Quick Details
-
Panel Size:
-
320X320mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
T3.3-HD
-
Pixel Pitch:
-
3.3mm, 3.3mm
-
Ingress protection:
-
IP65
-
Brightness:
-
≥4500 nits
-
Cabinet dimension:
-
981X341X106mm,38.62"X13.43"X4.17" double side
-
Cabinet resolution:
-
288X96pixel, double side
-
Weight:
-
Approx 20KG
-
Power consumption:
-
AVG. 120W
-
Input voltage:
-
9-36V DC, (work with car battery )
-
Operation system:
-
Andorid/ Linux
-
Network:
-
4G/WIFI, GPS (Geo-Targeting)
-
Installation:
-
Roof rack
Quick Details
-
Application:
-
Outdoor advertising
-
Brand Name:
-
HXTECH
-
Color:
-
FULL COLOR
-
Panel Size:
-
320X320mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
T3.3-HD
-
Pixel Pitch:
-
3.3mm, 3.3mm
-
Ingress protection:
-
IP65
-
Brightness:
-
≥4500 nits
-
Cabinet dimension:
-
981X341X106mm,38.62"X13.43"X4.17" double side
-
Cabinet resolution:
-
288X96pixel, double side
-
Weight:
-
Approx 20KG
-
Power consumption:
-
AVG. 120W
-
Input voltage:
-
9-36V DC, (work with car battery )
-
Operation system:
-
Andorid/ Linux
-
Network:
-
4G/WIFI, GPS (Geo-Targeting)
-
Installation:
-
Roof rack
Products Description
Slim in depths and light in weight
Strong profile aluminum frame with the weight less than 20KG.Reducing driver's loading cost.106mm in depth with a brilliant curve angle design reduce the
air resistance.
Energy saving
Energy saving design with a start up delay to protect the car battery.
Web based cloud system
Remote publish play program, publish your program anywhere anytime via 3G/4G or wifi.
Geo targeting
You can design GPS-based advertising map zones, and trigger specific ads to taxi top LED displays running in your target areas.
High brightness
Direct LED light display deliver a high visible brightness more than 4500 nits.It is visible even under direct sunlight.
Product Paramenters
|
Item
|
Parameters
|
|
Working environment
|
Outdoor
|
|
Model
|
T3.3-HD
|
|
LED type
|
3 in 1 SMD
|
|
Active display size(HxV)
|
960X320mm
|
|
Display resolution
|
288X96pixel
|
|
Cabinet material
|
Profile aluminum
|
|
IP rating
|
IP65
|
|
White balance brightness
|
≥4500 nits
|
|
Refresh rate(HZ)
|
≥3840
|
|
Input voltage
|
DC 9V-36V
|
|
AVG. power(W)
|
≤120
|
|
Processing
|
16bit/color
|
|
Operating temperature range
|
-20°C to +60°C
|
|
Operating humidity
|
10%~90%
|
|
Life time(50% brightness)
|
100,000 hours
|
|
Network
|
WIFI, USB,4G
|
|
GPS function
|
Available
|
|
Cloud management
|
Available
|
|
Installation method
|
Roof rack
|
