Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
JD-PJ650
-
Split Screen::
-
Support Picture in Picture(PIP/POP/PAP)
-
Dimension::
-
1024x578.6x123.3mm
-
lcd video wall_DVI::
-
1
-
Composite Video Input/(AV)::
-
3(3xBNC)
-
lcd video wall _nput Voltage::
-
Power Supply AC100V~240V
-
Warranty::
-
1 Year
-
After-sales Service Provided::
-
Video technical support
-
Material::
-
500cd/㎡
-
Viewing Angle::
-
178°
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LCD
-
Color:
-
customize
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
JD-PJ650
-
Split Screen::
-
Support Picture in Picture(PIP/POP/PAP)
-
Dimension::
-
1024x578.6x123.3mm
-
lcd video wall_DVI::
-
1
-
Composite Video Input/(AV)::
-
3(3xBNC)
-
lcd video wall _nput Voltage::
-
Power Supply AC100V~240V
-
Warranty::
-
1 Year
-
After-sales Service Provided::
-
Video technical support
-
Material::
-
500cd/㎡
-
Viewing Angle::
-
178°
Specification
|
Bezel
|
3.5mm
|
|
|
|
LCD Panel
|
Max Resolution Support
|
1920×1080(H×V)
|
|
|
|
Pixel Pitch
|
0.53025（H）×0.53025 (V)
|
|
|
|
Brightness (nits)
|
500 (cd/ m )
|
|
|
|
Contrast
|
4000:1
|
|
|
|
Response Time
|
8ms
|
|
|
|
Color
|
16.7M
|
|
|
|
Visual Angle (H/V)
|
178°(H) / 178°(V)
|
|
|
|
178°(H) / 178°(V)
|
16 : 9
|
|
|
|
Picture quality compensation
|
LTI、CTI
|
|
|
|
Motion compensation
|
AUTO MOVE
|
|
|
|
Filter
|
3D comb filtering，digital noise reduction
|
|
|
|
Video format
|
PAL、NTSC
|
|
|
Video Wall Controller
(Built-in each Screen) |
Computer centralized control interface
|
RS232
|
|
|
Structure
|
Border dimension
|
Top: 2.25mm; bottom :1.25mm; Left: :2.25mm; Right: 1.25mm
|
|
|
|
Net weight
|
25kg
|
|
|
|
Shell material
|
Metal shell, anti-static,anti-magnetic,anti-strong electric field interference
|
|
|
|
Installation way
|
Wall mount，floor standing mount，hanging mount
|
|
Feature
1.Industrial design, 80,000 hours of uninterrupted work, stable performance；
2.High resolution, high contrast, wide viewing angle；
3.narrow design, bilateral stitching is only 0.88mm；
3.narrow design, bilateral stitching is only 0.88mm；
4.Using direct type LED backlight system；
5.Built-in mosaic controller can realize image mosaic display function；
6.3D digital image processing kernel for precise monitoring of more details；
7.Image signal gain function, more stable and correct image control；
8.Realize image restoration and improve system reliability；
9.A variety of signal interfaces, supporting a variety of signal input / output.111
