Quick Details
-
Application:
-
all
-
Design Style:
-
Traditional
-
Floor Heating Valve:
-
all
-
Material:
-
fluoropolymer/XLPE/PVC
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
jiahong
-
Model Number:
-
HX MAT
-
Rated Voltage:
-
120V,208V,240V,277V,347V,480V,600V
-
Output:
-
37W/sq.ft (400W/m2),50W/sq.ft (540W/m2)
-
Bending radius:
-
1.5" (38mm)
-
Color:
-
Black
-
Certification:
-
CSA,CE,EAC,CETL
-
Max. rated Temp.:
-
220℉(105℃)
-
Min. Installation Temp.:
-
40℉(5℃)
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
all
-
Design Style:
-
Traditional
-
Floor Heating Valve:
-
all
-
Material:
-
fluoropolymer/XLPE/PVC
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
jiahong
-
Model Number:
-
HX MAT
-
Rated Voltage:
-
120V,208V,240V,277V,347V,480V,600V
-
Output:
-
37W/sq.ft (400W/m2),50W/sq.ft (540W/m2)
-
Bending radius:
-
1.5" (38mm)
-
Color:
-
Black
-
Certification:
-
CSA,CE,EAC,CETL
-
Max. rated Temp.:
-
220℉(105℃)
-
Min. Installation Temp.:
-
40℉(5℃)
Features
* Twin-conductor cable.
* Durable construction
* Single point connection
* Easy and flexible installation
* 10 years limited warranty.
|
Cable Construction
|
Twin conductor
|
|
Rated Voltage
|
120V, 208V, 240V, 277V, 347V, 480V, 600V
|
|
Output
|
37W/sq.ft (400W/m²)， 50W/sq.ft(540W/m²)
|
|
Heating Element Size
|
6.5' (2.0m)-80' (24.4m) long * 2' (0.6m) wide
|
|
Bending Radius
|
1.5" (38mm)
|
|
Cable Diameter
|
1/4" (6.5mm)
|
|
Conductor Insulation
|
Fluoropolymer and XLPE
|
|
Outer Insulation
|
PVC
|
|
Max. Rated Temp
|
220℉ (105℃)
|
|
Min. Installation Temp
|
40℉ (5℃)
|
|
Cold lead
|
20ft (6m) length
|
|
Approvals
|
ETL/CE/CSA
|
Installing SX Mat snow melting system provides a permanent solution to the problems caused by cold weather. Improve safety by providing instantaneous relief from snow and ice and increase your bottom line by reducing the cost associated with applying chemicals, owning snow clearing machinery or hiring outside services.
WuHu Jiahong New Material Co., Ltd
Jiahong is the largest manufacturer in Asia-pacific. We are always dedicated to research, develop and produce both constant wattage and self-regulating heating cables since 2002. Jiahong has been obtained more than 30 national patents in heating cable industry. Our products are widely used in residential, commercial and industrial areas. The main applications are indoor floor heating, roof & gutter snow melting, residential pipe freeze protection, hazardous industrial oil & gas pipe heat tracing.
Most of WuHu Jiahong products passed UL, CSA, ETL, TUV, CE, ATEX etc. We export to many regions, especially North America, Europe, Australia and Asia. The most professional marketing and R&D team earn good reputation in worldwide.
- 15 sets of high temp and low temp extruding machines.
- 21 sets of braiding machines which produce 40000M cables per day.
Why Choose Us
A1: We are the professional manufacturer since 2002 and specialized in constant wattage heating cables, self-regulating heating cables and thermostat.
Q2: How much the transportation freight of sample?
A2: The sample freight depends on the weight, packing size and your area.
Q3: How can I get the samples?
A3: You should pay for the cost and freight of samples, while the sample cost can be refunded after you place the order.
Q4: If your heating cable is eco-friendly?
A4: Our heating cable is all in accordance with ROHS, do not contain Lead(Pb), Cadmium(Cd), Mercury(Hg), Chromium VI(Cr VI), PBBs&PBDEs.
Q5: If your heating cable are anti-flame and waterproof?
A5: Our raw material of heating cable is all anti-flame material and waterproof classification is IP67.
Q6: Can I cut the heating cable anywhere?
A6: If you can identify parallel type and constant wattage type, the parallel type can cut and connect two cables together. But constant wattage type it's not available to cut. If you are not able to identify the type, please contact us directly.
Q7: If the heating cable can use on industrial area and hazardous area?
A7: Yes, our braiding coverage rate is over 90% and in certify to IECEx and ATEX, it's applicable to the industrial area and hazardous area.
