Quick Details
-
Customized support:
-
logo
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Diese
-
Model Number:
-
2402WiFi
-
Operating Temperature:
-
-40℃+80℃
-
Working voltage:
-
AC / DC 5V ~ 48V
-
Frequency:
-
433Mhz
-
WIFI:
-
IEEE 802.11 b/g/n
-
Work with:
-
Universal sliding door, garage door controller
-
Work with 2:
-
Led light lamp bulb switch, Home garage control system
-
Working code:
-
rolling code/learning code/fixed code
-
Working temperature:
-
-40℃- +80℃
-
Switch size:
-
94*60*28 mm
-
Operating mode:
-
Momentary mode/Toggle mode
Quick Details
-
Max. Current:
-
3A
-
Max. Voltage:
-
48v
-
Network:
-
RF433Mhz, WiFi
-
Customized support:
-
logo
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Diese
-
Model Number:
-
2402WiFi
-
Operating Temperature:
-
-40℃+80℃
-
Working voltage:
-
AC / DC 5V ~ 48V
-
Frequency:
-
433Mhz
-
WIFI:
-
IEEE 802.11 b/g/n
-
Work with:
-
Universal sliding door, garage door controller
-
Work with 2:
-
Led light lamp bulb switch, Home garage control system
-
Working code:
-
rolling code/learning code/fixed code
-
Working temperature:
-
-40℃- +80℃
-
Switch size:
-
94*60*28 mm
-
Operating mode:
-
Momentary mode/Toggle mode
Product Description
|
Working volt
|
AC / DC 5V ~ 48V
|
|
Contact current
|
<3A
|
|
RF Frequency
|
433Mhz
|
|
WIFI
|
IEEE 802.11 b/g/n
|
|
Size
|
95mm*60mm*25mm
|
|
Weight
|
80g
|
|
control method
|
WIFI(APP/Voice)+RF
|
|
Operating mode
|
Momentary mode/Toggle mode(Manually insert the jumper cap on the control board to T for Toggle mode, and insert it to M for
Momentary mode) |
|
Compatible with
|
PT2262 EV1527SMC5326P HT6P20,HCS300,HCS301,etc.data remote
|
|
Certification
|
CE/FCC/RoHS/UKCA
|
Working Mode Matching method:
1.
Momentary mode
:
1.insert the jumper cap on the control board to M for Momentary mode
2. Press learning button1times
Toggle mode :
insert the jumper cap on the control board to T for Toggle mode 2.Press learning button1times
1.insert the jumper cap on the control board to M for Momentary mode
2. Press learning button1times
Toggle mode :
insert the jumper cap on the control board to T for Toggle mode 2.Press learning button1times
How to clean the code?
Reset Press the learn button 8 times,succeed.
Packing&Shipping
Company Introduction
FAQ
1 .What are the advantages of your company?
A .We have our own factory and we are trading many years;
B. Meet the requirements of the quantity OEM & ODM order available;
C.CE& FCC certification;
D.Offer samples to test.
2. How to proceed an order ?
A: Firstly let us know your requirements or application.
Please confirm the frequency first: 315mhz 433mhz or 868mhz
Then please confirm the chip: rolling code : HCS301, HCS300, HCS200 etc.
Learning code: PT2240, EV1527 etc. Fixed code :SC2260 , SC2262, etc.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.。
3. How long can the remote control use ?
A:ln generally the remote control can be used for many years Only need to replace the battery .
4. What about the lead time?
A:Sample needs 2-5 days, 1000 piece production time needs 1 weeks for order quantity more than
5. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
6. What services can we provide?
Accepted Delivery Terms: CIF,EXW；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
7. Is it OK to print my logo on Remote control and receiver product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
8: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
9: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new one to you immediately.
For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
