**
|
||||||
|
*Max. Payload
|
18000kg
(19.15 t)
|
21300kg
(23 t)
|
23000kg
(23.75 t)
|
25710kg
(27.5 t)
|
26130kg
(29 t)
|
25500kg
(30 t)
|
||||||
|
Kerb Weight
|
11900kg
|
16900kg
|
14000kg
|
16790kg
|
17300kg
|
22150kg
|
||||||
|
Gross Vehicle Weight
|
29900kg
|
38200kg
|
37000kg
|
42500kg
|
43430kg
|
47650kg
|
||||||
|
Outline Dimension
|
L:10470mm
W:2550mm
H:3920mm
|
L:13152mm
W:2500mm H:3850mm |
L:13137mm
W:2500mm
H:3850mm
|
L:14297mm
W:2500mm H:4000mm |
L:13238mm
W:2640mm
H:4050mm
|
L:13052mm
W:2550mm H:4000mm |
||||||
|
Design Pressure
|
1.724 MPa
|
2.26 MPa
|
1.724MPa
|
1.724MPa
|
1.724MPa
|
2.5MPa
|
||||||
|
MAWP
|
1.724 MPa
at 51.7℃
|
2.26 MPa at 70℃
|
1.724MPa
|
-
|
1.724MPa
|
2.5MPa
|
||||||
|
Design Temperature
|
51.7℃
|
70℃
|
-23.3/51.7℃
|
50℃
|
-23.3/51.7℃
|
-40/+70℃
|
||||||
|
Corrosion Allowance
|
0mm
|
2mm
|
0mm
|
0mm
|
0mm
|
1mm
|
||||||
|
Material of Shell
|
SA-612M(N)
|
SA-537M
|
SA-612M(N)
|
SA-612M(N)
|
SA-612M(N)
|
SA-612
|
||||||
|
Material of Head
|
SA-612M(N)
|
SA-537M
|
SA-612M(N)
|
SA-612M(N)
|
SA-612M(N)
|
SA-612
|
||||||
|
Thickness of Shell
|
12.5mm
|
15mm
|
12mm
|
12.5mm
|
14mm
|
16mm
|
||||||
|
Thickness of Head
|
8mm
|
10mm
|
8mm
|
8mm
|
8mm
|
16mm
|
||||||
|
Test Pressure
(Hydraulic Horizontal)
|
2.25MPa
|
3.4MPa
|
2.24MPa
|
2.25MPa
|
2.25MPa
|
3.58MPa
|
||||||
|
Air Test Pressure
|
1.724MPa
|
2.26MPa
|
1.724MPa
|
1.724MPa
|
1.724MPa
|
-
|
||||||
|
*Please note that different medium component will cause different density and different payload.
** CIMC Hongtu is able to supply you LPG trailer with pump, the reference photos can be viewed hereinafter.
***Please contact for more different kinds of capacity and standard tanks.
|
|
|
|
|
|
|
||||||
|
II. China GB Standard
|
|
|
|
|
|
|||||
|
Volume
|
36m³
|
46m³
|
52m³
|
58.1m³
|
61.9m³
|
|||||
|
*Max. Payload
|
15120kg
(18 t)
|
19320kg
(23 t)
|
25506kg
(26 t)
|
26915kg
(29.05 t)
|
26000kg
(30.05 t)
|
|||||
|
Kerb Weight
|
11880kg
|
14680kg
|
13374kg
|
15000kg
|
14000kg
|
|||||
|
Gross Vehicle Weight
|
27000kg
|
34000kg
|
38800kg
|
41915kg
|
40000kg
|
|||||
|
Outline Dimension
|
L:9400mm
W:2500mm
H:3900mm
|
L:10360mm
W:2500mm
H:3990mm
|
L:12000mm
W:2500mm
H:3990mm
|
L:13150mm
W:2500mm
H:4100mm
|
L:13590mm
W:2550mm
H:4000mm
|
|||||
|
Design Pressure
|
1.61MPa
|
1.61MPa
|
1.77MPa
|
1.72/-0.1MPa
|
1.61/-0.04MPa
|
|||||
|
Design Temperature
|
-20/50℃
|
-20/50℃
|
-20/50℃
|
-20/50℃
|
-40/50℃
|
|||||
|
Corrosion Allowance
|
1mm
|
1mm
|
1mm
|
1mm
|
1mm
|
|||||
|
Material of Shell
|
Q370R(N)
|
Q370R(N)
|
Q420R
(WH590D)
|
Q370R(N)
|
WH590E(N)
|
|||||
|
Material of Head
|
Q370R(N)
|
Q370R(N)
|
Q420R
(WH590D)
|
Q370R(N)
|
16MnDR(N)
|
|||||
|
Thickness of Shell
|
12mm
|
13mm
|
11mm
|
12mm
|
10mm
|
|||||
|
Thickness of Head
|
11mm
|
12mm
|
10mm
|
8mm
|
8mm
|
|||||
|
Test Pressure
(Hydraulic Horizontal)
|
2.1MPa
|
2.1MPa
|
2.7MPa
|
2.24MPa
|
2.1MPa
|
|||||
|
Air Test Pressure
|
1.61MPa
|
1.61MPa
|
1.77MPa
|
1.72MPa
|
1.61MPa
|
|||||
|
*Please note that different medium component will cause different density and different payload.
** CIMC Hongtu is able to supply you LPG trailer with pump, the reference photos can be viewed hereinafter.
***Please contact for more different kinds of capacity and standard tanks. |
|
|
|
|
|
|||||
|
III. European Standard ADR
|
|
|
|
Design Code
|
EN12493:2013+A1:2014
|
|
|
Volume
|
60m³
|
|
|
Max. Payload
|
25200kg
|
|
|
Kerb Weight
|
14800kg
|
|
|
Gross Vehicle Weight
|
40000kg
|
|
|
Outline Dimension
LengthxWidthxHeight
|
13115x2550x4000 mm
|
|
|
Wheel Base
|
7900+1320+1320
|
|
|
Design Pressure
|
2.1/-0.04 MPa
|
|
|
Maxiumum Working Pressure
|
1.62 MPa
|
|
|
Design Temperature
|
-20/+50℃
|
|
|
Material of Shell
|
P460NL1
|
|
|
Nominal Thickness
|
10(Shell)/13(End) mm
|
|
|
Hydrostatic Pressure Test
|
2.10 MPa
|
|
