Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BADA
-
Model Number:
-
BDDR 2001
-
Application:
-
water supply, gas supply, repairing
-
Material::
-
PE80 or PE100
-
longevity:
-
more than 50 years
-
Color:
-
Black electrofusion fittings
-
Packing:
-
Carton
-
Feature:
-
Thicker wall
-
Keyword:
-
elbow poly pipe
-
Delivery Time:
-
5-10 Days
Quick Details
-
Technics:
-
injection
-
Shape:
-
All size
-
Head Code:
-
Square
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BADA
-
Model Number:
-
BDDR 2001
-
Application:
-
water supply, gas supply, repairing
-
Material::
-
PE80 or PE100
-
longevity:
-
more than 50 years
-
Color:
-
Black electrofusion fittings
-
Packing:
-
Carton
-
Feature:
-
Thicker wall
-
Keyword:
-
elbow poly pipe
-
Delivery Time:
-
5-10 Days
Details Images
High quality pn12.5 butt fusion cross elbow tee hdpe pipe fitting 4 way pipe fittings
1. Unique Design: Choose the maximum high pressure design, guarantee system security.
Accurate marking line of insertion depth and angle, saving time and construction cost
2. Superior Materials: We choose imported specialized resin suitable for pipe to produce PE fittings.
3. Lean Production: With sophisticated injection mold, automatic production, the dimension of pipe fitting is precise.
4. TCT : Guarantee the stability of product size.
5. Long Life: More than 50 years under normal conditions.
Accurate marking line of insertion depth and angle, saving time and construction cost
2. Superior Materials: We choose imported specialized resin suitable for pipe to produce PE fittings.
3. Lean Production: With sophisticated injection mold, automatic production, the dimension of pipe fitting is precise.
4. TCT : Guarantee the stability of product size.
5. Long Life: More than 50 years under normal conditions.
|
Basic performance of raw materials for pipe fittings
|
|
|
|
|
||||
|
Paramenter
|
|
Units
|
Requirement
|
Test Value
|
||||
|
Density
|
|
(kg/m3)
|
≥930
|
23°C
|
||||
|
Melt flow rate
|
|
g/10min
|
0.2-1.4
|
190°C,5kg
|
||||
|
Thermal slaility(OIT)
|
|
min
|
>20
|
200°C
|
||||
|
Volatilematter content
|
|
mg/kg
|
≤ 350
|
|
||||
|
Moisture content
|
|
mg/kg
|
≤ 300
|
ASTM D 4019:1994a
|
||||
|
Carbon black content
|
|
%
|
2.0-2.5
|
|
||||
|
Carbon black dispersion
|
|
grade
|
≤ 3
|
|
||||
|
Gas proof components
|
|
h
|
≥20
|
80°C,2MPa Hoop stress
|
||||
|
En>5mm Resitance to slow crack growth
|
|
h
|
165
|
80°C,0.8MPa Test Presssure 80°C,0.92MPa Test Presssure
|
||||
Using the process
