Quick Details
-
Model Number:
-
FP20000Q
-
Certificate:
-
CE ROHS
-
Product Name:
-
FP20000Q amplifier power sound system power amplifier
-
8 Ω stereo power:
-
2200w*4
-
4 Ω stereo power:
-
4000w*4
-
Input connector:
-
female XLR
-
Input impedance:
-
20 k Ω balance
-
Feature:
-
FP CLASS TD
-
Color:
-
BLACK
-
Use:
-
Indoor Ourdoor Activities
Quick Details
-
Warranty:
-
3years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GYIMPEX
-
Model Number:
-
FP20000Q
-
Certificate:
-
CE ROHS
-
Product Name:
-
FP20000Q amplifier power sound system power amplifier
-
8 Ω stereo power:
-
2200w*4
-
4 Ω stereo power:
-
4000w*4
-
Input connector:
-
female XLR
-
Input impedance:
-
20 k Ω balance
-
Feature:
-
FP CLASS TD
-
Color:
-
BLACK
-
Use:
-
Indoor Ourdoor Activities
Specification
|
Setting Information
|
|
|
|
MODEL
|
FP20000Q
|
|
|
rated voltage
|
220V 50HZ/110V 60HZ
|
|
|
channel
|
4
|
|
|
Height
|
2U
|
|
|
8 Ω stereo power
|
2200W
|
|
|
4 Ω stereo power
|
4000w
|
|
|
Class
|
TD
|
|
|
warranty
|
3 years
|
|
Product Description
FP20000Q Power Amplifier
8ΩStereo Power(RMS) 2200WX4
4ΩStereo Power(RMS) 4000WX4
2ΩStereo Power(RMS) 5000WX4
8ΩBridged Power(RMS) 8000WX2
4ΩBridged Monon Power 10000WX2
Output Power 20-20kHz, 1W with 1 khz
Signal Noise Ration(dB) 110dB
FREQUENTY RESPONSE 20Hz-25kHz +-0.5dB
THD+N(Rated power 4Ω/KHz)% <0.1%
Damping coefficient 500
Input gain 23,26,29,32,35,38,41,44dB
Input connectors Combo XLR type,3pin(NEUTRIK)
Link Connectors XLR type,3pin male(NEUTRIK)
Input Impedance 20kΩBalanced /10kΩUnbalanced/10kΩUnbalanced
Output Connectors Speakon Connectors(NEUTRIK)
Minimum power-up voltage 180-260V~50-60Hz
Power Requirement 200-240V~50-60Hz
Protection Short circuit, open circuit, thermal, overload
DC, super audio and other protective devices
Dimension 483x377x88mm
Weight(net) 18Kg
Packing Dimension 575x555x140mm
Gross weight 21.5kg
high power dj audio bass outdoor live power amplifier,audio 4 channel professional audio sanway fp20000q power amplifier best
quality professional,16000W Class D Professional Power Amplifier FP20000Q,FP amplifier series FP14000Q FP20000Q amplifier power
sound system power amplifier,China Made In China High Power Amplifier Fp20000q
8ΩStereo Power(RMS) 2200WX4
4ΩStereo Power(RMS) 4000WX4
2ΩStereo Power(RMS) 5000WX4
8ΩBridged Power(RMS) 8000WX2
4ΩBridged Monon Power 10000WX2
Output Power 20-20kHz, 1W with 1 khz
Signal Noise Ration(dB) 110dB
FREQUENTY RESPONSE 20Hz-25kHz +-0.5dB
THD+N(Rated power 4Ω/KHz)% <0.1%
Damping coefficient 500
Input gain 23,26,29,32,35,38,41,44dB
Input connectors Combo XLR type,3pin(NEUTRIK)
Link Connectors XLR type,3pin male(NEUTRIK)
Input Impedance 20kΩBalanced /10kΩUnbalanced/10kΩUnbalanced
Output Connectors Speakon Connectors(NEUTRIK)
Minimum power-up voltage 180-260V~50-60Hz
Power Requirement 200-240V~50-60Hz
Protection Short circuit, open circuit, thermal, overload
DC, super audio and other protective devices
Dimension 483x377x88mm
Weight(net) 18Kg
Packing Dimension 575x555x140mm
Gross weight 21.5kg
high power dj audio bass outdoor live power amplifier,audio 4 channel professional audio sanway fp20000q power amplifier best
quality professional,16000W Class D Professional Power Amplifier FP20000Q,FP amplifier series FP14000Q FP20000Q amplifier power
sound system power amplifier,China Made In China High Power Amplifier Fp20000q
