Quick Details
-
Voltage:
-
220V
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Longer
-
Dimension(L*W*H):
-
2800*780*1570mm
-
Weight:
-
280 KG
-
Certification:
-
CE ISO
-
Marketing Type:
-
Hot Product
-
Function:
-
For carton box, egg tray, etc
-
Max Load wight:
-
70 Kg
-
Heating furnace dimension:
-
1600*730*1300mm
-
Conveying speed:
-
0-15m/minute
-
Feature:
-
Flexible Size Ranges
-
Packing material:
-
POF, PE, PVC Film
Quick Details
-
Packaging Type:
-
Film
-
Packaging Material:
-
Plastic
-
Driven Type:
-
Electric
-
Voltage:
-
220V
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Longer
-
Dimension(L*W*H):
-
2800*780*1570mm
-
Weight:
-
280 KG
-
Certification:
-
CE ISO
-
Marketing Type:
-
Hot Product
-
Function:
-
For carton box, egg tray, etc
-
Max Load wight:
-
70 Kg
-
Heating furnace dimension:
-
1600*730*1300mm
-
Conveying speed:
-
0-15m/minute
-
Feature:
-
Flexible Size Ranges
-
Packing material:
-
POF, PE, PVC Film
This shrink wrapping machine is a fully automatic unmanned operation L-bar sealer which is widely used in mass production packaging line with high efficiency. Automatic film feeding punching device, manually adjustable film-guide system and feeding conveyor platform make the machine suitable for different width and height items.
|
Model
|
CK-DQL5545G
|
CK-DSC4525L
|
|
|
Max packing size(mm)
|
L+2H≤550, W+2H≤450,H<130
|
W450*H250
|
|
|
Max sealing size(mm)
|
L550×W450
|
/
|
|
|
Power(KW)
|
1.3
|
9
|
|
|
Capacity
|
0-24m/min
|
0-16m/min
|
|
|
Voltage
|
220V 50/60HZ
|
380V 50/60HZ
|
|
|
Sealing temperature
|
180℃-250℃ depends on thickness of film and environment temperature
|
180℃-250℃ depends on thickness of film and environment temperature
|
|
|
Thickness of film(mm)
|
0.015-0.10
|
/
|
|
|
Air pressure(Kg/cm2) )
|
5
|
/
|
|
|
Packing material
|
POF PVC
|
|
|
|
Machine weight(kg)
|
320
|
220
|
|
|
Machine size(mm)
|
L1700*W900*H1400
|
L1800*W703*H1260
|
|
Main Application
Suitable film: POF
Application: food, cosmetics, stationary, hardware, daily used products, etc.
Packaging style: L type full closed sealing packing
Packaging style: L type full closed sealing packing
