Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hua Ming Yuan
-
Surface treatment:
-
Hot dip Galvanizing antirust.
-
Thickness of Galvanizing:
-
80-100 microns in average according to ASTM A123
-
Painting color:
-
(RAL)Color card according to client's requirements.
-
Pole's Shape:
-
Round, Polygonal, Octagonal
-
Arm type:
-
Single arm, Double arm, Tri-arm, Four-arm
-
Welding:
-
Advanced submerge-arc welding technology according to AWS D 1.1
-
wall Thickness:
-
2.5mm-30mm
-
Dimension Tolerance:
-
+- 2%
-
Ground Mounted:
-
Base plate with Anchor bolt in concrete foundation or Direct-embedded.
Quick Details
-
Material:
-
Steel
-
Type:
-
Polygonal
-
Application:
-
Outdoor illumination, Road illumination, Street illumination
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hua Ming Yuan
-
Surface treatment:
-
Hot dip Galvanizing antirust.
-
Thickness of Galvanizing:
-
80-100 microns in average according to ASTM A123
-
Painting color:
-
(RAL)Color card according to client's requirements.
-
Pole's Shape:
-
Round, Polygonal, Octagonal
-
Arm type:
-
Single arm, Double arm, Tri-arm, Four-arm
-
Welding:
-
Advanced submerge-arc welding technology according to AWS D 1.1
-
wall Thickness:
-
2.5mm-30mm
-
Dimension Tolerance:
-
+- 2%
-
Ground Mounted:
-
Base plate with Anchor bolt in concrete foundation or Direct-embedded.
Product Description
|
SPECIFICATION
|
|
|
|
Material
|
Hot rolled steel, Q235,Q345,S235,S355,SS400,Gr 50
|
|
|
Yield Strength Of Material
|
Minimum yield strength>=235n/mm2 for Q235, S235 and SS400
Minimum yield strength>=345n/mm2 for Q345 S355 and Gr 50 |
|
|
Height
|
3m –15m
|
|
|
Length Of One Part
|
Within 16m once forming without slip joint
|
|
|
Wall Thickness
|
2.3mm-30mm
|
|
|
Pole Shape
|
Round, Polygonal, Taper Octagonal, Taper round, Round conical, Taper Square, Square
|
|
|
Arm Type
|
Single arm, Double arm, Tri-arm, Four-arm
|
|
|
Power
|
250W to 400W
|
|
|
Welding
|
Advanced submerge-arc welding and CNC welding equipment;
Welding standard : international welding standard of EN1090 and AWS D 1.1;
|
|
|
Galvanization
|
Hot dip galvanization with thickness of 80-100µm average can meet requirement of EN1090 or Chinese standardGB/T 13912-2002 or American standard ASTM A123, ISO: 2626-1985
|
|
|
Wall Thickness Tolerance
|
±0.1mm from 2.3mm to 4mm
±0.2mm from 5mm to 20mm ±0.5mm from 22mm to 30mm |
|
|
Painting Color
|
RAL Color Chart(customerized)
|
|
|
Surface Treatment-1
|
Black pole, Rough pole
|
|
|
Surface Treatment-2
|
Hot dip Galvanizing antirust
|
|
|
Surface Treatment-3
|
Hot dip galvanizing with powder coating
|
|
|
Temperature Range
|
-35 °C~+45 °C
|
|
|
Wind Speed
|
Aganist wind pressure of 120Km/h to 180Km/h;According to design requirements
|
|
|
Base Plate Mounted
|
Square, octagonal or round in shape with slotted holes for anchor bolt (customized)
|
|
|
Ground Mounted
|
Buried underground length according to customer's requirements.
|
|
