Quick Details
-
Brand Name:
-
TK
-
Feature 1:
-
Low density,Excellent Flexibility,Corrosion resistance,
-
Feature 2:
-
High elasticity,High tensile strength,Durability.
-
Product name:
-
E- Tpu Granules
-
Color:
-
Customized
-
Usage:
-
household goods,bottom load non-inflatable tires etc.
Quick Details
-
color:
-
colorful
-
Shape:
-
Pellet, Pellet
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TK
-
Feature 1:
-
Low density,Excellent Flexibility,Corrosion resistance,
-
Feature 2:
-
High elasticity,High tensile strength,Durability.
-
Product name:
-
E- Tpu Granules
-
Color:
-
Customized
-
Usage:
-
household goods,bottom load non-inflatable tires etc.
Product Description
E-tpu is a new type of foaming TPU.The closed foam structure can be integrated perfectly with TPU's excellent properties which makes ETPU molding soft and elastic.It is not only suitable for the production of the middle and inner bottoms of sports shoes,but also suitable for the fields of repeated impact,sports protection,damping,household goods,bottom load non-inflatable tires etc.
E-TPU, is using supercritical fluid as physical foaming agent and TPU as raw material product a closed cell expanded thermoplastic polyurethane beads. The foam process causes the TPU particles to swell up to 7-10 times original volume, while at the same time greatly reducing their weight. The excellent performance of both the TPU and the foaming material into one, inherited the excellent performance TPU material: high tensile strength, elongation at break, excellent resistance to compression, high elasticity, outstanding resilience and good chemical resistance.
Product Feature
※
Excellent Flexibility,Corrosion resistance,High elasticity,High tensile strength,Durability.
※ Low density, light quality
※ High return elasticity
※ Compression resistance, low compression permanent variable change
※ Low temperature and flexibility
※ Good mechanical performance
※ Green and safe and environmentally friendly, renewable
※ The E-TPU produced by our company is a polyether type, which has the advantages of hydrolysis, aging resistance, and longer service life.
E-TPU has the above excellent performance to make it widely used in the fields of leisure sneakers, sports equipment, fitness equipment, protective gear, plastic runway, car, buffer accessories and other fields.
Product Properties
|
Property
|
Test method
|
Unit
|
Value
|
|
|
|
|
|
|
No.35
|
No.15
|
|
|
Density
|
ISO845
|
g/cm3
|
0.18
|
0.24
|
|
|
Hardness
|
ASTM D2240
|
Shore C
|
35~43
|
30~35
|
|
|
Tensile strength
|
ISO1798
|
kpa
|
1100
|
1200
|
|
|
Elongation at break
|
ISO1798
|
%
|
130
|
150
|
|
|
Compression set（23℃，22h，50%）
|
ISO1856（Method C）
|
%
|
<6
|
<5
|
|
|
Rebound
|
DIN 53512
|
%
|
60
|
65
|
|
|
Thermal traction
|
70℃/40min
|
%
|
0.8
|
0.5
|
|
|
UV test
|
QUV12hr
|
—
|
≥4
|
≥4
|
|
|
Molding pressure
|
—
|
bar
|
3.0~3.6
|
1.5~1.8
|
|
Specification
|
item
|
value
|
|
color
|
colorful
|
|
Shape
|
Pellet
|
|
Application
|
sports equipment, the middle and inner bottom of sports shoes,, household goods,bottom load non-inflatable tires e
|
|
Grade
|
foaming grade
|
|
Feature
|
aging resistance, transparent grade
|
|
Place of Origin
|
China
|
|
|
Zhejiang
|
|
Brand Name
|
TK
|
|
Feature 1
|
Low density,Excellent Flexibility,Corrosion resistance,
|
|
Feature 2
|
High elasticity,High tensile strength,Durability.
|
|
Feature
|
Low density, light quality,Low temperature and flexibility
|
|
Product name
|
E- Tpu Granules
|
|
Color
|
Customized
|
|
Application
|
the production of the middle and inner bottoms of sports shoes
|
|
Usage
|
household goods,bottom load non-inflatable tires etc.
|
|
Shape
|
Pellet
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
