Quick Details
-
Voltage:
-
220V/380V/440V or follow your need
-
Dimension(L*W*H):
-
580*580*560---2200*2200*1680mm
-
Weight:
-
75 KG
-
Product name:
-
Cocoa seed circular vibrating sieve shaker
-
Material:
-
Stainless Steel 304, base carbon steel
-
Function:
-
Screening\separation\sorting\sieving
-
Keyword:
-
Cocoa seed circular vibrating sieve shaker
-
Layer:
-
1-5 layers
-
Mesh type:
-
Wire mesh/ punching hole
-
Screen mesh:
-
5--625mesh
-
Sieving Diameter:
-
320~1750mm
-
Cleaning system:
-
Cleaning of bouncing ball/ ultrasonic system
-
Capacity:
-
0.05-5t/h for Cocoa seed circular vibrating sieve shaker
Quick Details
-
Type:
-
Circular
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Zhenying
-
Voltage:
-
220V/380V/440V or follow your need
-
Dimension(L*W*H):
-
580*580*560---2200*2200*1680mm
-
Weight:
-
75 KG
-
Product name:
-
Cocoa seed circular vibrating sieve shaker
-
Material:
-
Stainless Steel 304, base carbon steel
-
Function:
-
Screening\separation\sorting\sieving
-
Keyword:
-
Cocoa seed circular vibrating sieve shaker
-
Layer:
-
1-5 layers
-
Mesh type:
-
Wire mesh/ punching hole
-
Screen mesh:
-
5--625mesh
-
Sieving Diameter:
-
320~1750mm
-
Cleaning system:
-
Cleaning of bouncing ball/ ultrasonic system
-
Capacity:
-
0.05-5t/h for Cocoa seed circular vibrating sieve shaker
Small diameter vibrating screen to clean pollen from lavender
Small diameter vibrating screen to clean pollen from lavender
Dust cover
Cleaning system including bouncing ball and PU ring
Screen frame
Vibrating body with vibrating motor
Description
Small diameter vibrating screen to clean pollen from lavender adopt new type dynamic generator , making three dimension powers more obviously and successfully, making the scale of processed materials enlarged.
Accordingly this makes vibratory screen capable of processing various kinds of materials.
Application
As to the functional feature, it has reached the highest international level.
It has prominent advantages in solving materials sieving problems such as
high
absorption, easy agglomeration, high static, high precision degree, light weight etc.
Features
1.High efficiency, refined design, durable, it can apply to any powders and mucilage
screening.
2.Replace the screen cloth easily, easy operation and cleaning.
3.No mesh plug, no powder flying.
4.Impurity and coarse material discharged automatically and can be continuous
operation.
5.Unique screen frame design, long life screen cloth.
6.Small in size, moving easily.
Parameter
Cocoa seed circular vibrating sieve shakerModel |
Power (kw) |
Screen Effective Diameter (mm) |
Dimension (mm) |
Layers |
|
ZYD-400-1S ZYD-400-2S ZYD-400-3S |
0.18 | 320 |
580*580*560 580*580*660 580*580*760 |
1 2 3 |
|
ZYD-600-1S ZYD-600-2S ZYD-600-3S |
0.25 | 550 |
800*800*680 800*800*780 800*800*880 |
1 2 3 |
|
ZYD-800-1S ZYD-800-2S ZYD-800-3S |
0.55 | 750 |
900*900*780 900*900*930 900*900*1080 |
1 2 3 |
|
ZYD-1000-1S ZYD-1000-2S ZYD-1000-3S |
0.75 | 950 |
1160*1160*880 1160*1160*1030 1160*1160*1180 |
1 2 3 |
|
ZYD-1200-1S ZYD-1200-2S ZYD-1200-3S |
1.1 | 1150 |
1360*1360*980 1360*1360*1160 1360*1360*1360 |
1 2 3 |
|
ZYD-1500-1S ZYD-1500-2S ZYD-1500-3S |
1.5 | 1450 |
1850*1850*1130 1850*1850*1330 1850*1850*1550 |
1 2 3 |
|
ZYD-1800-1S ZYD-1800-2S ZYD-1800-3S |
2.2 | 1750 |
2200*2200*1360 2200*2200*1460 2200*2200*1680 |
1 2 3 |
Production flow:
For our standard small diameter vibrating screen to clean pollen from lavender m odel.
Our products
1.Sieving machine;
2.Conveying machine;
3.Feeding machine;
4.Related equipments and spare parts.
Shipping mark:
Our standard: ZHENYING MACHINE NO.1/1
If you have any special needs please tell us (like "made in China" sprayed on the case).
More than 7 years exporting experience.
