Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Greensun
-
Model Number:
-
GRS 5000H
-
Input Voltage:
-
48V
-
Output Voltage:
-
220/230/240V;110/120V; 120/240V
-
Output Current:
-
22A
-
Output Frequency:
-
50/60HZ
-
Size:
-
446.9*350*133mm
-
Certificate:
-
CE UL, CE ISO ROHS
-
Warranty:
-
5Years, 5 Years
-
Weight:
-
13kg
-
Product name:
-
inverter 5kw
-
Application:
-
Solar Power System Home
-
Protection:
-
IP65
-
Max PV Input Power:
-
5.5KW
-
Communication:
-
RS485; CAN
-
Efficiency:
-
≥99.9%
-
Cooling:
-
intelligent fan
-
Delivery time:
-
15 working days
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
90-93%
-
Place of Origin:
-
China
-
Brand Name:
-
Greensun
-
Model Number:
-
GRS 5000H
-
Input Voltage:
-
48V
-
Output Voltage:
-
220/230/240V;110/120V; 120/240V
-
Output Current:
-
22A
-
Output Frequency:
-
50/60HZ
-
Size:
-
446.9*350*133mm
-
Certificate:
-
CE UL, CE ISO ROHS
-
Warranty:
-
5Years, 5 Years
-
Weight:
-
13kg
-
Product name:
-
inverter 5kw
-
Application:
-
Solar Power System Home
-
Protection:
-
IP65
-
Max PV Input Power:
-
5.5KW
-
Communication:
-
RS485; CAN
-
Efficiency:
-
≥99.9%
-
Cooling:
-
intelligent fan
-
Delivery time:
-
15 working days
Products Description
Solar System Configuration
|
Datasheet
|
GRS 3500H
|
GRS 5000H
|
GRS 8000H
|
GRS 10000H
|
||||
|
INVERTER OUTPUT
|
|
|
|
|
||||
|
Rated Output Power
|
3000W
|
5000W
|
8000W
|
10000W
|
||||
|
Max.Peak Power
|
6000VA
|
10000VA
|
16000W
|
20000W
|
||||
|
Rated Output Voltage
|
120Vac（L/N/PE Single-phase）
|
|
120/240Vac（L1/L2/N/PE split phase）
|
|
||||
|
Load Capacity of Motors
|
2HP
|
4HP
|
5HP
|
6HP
|
||||
|
Waveform
|
Pure Sine Wave
|
|
|
|
||||
|
Parallel Capacity
|
/
|
1-6 units (1/2/3 phase)
|
/
|
/
|
||||
|
BATTERY
|
|
|
|
|
||||
|
Battery Type
|
Li-ion / Lead-Acid / User Defined
|
|
|
|
||||
|
Rated Battery Voltage
|
24Vdc
|
48Vdc
|
|
|
||||
|
Max.MPPT Charging Current
|
60A
|
100A
|
200A
|
200A
|
||||
|
Max.Mains/Generator Charging Current
|
40A
|
40A
|
100A
|
120A
|
||||
|
Max.Hybrid Charging Current
|
100A
|
100A
|
180A
|
200A
|
||||
|
PV INPUT
|
|
|
|
|
||||
|
Num. of MPPT Trackers
|
1
|
1
|
2
|
2
|
||||
|
Max.PV Array Power
|
1600W
|
5500W
|
11000W
|
11000W
|
||||
|
Max.Input Current
|
40A
|
22A
|
22A/22A
|
22A/22A
|
||||
|
Max.Voltage of Open Circuit
|
108Vdc
|
500Vdc
|
500Vdc
|
500Vdc
|
||||
|
MPPT Voltage Range
|
30-90Vdc
|
125~450Vdc
|
125~425Vdc
|
125~425Vdc
|
||||
|
Bypass Overload Current
|
40A
|
63A
|
63A
|
63A
|
||||
|
GENERAL
|
|
|
|
|
||||
|
Dimension
|
378*280*103mm
|
446.9*350*133mm
|
620*435*130mm
|
620*435*130mm
|
||||
|
Weight
|
6.8kg
|
13kg
|
20kg
|
21kg
|
||||
|
Embedded Interfaces
|
RS485 / USB / Dry contact
|
|
|
|
||||
|
External Modules
|
Wi-Fi / GPRS
|
|
|
|
||||
Factory and Production
Greensun Solar Energy Tech. Co., Limited is a professional, fast growing company. Greensun Solar is well known as a world leading manufacturer of cost-effective, high efficiency and good quality photovoltaic panel, storage battery, and complete solar energy system for residential and C&I application.
Having professional engineering team, Greensun Solar provide best design and customization of One-Stop Solar Solution. Greensun Solar was founded in 2004, headquartered in Hefei, Anhui China.
Our factory covers 90,000 square meters area and has more than 2,000 employees. Greensun Solar has 15years experience in solar industry and is dedicated to research and development, production innovation and strict quality control management.
We have comprehensive product range: solar panel, inverter, controller, battery, on grid and off grid solar system, hybrid solar system and solar pump system.
We aim to manufacture and provide reliable and innovated solar panel and solar energy solutions to the world.
We aim to manufacture and provide reliable and innovated solar panel and solar energy solutions to the world.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Global Project
We have sold and installed over 20,000 solar systems around the world.
Including residential energy storage systems and large-scale commercial solar photovoltaic systems.
Contribute to global carbon neutrality.
Why Choose Us
1. We are a real factory and have strict requirements on the quality of products.
2. We provide OEM services for many leading companies around the world.
It has long-term cooperation with Longi, Risen, Jinko and other first-line brands.
3. As a factory, we have better control over product costs.
4. Both production and delivery are very fast.
5. Also, we provide stable and long-term after-sales service.
