Quick Details
-
Elongation (≥ %):
-
40
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
Used in chemical, oil, Marine industry
-
Grade:
-
Monel/Inconel/Hastelloy/Nickel Alloy
-
Ni (Min):
-
63%
-
Model Number:
-
tgpx
-
Brand Name:
-
DeLong
-
Keyword:
-
Monel plate
-
Color:
-
Silver
-
Shape:
-
Plate/sheet/bar/pipe
-
Payment term:
-
T/T
-
Package:
-
Standard Sea Worthy Package
-
Usage:
-
Ship building
-
Technology:
-
cold rolled
-
MOQ:
-
500 Kilogram/Kilograms
-
Packing:
-
according to customer's request
Quick Details
-
Resistance (μΩ.m):
-
1.5
-
Powder Or Not:
-
Not Powder
-
Ultimate Strength (≥ MPa):
-
730
-
Elongation (≥ %):
-
40
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
Used in chemical, oil, Marine industry
-
Grade:
-
Monel/Inconel/Hastelloy/Nickel Alloy
-
Ni (Min):
-
63%
-
Model Number:
-
tgpx
-
Brand Name:
-
DeLong
-
Keyword:
-
Monel plate
-
Color:
-
Silver
-
Shape:
-
Plate/sheet/bar/pipe
-
Payment term:
-
T/T
-
Package:
-
Standard Sea Worthy Package
-
Usage:
-
Ship building
-
Technology:
-
cold rolled
-
MOQ:
-
500 Kilogram/Kilograms
-
Packing:
-
according to customer's request
Products Description
Specifications
|
Specifications
|
ASTM / ASME SB 127
|
|
Size
|
1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
|
|
Thickness
|
0.1mm to 12 mm Thk
|
|
Form
|
Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
|
|
Finish
|
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
|
|
Hardness
|
Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
|
|
Monel Plate Metric Dimensions
|
|
|
||
|
Surface finish
|
Thickness (mm)
|
Width (mm)
|
||
|
2B – Cold rolled, heat treated, pickled, skin passed
|
0.25–8.0
|
max. 2032
|
||
|
2D – Cold rolled, heat treated, pickled
|
0.4–6.35
|
max. 1524
|
||
|
2E – Cold rolled, heat treated, mechanically descaled
|
0.4–8.0
|
max. 2032
|
||
|
2R – Cold rolled, bright annealed
|
0.25–3.5
|
max. 1524
|
||
|
2H – Work hardened
|
0.4–6.35
|
max. 1524
|
||
|
Polished, brushed
|
0.5–4.0
|
max. 1524
|
||
|
Monel Grade/Trade Name
|
ASTM/AISI Alloy Type
|
UNS No.
|
%Ni
|
%Cu
|
%Fe
|
%Mn
|
%Al
|
%Ti
|
%Si
|
|
Monel 400
|
B 127/ B 164
|
N04400
|
Min. 63
|
28-34
|
Max 2.5
|
Max 2.0
|
|
|
Max 0.5
|
|
Monel 401
|
|
N04401
|
Min. 63
|
28-34
|
Max 2.5
|
Max 2.0
|
|
|
Max 0.5
|
|
Monel 404
|
|
N04404
|
52-57
|
Remaining
|
Max 0.5
|
Max 0.1
|
Max 0.05
|
|
Max 0.1
|
|
Monel 405
|
B 164
|
N04405
|
Min. 63
|
28-34
|
Max 2.5
|
Max 2.0
|
|
|
Max 0.5
|
|
Monel K500
|
B 865
|
N05500
|
Min. 63
|
27-33
|
Max 2.0
|
Max 1.5
|
2.3-3.15
|
0.35-0.85
|
Max 0.5
|
Advantages
Applications
Due to fabrication by hot- and cold-working, machining, and welding, Monel is extensively used in marine and chemical processing fields. However, the material is costly so can only be used where cheaper alternatives are not available. Usually, Monel piping is more than 3 times as expensive as compared to carbon steel pipe. Typical applications of Monel are valves and pumps; pump and propeller shafts; electrical and electronic components; crude petroleum stills, boiler feedwater heaters, marine fixtures, and fasteners; gasoline and water tanks; fuel tanks; springs; chemical processing equipment; process vessels and piping; heat exchangers; metal instruments; deaerating heaters; musical instruments; refrigerators; film processing; kitchen sinks; roofing; and eye-glass frames. Monel is available in a pipe, fittings, plate, strip, round bar, strip, tube, sheet, and wire form.
Product Process
Packing & Delivery
About Delong Steel
Shandong Delong Metal Products Co., Ltd is a well-known metal steel supplier with 20 years industry experience. As a leading manufacturer of steel materials, the enterprise has established good cooperative relationships with other famous steel plant like TISCO, Bao Steel, Anshan Steel, JISCO, ZPSS, LISCO and so on, enhancing its capacity to offer best reliable sources of products to clients.
We have 50000 tons regular specifications in stock for fast delivery as well as support custom-made production.
We focus on maximum product performance and customer experience with scientific minimum cost,you will get most cost-effective cost.
We focus on maximum product performance and customer experience with scientific minimum cost,you will get most cost-effective cost.
All of our products have been certified by Multiple quality certification and we conduct strict high quality control system. Manufacturer Test Certificate and the Third Party Inspection are all available.
We have the world's advanced processing machine to process any size as clients requirements.
