Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MAP
-
Weight (KG):
-
1950 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Rated loading:
-
1500kg
-
Bucket Capacity:
-
0.7CBM
-
Manufacturer:
-
Weifang Map Power
-
Color:
-
According to customer' request
-
After Warranty Service:
-
Video technical support
Quick Details
-
Engine Capacity:
-
1012
-
Size:
-
3320-2780*2150
-
Gross Vehicle Weight:
-
2300
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MAP
-
Weight (KG):
-
1950 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Rated loading:
-
1500kg
-
Bucket Capacity:
-
0.7CBM
-
Manufacturer:
-
Weifang Map Power
-
Color:
-
According to customer' request
-
After Warranty Service:
-
Video technical support
4wd 1.5ton dumper truck, 4wd small garbage truck small dumper truck
Weifang Map Power Company ,supply dumper cover 0.8T to 5T, with all kinds of implements and adjustable design
Main Features of FCY15S 4wd Garbage Truck:
1.4*4 drive type
2.rated load 1500kg, bucket capacity:0.7cbm
3. single cylinder water cooled diesel engine
4.Min. turning radius:3500mm
5. CE approved
Here is the detailed information of 1.5T site dumper, pls kindly check:
| DUMPER MODEL | FCY20 | |
| Engine details | Model | 390 |
| Engine Type | In-line, water-cooled, 3 cylinders, diesel engine | |
| Rated Power | 25kw | |
| Rated Speed | 2200r/min | |
| Bucket | Bucket Capacity | 0.7m³ |
| Rated Loading Weight | 1500kg | |
| Operating Weight | 1000kg | |
| Dimensions | Overall Length | 3800mm |
| Overall Height | 2200mm | |
| Overall Width | 1500mm | |
| Wheel Base | 1280mm | |
| Tread | 1500mm | |
| Minimum turn radius | 3500mm | |
| Tire | Front tire:7.50/16 | Rear Tire:7.50/16 |
| Drive Type | 4*4 Wheel Drive | |
For any questions,
Dumpers brief introduction:
As a low-volume, short-distance transport of bulk materials for small site dumpers, because of its easy operation, small turning radius can be used in a narrow environment, etc,. Dumpers are widely used in many different occasions, such as the construction industry, the factory floor, battlefield ,protecting road section, the municipal engineering, underground mines and so on.
