Quick Details
-
connector standard:
-
type 2 to type 2
-
Protection rank:
-
IP55
-
cable color:
-
black
-
Rated Current:
-
16A 3Phase
-
packages:
-
Each in PE bag, then in Pizza box
-
Cable Spec:
-
5x6.0mm²+2x0.5mm²
-
Power:
-
11kW
-
Operating temperature:
-
-30℃ to 50℃
-
Withstand voltage:
-
2000V
Quick Details
-
Place of Origin:
-
Guangdong, China, Zhongshan, China
-
Model Number:
-
V1-16T
-
Brand Name:
-
Auxus
-
connector standard:
-
type 2 to type 2
-
Protection rank:
-
IP55
-
cable color:
-
black
-
Rated Current:
-
16A 3Phase
-
packages:
-
Each in PE bag, then in Pizza box
-
Cable Spec:
-
5x6.0mm²+2x0.5mm²
-
Power:
-
11kW
-
Operating temperature:
-
-30℃ to 50℃
-
Withstand voltage:
-
2000V
Products Description
|
Electrical Performance
|
|
|
|
Protection rank
|
IP55
|
|
|
Fire retardant level
|
94 V-0
|
|
|
Rated Current
|
16A / 32A
|
|
|
Rated voltage
|
250V / 480V~
|
|
|
Insulation resistance
|
> 1000M ohm (DC 500V)
|
|
|
Terminal temperature rise
|
<50K
|
|
|
Withstand voltage
|
2000V
|
|
|
Contact resistance
|
0.5m ohm Max
|
|
|
Coupled insertion force
|
0.5m ohm Max
|
|
|
Coupled insertion force
|
>45N <80N
|
|
|
Operating temperature
|
- 30℃ to + 50℃
|
|
|
Mechanical Testing
|
|
|
|
Mechanical life
|
no load plug in / pull out > 10000 times
|
|
|
Impact of external force
|
qualify 1m drop or 2 Ton vehicle run over
|
|
|
Materials Applied
|
|
|
|
Connector
|
by copper alloy with nickel bottom plating and 3um silver surface plating
|
|
|
|
white/ black by thermoplastic PC. Fire retardant. Other color optional by customizing
|
|
|
Cable
|
black with TPU jacket. Other color optional by customizing
|
|
|
Features
|
|
|
|
|
Product conforms to IEC61851-1:2010 mode 3 & B2, and EN62196-2:2017,EN62196-1:2014
IP55 protection; Fire-retardant; Pressure resistance; Abrasion resistance; Impact resistance |
|
|
Package
|
|
|
|
Package
|
Each in PE bag, then in Pizza box, then 5 Pizza boxes into 1 master carton
Deluxe pack: each in Oxford cloth with zipper & handle, easy for end users to keep |
|
|
Customizing
|
|
|
|
Customizing
|
Logo put on shell by laser or flexible tooling; on Oxford cloth bag by printing
|
|
|
Certificate
|
|
|
|
Certificate
|
CE, UKCA, ROHS, ISO
|
|
White.
Black.
|
Connector Type
|
Type 2 to Type 2
|
Type 2 to Type 2
|
Type 2 to Type 2
|
Type 2 to Type 2
|
|
Max.AC Charging Current
|
16A
|
32A
|
16A
|
32A
|
|
Max.Output
|
3.6KW
|
7.2KW
|
11W
|
22KW
|
|
Cable Length
|
5m
|
5m
|
5m
|
5m
|
|
Phase
|
Single Phase
|
Single Phase
|
Three Phase
|
Three Phase
|
|
FREE Carry Bag Included
|
√
|
√
|
√
|
√
|
CAUTION:
1. Don't submerge the EV charging cable in water.
2. Don't step on, fold or knot the cable.
3. Don't drop the EV charging box or place a heavy object on it.
4. Don't place the charging cable near high temperature object when charging.
5. Don't operate the EVSE in temperatures beyond its operating range of -30°C to 50°C.
6. Power-supply side input cable should be at least 3*2.5mm (recommended 3*4mm), with a standard 16A socket. It is suggested that
the power distribution is done by the professionals.
7. Don't put fingers into the charging connector when the power plug is still connecting to the power.
8. Don't use this EV charging box when the cable is damaged.
9. The EV charging box is only for EV charging using.
10. Don't use this device with other brand's extension cord or adapter.
2. Don't step on, fold or knot the cable.
3. Don't drop the EV charging box or place a heavy object on it.
4. Don't place the charging cable near high temperature object when charging.
5. Don't operate the EVSE in temperatures beyond its operating range of -30°C to 50°C.
6. Power-supply side input cable should be at least 3*2.5mm (recommended 3*4mm), with a standard 16A socket. It is suggested that
the power distribution is done by the professionals.
7. Don't put fingers into the charging connector when the power plug is still connecting to the power.
8. Don't use this EV charging box when the cable is damaged.
9. The EV charging box is only for EV charging using.
10. Don't use this device with other brand's extension cord or adapter.
