Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
CANMAX
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1700*1100*1600mm
-
Weight:
-
950 KG
-
Warranty:
-
1 Year, 12 Months
-
Method to press:
-
Hydraulic Press
-
Raw material:
-
Soybean,sesame,sunflower seeds,peanut,oil seeds,
-
Material:
-
316 Stainless Steel
-
Package:
-
Wooden Case
-
Product name:
-
Oli Press Machine
-
Application:
-
Edible Oil Production Line
-
Function:
-
Cold Press
-
Advantage:
-
Energy Saving
-
Certification:
-
CE ISO
Quick Details
-
Applicable Industries:
-
Oil factory
-
Use:
-
multifunctional
-
Production Capacity:
-
100%
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
CANMAX
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1700*1100*1600mm
-
Weight:
-
950 KG
-
Warranty:
-
1 Year, 12 Months
-
Method to press:
-
Hydraulic Press
-
Raw material:
-
Soybean,sesame,sunflower seeds,peanut,oil seeds,
-
Material:
-
316 Stainless Steel
-
Package:
-
Wooden Case
-
Product name:
-
Oli Press Machine
-
Application:
-
Edible Oil Production Line
-
Function:
-
Cold Press
-
Advantage:
-
Energy Saving
-
Certification:
-
CE ISO
Oil press machine is to separate the oil from oil corps by the pressing power which comes from the big pressure created in press chamber by the hydraulic cylinder, the oil can be discharged from gap of press bars and press rings.
Features of oil press machine:
* Stainless steel machine base and national certified steel frame;
* Special oil pump structure make the pressing fast and with longer life-span;
* High Manganese alloy steel bars ;
* Vegetable oil seeds, soybeans, peanuts, cotton seeds, sesame seeds, palm kernel, coconut, etc
* Compact structure, stable function, simple operation and maintenance
| Model | YZ-150 | YZ-180 | YZ-230 | YZ260 | YZ-320 | YZ-360 | YZ-415 | YZ-460 |
| Dimension (M) | 0.7*0.8*0.78 | 0.8*0.9*1.05 | 0.9*1*1.4 | 1.05*1.1*1.55 | 1.12*1.2*1.65 | 1.2*1.2*1.68 | 1.25*1.25*1.7 | 1.5*1.5*2.15 |
| Weight (KG) | 240KG | 550KG | 950KG | 1200KG | 1700KG | 2000KG | 2200KG | 3000KG |
| Pressure (KN) | 650KN | 1600KN | 2200KN | 2600KN | 3000KN | 3600KN | 4300KN | 4800KN |
| MPA | 55-60 | 55-60 | 55-60 | 55-60 | 55-60 | 55-60 | 55-60 | 55-60 |
| Heater Power (W) | 600W | 720W | 850W | 950W | 1100W | 1250W | 1500W | 2000W |
| Temp. (℃) | 50-70 | 50-70 | 50-70 | 50-70 | 50-70 | 50-70 | 50-70 | 50-70 |
| Volume (KG) | 2 | 4 | 8 | 12 | 17.5 | 22.5 | 30 | 45 |
| Capacity (KG/DAY) | 300 | 480 | 960 | 1440 | 1680 | 2160 | 2880 | 4320 |
| Motor Power (KW) | 0.75KW | 1.5KW | 1.5KW | 1.5KW | 2.2KW | 2.2KW | 2.2KW | 3.0KW |
| Oil Specs | |||||
| Items |
Oil Yield
Efficiency % |
Residual Oil Ratio | Condition | ||
| Impurity | Moisture | Acid Value | |||
| Sesame | >94% | <6% | <0.2 | <0.2 | <4.0 |
| Peanut | >94% | <6% | <0.2 | <0.2 | <4.0 |
| Rapeseed | >95% | <5% | <0.2 | <0.2 | <4.0 |
| Soybean | >95% | <5% | <0.2 | <0.2 | <4.0 |
| Cotton Seed | >95% | <5% | <0.2 | <0.2 | <4.0 |
