Quick Details
-
Model Number:
-
627-236
Quick Details
-
Warranty:
-
12 months
-
Place of Origin:
-
China
-
Brand Name:
-
Emerson
-
Model Number:
-
627-236
Product Description
Specification
|
tem
|
value
|
|
Warranty
|
1 year
|
|
Place of Origin
|
China
|
|
Brand Name
|
Fish-er
|
|
Model Number
|
627 Series Commercial / Industrial Regulators
|
|
Body Sizes
|
3/4, 1, or 2
|
|
End Connections
|
NPS 1 or 2 / DN 25 or 50: CL150 RF, CL300 RF
|
|
NPT Steel Maximum Inlet Pressure
|
2000 psig / 138 bar
|
|
Flanged Steel Maximum Inlet Pressure
|
1500 psig / 103 bar
|
|
Ductile Iron Maximum Inlet Pressure
|
1000 psig / 69,0 bar
|
|
Outlet Pressure Range
|
5 to 500 psig / 0,34 to 34,5 bar in six ranges
|
|
Approximate Weights
|
Ductile Iron or Steel Casings: 10 pounds / 5 kg
|
|
Internal Pressure Registration
|
Type 627, 627H or 627R/Type 627M, 627HM or 627MR
|
|
External Pressure Registration
|
through 1/4 NPT internal control line connection
|
|
Temperature Capabilities
|
-20° to 180°F / -29° to 82°C
|
Packing & Delivery
carton
