Quick Details
-
Voltage:
-
220V / 380V
-
Power:
-
1000W
-
Weight:
-
2100 KG
-
Dimension(L*W*H):
-
customized
-
Year:
-
2023
-
Product name:
-
Orange peeler machine
-
After-sales Service Provided:
-
Overseas service center available
-
Material:
-
SUS304/316L
-
Speed:
-
2800r/min
-
control type:
-
automatic
-
Effeciency:
-
High
-
Model Number:
-
customized
-
Usage:
-
Juicer Extrator
-
Capacity:
-
3TPH-10TPH
-
Certification:
-
CE and ISO
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Beyond
-
Type:
-
industrial fruit equipment
-
Voltage:
-
220V / 380V
-
Power:
-
1000W
-
Weight:
-
2100 KG
-
Dimension(L*W*H):
-
customized
-
Year:
-
2023
-
Product name:
-
Orange peeler machine
-
After-sales Service Provided:
-
Overseas service center available
-
Material:
-
SUS304/316L
-
Speed:
-
2800r/min
-
control type:
-
automatic
-
Effeciency:
-
High
-
Model Number:
-
customized
-
Usage:
-
Juicer Extrator
-
Capacity:
-
3TPH-10TPH
-
Certification:
-
CE and ISO
Orange peeler machine orange peeling machine orange juicer machine commercial industrial
Product Description
Roller half-cut juice extractor is the international advanced continuous automatic juice extracting machine used for orange, lemon, grapefruit, etc. After the grading and oil extracting, the fruit(orange, lemon, grapefruit) will be fed into this machine, and transported through the bowl-shape conveyor , it will cut them in to two halves, and separately send to two vertical rotating hubs to get the juice, and automatically separate the peel and juice. This machine is continuous type automatic rotation coning juice, it is advanced in structure, stable in transmission, high in production efficiency. During the juicing extracting process, it will not crush the peel of fruit, thus it will provide the high quality juice with high juice yield.
|
1
|
Master machine
|
|
2
|
Auto control Cabinet
|
|
3
|
Extraction of pineapple,apple,pear,berry etc.
|
|
4
|
High jucing rate
|
|
5
|
Energy saving
|
|
6
|
continuous working
|
Direction for use
It adopts the foreign advanced technology, can be applicable for fresh juice extracting from tangerine, orange, grapefruit, lemon, etc., and avoid the bitter vegetable oil remained in fruit cells and residue from fruit peels.
This machine is composed of the parts: machine frame, gear box, juice collecting bucket, left rotor drum, blades, 4-opens rotary tables, right rotor drum, bowl-shape conveyor, safety cover, driving motor, etc. The working theory is the motor drives the main shaft through the V-belt pulley, the main shaft will transfer the power to the following structures: bowl-shape conveyor, 4-opens rotary tables, left rotor drum, and right rotor drum.
-
Description of application effect
The machine is suitable for fresh juice extracting from tangerine, orange, grapefruit, lemon, etc.
Features:
Machine capacity: 300-320 pcs/mins;
Juice extracting rotor drum: 2 numbers;
Extracting heads: 7 pcs/ drum;
Motor power: 5.5kw, 960r/min;
Machine size: 1700×1670×1600mm(Length×Width×Height);
Machine net weight: 2T;
This machine is continuous type automatic rotation coning juice, it is advanced in structure, stable in transmission, high in production efficiency. During the juicing extracting process, it will not crush the peel of fruit, thus it will provide the high quality juice with high juice yield.
The materials contacting with product is made of good quality stainless steel, comply with food hygienic standard;
The whole frame structure, good rigidity, stable working, and small vibration;
It is equipped with centralized CIP cleaning device.
Detailed Images
This machine is continuous type automatic rotation coning juice, it is advanced in structure, stable in transmission, high in production efficiency. During the juicing extracting process, it will not crush the peel of fruit, thus it will provide the high quality juice with high juice yield.The materials contacting with product is made of good quality stainless steel, comply with food hygienic standard.
Size Information
Size Chart of This Design
|
Model
|
Capacity
|
Motor power:
|
Mechanical size
|
Extracting heads
|
|
ZZJ-5
|
5TPH
|
5.5KW,960r/min
|
1700*1670*1600mm
|
7 pcs/ drum
|
|
ZZJ-10
|
10TPH
|
9KW,960r/min
|
2200*2250*2800mm
|
7 pcs/ drum
|
Related Products
Packing&Shipping
Standard Export Package including Wooden case,PE wrap film,Carbon Steel
After Sales Service
After Sales Services
1.Installation and commission on site;
2.Online technical video support;
3.Spare parts;
4.Maintenance services;
2.Online technical video support;
3.Spare parts;
4.Maintenance services;
Company Introduction
Shanghai Beyond Machinery Co., Ltd is a professional technology developing enterprise which mainly engaged in healthy equipment fields. Combined with R& D, procedure design service, turnkey base project, equipment manufacturing, installation, commissioning and training, our company is specialized in turnkey projects services widely applicable to food industry such as fruit and vegetable juice, dairy product and beverage, meat and bone, egg product, etc. and others include fine chemicals as well. Beyond acted as pioneer to introduce and absorb advanced international technology and procedures, continuously innovate and positively promote deep communication and cooperation inside industry, which high effectively push industry develop healthily and orderly.
Our Services & Strength
Installation and commission on site;Online technical video support;Spare parts;Maintenance services; Oversea service agent ; local exhibiton hall.
