Quick Details
-
Brand Name:
-
Enzar
-
Model Number:
-
EM19128
-
Factory:
-
Anping
-
Ref #:
-
0319
Quick Details
-
Project Solution Capability:
-
Others
-
Application:
-
Hotel, Apartment, Warehouse
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Enzar
-
Model Number:
-
EM19128
-
Factory:
-
Anping
-
Ref #:
-
0319
Galvanized Steel Bar Grating
Bar grating, Steel grating,steel grating plate, Expanded metal grating is specially designed with a good percentage of open gaps,and suitable for use in areas requiring good ventilation and emission of light. Its installation is easy and simple, and hence time saving. As the grating is easily cut according to required specifications, that makes the field work simple and quick.
Steel grating is a kind of open steel member with its bearing bar & cross bar jonting at intersections either by welding or by locking. Steel graing is a kind of open steel member with its bearing bar & cross bar jonting at intersections either by welding or by locking.
Steel Grating Standard Specifications
|
No |
Item |
Description |
|
1 |
Bearing bar |
25x3,25x4,30x3,30x4,30x5,32x5,40x5,50x5,.....75x10mm |
|
2 |
Bear bar pitch |
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40,41,60mm. US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x 1/4", 1 1/4"x 1/4", 1 1/2"x 1/4" etc. |
|
3 |
Cross bar pitch |
38,50,76,100,101.6mm |
|
4 |
Material |
Q235,A36,SS304 |
|
5 |
Surface treatment |
Black, hot dipped galvanising, paint |
Steel grating standards:
|
Steel Grating Standard |
|||
|
|
Steel Grating Standard |
Steel Standard |
Galvanizing Standard |
|
China Standard |
YB/T 4001.1-2007 |
GB700-88 |
GB/T13912-2002 |
|
USA Standard |
ANSI/NAAMM(MBG531-88) |
ASTM(A36) |
ASTM(A123) |
|
U.K. Standard |
BS4592-1987 |
BS4360(43A) |
BS729 |
|
Australia Standard |
AS1657-1985 |
AS3679 |
AS1650 |
Finished grating is usually packed with steel belt, & wood is used for matting, for loading convenience. For standard grating panels, we usually use flat bar for packing.
