Quick Details
-
Range of Spindle Speed(r.p.m):
-
20 - 1800 r.p.m
-
Width of bed (mm):
-
350
-
Max. Turned Length (mm):
-
2000 mm
-
Spindle Motor Power(kW):
-
7.5
-
Year:
-
2022
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SIECC
-
Voltage:
-
Customer's Requirement
-
Dimension(L*W*H):
-
2950X1150X1750MM
-
Weight (KG):
-
1700 KG
-
Marketing Type:
-
Hot Product 2022
-
Certification:
-
CE/ISO/SGS/GOST
Quick Details
-
Max. Length of Workpiece (mm):
-
4000
-
Machining Capacity:
-
Medium Duty
-
Spindle Bore(mm):
-
82
-
Range of Spindle Speed(r.p.m):
-
20 - 1800 r.p.m
-
Width of bed (mm):
-
350
-
Max. Turned Length (mm):
-
2000 mm
-
Spindle Motor Power(kW):
-
7.5
-
Year:
-
2022
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SIECC
-
Voltage:
-
Customer's Requirement
-
Dimension(L*W*H):
-
2950X1150X1750MM
-
Weight (KG):
-
1700 KG
-
Marketing Type:
-
Hot Product 2022
-
Certification:
-
CE/ISO/SGS/GOST
Product Description
| Model | C6236H | C6240H | C6250H | C6260H | |
| CH6236F | CH6240F | CH6250F | CH6260F | ||
| CAPACITY | Max.swing over bed | 360mm | 400mm | 500mm | 600mm |
| Max.swing over cross slide | 190mm | 230mm | 330mm | 330mm | |
| Max.swing over gap | 520mm | 560mm | 660mm | 760mm | |
| Effective length of gap | 200mm | ||||
| Center Distance | 750\1000\1500\2000mm | ||||
| Bed Width | 360mm | ||||
| HEADSTOCK | Spindle hole | 52mm | |||
| Spindle nose | ISO-C6 | ||||
| Spindle taper | MT6 | ||||
| Spindle speed(Number) | (9steps)40-1400rpm | ||||
| FEEDS | Longitudinal feeds range | 0.0832-4.66mm/r | |||
| Cross feeds range | 0.048-2.69mm/r | ||||
| Metric threads range | 19kinds 0.25-14mm | ||||
| Inch threads range | 49kinds 2-40inch | ||||
| Moudle threads range | 11kinds 0.5-3.5mπ | ||||
| CARRIAGE | Max.travel of top slide | 95mm | |||
| Max.travel of cross slide | 180mm | 200mm | 250mm | 250mm | |
| Max.size of toolshank | 20*20mm 2 | ||||
| TAILSTOCK | Dia.of tailstock sleeve | 65mm | |||
| Taper of tailstock sleeve | MT4 | ||||
| Max.travel of tailstock | 140mm | ||||
| MOTOR | Main drive motor | 4KW | 5.5KW | 7.5KW | |
| Coolant pump motor | 125W | ||||
|
PACKING
L*W*H |
Center Distance(750mm) | 225*115*175cm | |||
| Center Distance(1000mm) | 245*115*175cm | ||||
| Center Distance(1500mm) | 295*115*175cm | ||||
| Center Distance(2000mm) | 345*115*175cm | ||||
| N.W/G.W | Center Distance(750mm) | 1350/1750kg | 1400/1800kg | 1500/1900kg | 1600/2000kg |
| Center Distance(1000mm) | 1450/1850kg | 1500/1900kg | 1600/2000kg | 1700/2100kg | |
| Center Distance(1500mm) | 1600/2000kg | 1650/2050kg | 1750/2150kg | 1900/2300kg | |
| Center Distance(2000mm) | 1750/2150kg | 1800/2200kg | 1900/2300kg | 2050/2450kg | |
