Quick Details
-
Color:
-
White Optional
-
Total heat leakage rate:
-
≤30W/K
-
Total air leakage rate:
-
≤5m3/h
-
Truck body material:
-
PU foam/XPS Sandwich panel
-
Truck body covering material:
-
Fiber Glass plate/Steel Sheet
-
Truck body panel thickness:
-
60mm-150mm(Max 300mm Customized)
-
Refrigeration unit:
-
Thermo King/carrier/Bing Huang
-
Truck body size:
-
customized
-
Truck application:
-
Optional(Fruits/Vegetable/Meat/Sea Food/Medicine/Ice Cream etc
-
Warranty:
-
12 Months Guarantee
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 3
-
Gross Vehicle Weight:
-
3780
-
Color:
-
White Optional
-
Total heat leakage rate:
-
≤30W/K
-
Total air leakage rate:
-
≤5m3/h
-
Truck body material:
-
PU foam/XPS Sandwich panel
-
Truck body covering material:
-
Fiber Glass plate/Steel Sheet
-
Truck body panel thickness:
-
60mm-150mm(Max 300mm Customized)
-
Refrigeration unit:
-
Thermo King/carrier/Bing Huang
-
Truck body size:
-
customized
-
Truck application:
-
Optional(Fruits/Vegetable/Meat/Sea Food/Medicine/Ice Cream etc
-
Warranty:
-
12 Months Guarantee
- Supply Ability:
- 2000 Set/Sets per Month
- Packaging Details
- Nude packing shipped by RO-RO or Bulk Cargo Ship
- Port
- SHANGHAI
- Lead Time :
- Shipped in 15 days after payment
| EQ6031 | |||
Box Structure and Material
The inner and outer covering is high quality fiber glass panel with thickness 2.2mm-3.5mm.
The middle insulated panel is made by PU foam.The complete panel is called FRP sandwich panel.
The panels are made by Positive Pressure Bonding technology and every single panel is separated and vacuum to stop the heat conduction.
All of the insulated PU foam panels are covered by fiber glass panels,which is called sandwich panel.
Most of the high-end refrigerator trucks bodies are using this kind of sandwich panels.
Every single panel is made by high tempereture,high pressure and vacuumized in one time.
Assembly Method of Box Panels
Plate bond structure with the cam lock/snap fastener on the edge of the panel.
And using the big board glue to splice together what makes the high leakproofness and high strength.
There is no possible for the heat conduction by either metal or air.
All of these guaranteed the heat insulation greatly.
The Box Strength
The inner and outer fiber glass plate of the sandwich panel would be lap jointed every 50cm.
Which is formed many independent,small and completed boxes to enhance the box strength.
The Box Assembled parts Material
The inner and outer covering is high quality fiber glass panel with thickness 2.2mm-3.5mm.
The middle insulated panel is made by PU foam.The complete panel is called FRP sandwich panel.
Generally,the thickness can be customerized from 60mm-150mm.The thickest could be 300mm.
For the lockset,it is used by high quality stainless stell which makes it sturdy and durable.
High Quality Accessories
The truck body is edged by aluminium alloy and assembled with stainless steel frame,hinges and stainless locksets.
The LED light is available in the box.
