Quick Details
-
Power:
-
50-1000KW
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
50000 kg
-
Product name:
-
Best Price Calculation Lime Rotary Kiln For Construction
-
Application:
-
Active Lime Plant
-
Capacity:
-
50-1000tpd
-
Spare Parts Supply:
-
Supply at lowest price
-
Installation and trial:
-
Send Engineer
-
Factory Visit:
-
Invitation Letter
-
Design drawings:
-
Provided
-
Quality:
-
International Standard
-
Calcination material:
-
Limestone, Cement clinker
-
After-sales Service Provided:
-
Online support
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
UNISHINE
-
Voltage:
-
220-480V
-
Power:
-
50-1000KW
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
50000 kg
-
Product name:
-
Best Price Calculation Lime Rotary Kiln For Construction
-
Application:
-
Active Lime Plant
-
Capacity:
-
50-1000tpd
-
Spare Parts Supply:
-
Supply at lowest price
-
Installation and trial:
-
Send Engineer
-
Factory Visit:
-
Invitation Letter
-
Design drawings:
-
Provided
-
Quality:
-
International Standard
-
Calcination material:
-
Limestone, Cement clinker
-
After-sales Service Provided:
-
Online support
|
Model |
Diameter of cylinder (mm) |
Length of cylinder (mm) |
Inclination (%) |
Capacity (t/h) |
Rotation speed (rpm) |
Power (kw) |
Weight (t) |
|
YZ1225 |
1200 | 25000 | 4 | 3 |
0.53-5.25 |
22 | 34 |
|
YZ1632 |
1600 | 32000 | 4 | 3.5 |
0.53-5.25 |
15 | 46.82 |
|
YZ1828 |
1800 | 28000 | 4 | 4 |
0.28-2.84 |
30 | 59.39 |
|
YZ1845 |
1800 | 45000 | 4 | 4.5 |
0.28-2.84 |
30 | 80 |
|
YZ1636 |
1600 | 36000 | 4 | 1.2-1.9 |
0.26-2.61 |
22 | 51.023 |
|
YZ1939 |
1900 | 3900 | 4 | 1.6-3.4 |
0.31-2.82 |
37 | 70.704 |
|
YZ2044 |
2000 | 44000 | 3.5 | 2.4-4 |
0.22-2.26 |
37 | 97.135 |
|
YZ2245 |
2200 | 45000 | 3.5 | 3.2-5.3 |
0.23-2.25 |
45 | 125.462 |
|
YZ2550 |
2500 | 50000 | 3.5 | 6.2-7.4 |
0.68-1.45 |
55 | 179.606 |
|
YZ2555 |
2500 |
55000 |
3 | 7.3-9.8 | 0.79-2.38 | 55 | 191.203 |
|
YZ2820 |
2800 |
20000 |
4 |
15-18 |
0.8-1.45 |
75 | 186.373 |
| YZ3028 | 3000 |
28000 |
4 | 18-23 |
0.8-1.45 |
75 | 180.737 |
| YZ3060 | 3000 | 60000 | 3.5 |
16-20 |
0.49-2.41 | 90 | 272.510 |
| YZ3226 | 3200 | 26000 | 4 | 22-27 | 0.8-1.45 | 90 | 185.107 |
| YZ3255 | 3200 | 55000 | 3.5 |
17-23 |
0.1-1.52 |
75 | 271.673 |
| YZ3529 | 3500 | 29000 | 4 |
28-40 |
0.16-1.38 |
110 | 238.031 |
|
YZ3560 |
3500 | 60000 | 3.5 | 28-40 | 0.65-2.25 | 125 | 347.872 |
| YZ4030 | 4000 | 30000 | 4 | 52-70 | 0.38-3.52 | 160 | 415.103 |
|
YZ4060 |
4000 | 60000 | 3.5 | 55-78 | 0.38-3.52 | 315 | 514.223 |
|
YZ4262 |
4200 | 62000 | 3.5 | 80-105 |
0.38-3.52 |
315 | 541.615 |
| YZ4565 | 4500 | 65000 | 3.5 |
110-140 |
0.38-3.52 |
420 | 609.526 |
| YZ4772 | 4700 | 72000 | 3.5 |
150-190 |
0.38-3.52 |
550 | 795.325 |
| YB1626 | 1600/1400 | 26000 | 4 | 0.7-11 |
0.41-3.85 |
18.5 | 38.621 |
|
YB1939 |
1900/1600 | 39000 | 4 |
2.2-2.7 |
0.27-2.58 |
22 | 60.841 |
| YB2245 | 2200/2000 | 45000 | 3.5 |
2.5-3.5 |
0.25-2.28 | 30 | 88.632 |
| YB2545 |
2500/2200 |
45000 | 3.5 | 4.5-6.2 | 0.25-2.18 | 45 | 102.367 |
| YB2845 |
2800/2500 |
45000 | 3.5 |
7.5-10 |
0.68-1.45 |
55 | 192.622 |
| YB3560 |
3500/3000 |
60000 | 3.5 |
23-32 |
0.65-2.28 | 125 | 310.263 |
Ferronickel rotary kiln
Capacity : 180-1000t/d
Applicable materials : Laterite nickel ore.
Application : Mainly used in building materials, metallurgy, chemical industry, refractory materials, environmental protection and other industries.
Brief Introduction: Ferronickel rotary kiln is a high-quality calcining equipment developed according to the characteristics of nickel iron ore. It mainly consists of cylinder, motor, gear device, heating system, etc. the equipment configuration is very high, and the operation is quite simple and convenient.
Introduction
Ferronickel is a kind of metal compound with high iron content. Its comprehensive utilization value is very high, and its application field is quite wide. It plays a very important role in industry, construction, chemical industry, metallurgy and other industries. Ferronickel rotary kiln is a high-quality calcining equipment developed according to the characteristics of the ore. It is mainly composed of cylinder, motor, blocking wheel device, heating system, etc. the configuration of the equipment is very high, and the operation is quite simple and convenient.
Characteristics
1. Large cylinder volume, large material handling capacity, high work efficiency and high production capacity;
2. Good sealing, low noise, strong environmental protection and lower energy consumption;
3. Stable operation and longer service life;
4. Good safety and higher safety factor;
5. Automatic control, simple operation;
