Quick Details
-
Brand Name:
-
MiWi
-
Model Number:
-
SCN-1500-15
-
Output Frequency:
-
47 ~ 63Hz
-
Output Current:
-
100A
-
Product Name:
-
Dc Power Supply 100A
-
Rated Current:
-
100A
-
DC Output Power:
-
1500W
-
Input Current:
-
15.0A/230VAC
-
Current Range:
-
0-100A
-
AC Inrush Current:
-
120A / 230VAC
-
Efficiency (Typ.):
-
83%
-
Voltage Tolerance:
-
± 1%
-
Dimension:
-
291*132*132 mm
-
Certifications:
-
CE
Quick Details
-
Input Voltage:
-
200 ~ 240VAC 290 ~ 370VDC
-
Output Voltage:
-
15V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
MiWi
-
Model Number:
-
SCN-1500-15
-
Output Frequency:
-
47 ~ 63Hz
-
Output Current:
-
100A
-
Product Name:
-
Dc Power Supply 100A
-
Rated Current:
-
100A
-
DC Output Power:
-
1500W
-
Input Current:
-
15.0A/230VAC
-
Current Range:
-
0-100A
-
AC Inrush Current:
-
120A / 230VAC
-
Efficiency (Typ.):
-
83%
-
Voltage Tolerance:
-
± 1%
-
Dimension:
-
291*132*132 mm
-
Certifications:
-
CE
You are here: Home >> Single Output Series >> SCN Series
MiWi SCN-1500-15 Single Output Dc 1500W 15V 100A Switching Power Supply
- AC input 200~240V only
- Protections: Short circuit / Overload / Over voltage / Over temp.
- High reliability/ Low ripple noise
- Built-in remote sense function
- Built-in remote ON-OFF control
- Built-in parallel operation function
- Can adjust from 20~100% output voltage by external control 1-5V
- Forced air cooling by built-in DC fan
- Case coating with paint
- 2 years warranty
| Model | SCN-1K5-12 | SCN-1K5-15 | SCN-1K5-24 | SCN-1K5-48 |
| DC Output Voltage | 12V | 15V | 24V | 48V |
| Iutput Voltage Error | ± 1% | ± 1% | ± 1% | ± 1% |
| Rated Output Current | 125A | 100A | 62.5A | 32A |
| Output Current Range | 0-125A | 0-100A | 0-62.5A | 0-32A |
| Tripple and Noise | 240mVp-p | 240mVp-p | 240mVp-p | 480mVp-p |
| Voltage Adj range | ±5.0% typical adjustment by potentiometer 20~100% adjustment by 1~5VDC external control | |||
| Iniet Stability | ± 0.5% | ± 0.5% | ± 0.5% | ± 0.5% |
| Tolerance Voltage | ± 1% | ± 1% | ± 1% | ± 1% |
| DC Output Power | 1500W | 1500W | 1500W | 1536W |
| Efficiency | 84% | 83% | 85.5% | 87% |
| AC Input Voltage Range | 200 ~ 240VAC 290 ~ 370VDC | |||
| Input Current | 15.0A/230VAC | |||
| AC Inrush Current | Cold-Start Current: 120A / 230VAC | |||
| Leakage Current | 3.5mA/240VAC | |||
| Overload Protection | 110 ~ 135% rated output power,Current limiting, delay shut down o/p voltage, re-power on to recover | |||
| Over Voltage Protection | 110 ~ 135% follow to output set up point, Shut down o/p voltage, re-power on to recover | |||
| High Temperature Protection | >100℃ / measure by heat sink, near transformer,Shut down o/p voltage, re-power on to recover | |||
| Temperature Coefficient | ± 0.04% /℃ (0~50℃) | |||
| Start, Rise, Hold time | 800ms, 50ms, 16ms at full load | |||
| Vibration | 10 ~ 200Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes | |||
| Withstand Voltage | I/P-O/P, I/P-FG:1500VAC | |||
| Isolation Resistance | I/P-O/P, I/P-FG, 100M Ohms / 500VDC / 25 ℃/ 70% RH | |||
| Working Temp,Humidity | `-10℃~+60℃ (Refer to Output Derating Cutve), 20%~90%RH | |||
| Storage Temp,Humidity | `20℃~+85℃, 10%~95%RH | |||
| MTBF | 60Khrs min. MIL-HDBK-217F (25 ℃) | |||
| Overall Dimension | 291*132*132 mm | |||
| Weight | 4.75 kgs | |||
| Special function |
DC voltage adj., Remote sensing, remote control, parallel operation (refer to terminal instruction manual) |
|||
| Safety Standards | CE | |||
| EMC Standards | Meet FCC Part 15J Conduction class A | |||
| Note |
1. 1.All parameters are specified at 230VAC input, rated load, 25℃ 70% RH ambient.
2. Tolerence: includes set up tolerance, line regulation, load regulation 3. Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor. 4.The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. |
|||
