Quick Details
-
Table Size:
-
910*500*52mm
-
Overall Dimensions:
-
910*500*52mm
-
Weight:
-
19200 kg
-
Engine:
-
KDI2504TCR
-
Control Voltage:
-
12V DC
-
Drive Mode:
-
4WD
-
Steering Mode:
-
Front-wheel/Rear-wheel/Crab
-
Work Height:
-
22.75m
-
Platform Height:
-
20.75m
-
After-sales Service Provided:
-
Online support
-
Certification:
-
CE
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
ZOOMLION
-
Table Size:
-
910*500*52mm
-
Overall Dimensions:
-
910*500*52mm
-
Weight:
-
19200 kg
-
Engine:
-
KDI2504TCR
-
Control Voltage:
-
12V DC
-
Drive Mode:
-
4WD
-
Steering Mode:
-
Front-wheel/Rear-wheel/Crab
-
Work Height:
-
22.75m
-
Platform Height:
-
20.75m
-
After-sales Service Provided:
-
Online support
-
Certification:
-
CE
Dingli scissor lift tires
Zoomlion telescopic boom lifts are engineered to enhance working efficiency and offer greater horizontal outreach than any other type of aerial work platform. These units feature stable extension and great gradeability in rough terrain, offering a dual lift capacity of 300 kg unrestricted and 454 kg restricted. It is ideal for outdoor construction and industrial applications.
ZT20J features modularized design, light weight, commonalization and intelligence and provides a large lift capacity and high reliability. Four-wheel drive and oscillating axle system greatly improves off-road performance. With a gradeability of 45%, these machines are perfect for work in construction and industrial applications with limited access. Lubrication-free boom system minimizes equipment holding costs. Swing-out engine tray makes regular maintenance more convenient. Remote Monitoring and Rental Management System realizes on-board diagnosis, POST (power on self test), and maintenance alert for efficient fleet management.
PARAMETERS:
| Main Specs of Telescopic Boom Lifts | |||
| Comply with CE/ANSI/GB Standard | |||
| Model | ZT34J | ZT26J | ZT20J |
| Size | |||
| Work Height | 36m | 28.20m | 22.75m |
| Platform Height | 34m | 26.20m | 20.75m |
| Horizontal Outreach | 23.50m | 22.71m | 16.80m |
| A - Stowed Length | 13.50m | 12.5m | 10.36m |
| B - Stowed Width | 2.49m | 2.49m | 2.49m |
| C - Stowed Height | 3m | 2.80m | 2.78m |
| D - Platform Length | 2.44m | 2.44m | 2.44m |
| E - Platform Width | 0.91m | 0.91m | 0.91m |
| F - Wheelbase | 3.80m | 3.05m | 2.52m |
| Wheelbase | 2.05/3.41m | 2.11m | 2.13m |
| G - Ground Clearance | 0.41m | 0.40m | 0.42m |
| Performance | |||
| Platform Capacity (Unrestricted/Restricted) | 300/454kg | 300kg/454kg | 300kg/454kg |
| Drive Speed (Working) | 5.5km/h | 5.5km/h | 6.0km/h |
| Gradeability | 45% (24°) | 45% (24°) | 45% (24°) |
| Turning Radius (Inside) | 2.80m | 3.66m | 2.4m |
| Turning Radius (Outside) | 5.70m | 6.86m | 5.4m |
| Turntable Swing | 360°continuous | 360°continuous | 360°continuous |
| Platform Rotation | ±90° | ±90° | ±90° |
| Tail Swing | 1.88m | 1.60m | 1.45m |
| Jib (Range of Articulation) | 130°(-55°~75°) | 130°(-55°~75°) | 135°(-60°~75°) |
| Max. Working Slope | 3° | 3° | 3° |
| Max. Wind Speed | 12.5m/s | 12.5m/s | 12.5m/s |
| Power | |||
| Engine | Kohler KDI2504TCR | Deutz TD2.9 L4/ QSF2.8 | Deutz D447 L4/ 404D-22T |
| Fuel Tank Capacity | 200L | 150L | 130L |
| Control Voltage | 12V DC | 12V DC | 12V DC |
| Hydraulic Tank Capacity | 250L | 150L | 150L |
| Drive Mode | 4WD | 4WD | 4WD |
| Steering Mode | Front-wheel/Rear-wheel/Crab | Front-wheel | Front-wheel |
| Tire | |||
| Type |
IN445/50D710
Foam-filled Tires |
15-625 Foam-filled Tires | 355/55D-625 Foam-filled Tires |
| Weight | |||
| Gross | 19200kg | 18900kg | 12200kg |
| Highlights | |||
| Better work envelop performance, 10% larger than competitor | |||
| Zoomlion AWM Remote Monitoring and Rental Management System | |||
| Smart telematic control interface with self-diagnostic monitoring capability | |||
| Platform dual capacity design, up to 300/454 kg | |||
| Smooth & stable boom extension technique controls the minimum stable extending speed at 0.015 m/s | |||
| Features | |||
| Standard Features | |||
| All motion alarm | Horn | ||
| Self-closing entry gate | Proportional control | ||
| GPS positioning and tracking system | Flashing amber beacon | ||
| Auto-leveling system | Remote monitoring and rental management system | ||
| Over tilt protection system | Emergency stop button | ||
| On-board diagnostic system | Emergency descent system | ||
| 4.3' LED display | Oscillating axle | ||
| Swing-out engine tray | Load sensing system | ||
| Accessories & Options | |||
| Platform work lights | |||
| Anti-collision device | |||
| AC power to platform | |||
