Diving breathing application
: Diving clubs, diving enthusiasts, marine breeding, marine rescue, shipboard equipment, underground operations, fishery fishing, aquaculture, sunken object salvage, underwater engineering, water parks, shipbuilding and other industries, providing divers with high purification, clean and tasteless , Safe and reliable compressed breathing air. In an environment that cannot meet the requirements of the human body for normal breathing, the air is filled into a high-pressure gas cylinder for human breathing.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
HBBC-100
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
70*38*42
-
Weight:
-
46kg
-
Working Pressure:
-
300bar, 30Mpa
-
Air capacity:
-
100L/min
-
Marketing Type:
-
Hot Product 2022
-
Model:
-
HBBC-100
-
Product name:
-
Breathing Air Compressor
-
Pressure:
-
300bar/30Mpa
-
Capacity:
-
100L/min
-
Cooling:
-
air cooling
-
Control method:
-
Manual shutdown
-
Compression Stage:
-
Three
-
Usage:
-
Breathing or fire fighting
Quick Details
-
Applicable Industries:
-
Driving, fire fighting
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HUAYAN
-
Model Number:
-
HBBC-100
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
70*38*42
-
Weight:
-
46kg
-
Working Pressure:
-
300bar, 30Mpa
-
Air capacity:
-
100L/min
-
Marketing Type:
-
Hot Product 2022
-
Model:
-
HBBC-100
-
Product name:
-
Breathing Air Compressor
-
Pressure:
-
300bar/30Mpa
-
Capacity:
-
100L/min
-
Cooling:
-
air cooling
-
Control method:
-
Manual shutdown
-
Compression Stage:
-
Three
-
Usage:
-
Breathing or fire fighting
Product Description
Model：HBBC-100/EM/ET/SH
Work pressure：
30Mpa Mpa(300bar)
Displacement (Inhalation state)：
100L/min L/min
Type：W-type layout-three-cylinder three-stage reciprocating piston compression
Drive：Electric 220V/50Hz/2.2kw or 380V/50Hz/3kw or gasoline engine drive
Lubrication method：Splash lubrication
Cooling method：Air-cooled
Control method：Manual shutdown
Clean air：1 air filtration、1 oil-water separation、1 air purification
Safety devices：Interval installation valve、Install the protective cover for the transmission part
Package dimensions（Length×width×height）： 70×38×42 cm
Weight：46kg
Inflation speed：
6 liter bottle 30Mpa about 22 minutes
Certified product：
CE certification, MA test report
Packing List： Manual, safety inspection report certificate, 1 set of inflation hose and joint, 1 bottle of standard lubricant.
Working Principle
This product is mass-produced after design changes and optimizations in accordance. The final piston adopts a special process, the piston ring adopts process, and all casting products are cast in a large-scale outsourcing factory. The product has been on the market for many years and has won users’ approval. Unanimously praised.
This product adopts three-cylinder three-stage compression, splash lubrication, last-stage safety valve and filter system
. HBBC-100 can provide safe compressed air for any industry that requires high-pressure pure air source, and provide safe compressed air that meets the requirements of human breathing. This product is designed, produced and tested and accepted in accordance with the requirements of GB/T 12929-2008 "Marine High Pressure Piston Air Compressor"; the air quality complies with the EN12021 international breathing compressor breathing standard; HBBC-100 is a kind of air compression equipment, it will be free 1 kg (
1bar/0.1Mpa
) of the air in the state is compressed
to
a high pressure gas with a gauge pressure of 300 kg (
300bar/30Mpa
). The oil and impurities in the high-pressure air can filter the inhaled air containing fine particles (PM2.5) to a safety value of
less than 10 micrograms
, which meets the standards set by the World Health Organization, making the exhaust gas clean and tasteless. The personnel provide highly purified, clean, odorless, safe and reliable compressed breathing air.
Factory Show
Main Application
Driving Cylinder Filling
Fire Gas Cylinder Filling
Fire breathing application
: Equipped in the gas supply stations of the fire brigade or various fire-fighting vehicles, it provides emergency gas supply at the scene of a fire or in the rescue and relief process, so that the majority of firefighters will be exposed to various environments such as dense smoke, poisonous gas, steam or oxygen deficiency. Breathing high-purity, clean, odorless, safe and reliable compressed air ensures that fire extinguishers can safely and effectively carry out fire fighting, rescue, disaster relief, and rescue.
