Quick Details
-
Brand Name:
-
TIANNIU
-
Model Number:
-
AS45TSS45
-
Place of Origin:
-
Jiangsu, China
-
Product number:
-
AS45 TSS45
-
Material:
-
GCr15
-
Application:
-
machinery
-
Package:
-
carton box
-
OEM:
-
accept
-
Delivery Time:
-
10-15 days
-
Torque (Nm):
-
347
-
Inner Race Max. Overrunning (rpm):
-
1300
-
Thickness (mm):
-
19
-
Weight (Kg):
-
0.495
Quick Details
-
Type:
-
SPRAG
-
Precision Rating:
-
P0
-
Seals Type:
-
Sealed
-
Brand Name:
-
TIANNIU
-
Model Number:
-
AS45TSS45
-
Place of Origin:
-
Jiangsu, China
-
Product number:
-
AS45 TSS45
-
Material:
-
GCr15
-
Application:
-
machinery
-
Package:
-
carton box
-
OEM:
-
accept
-
Delivery Time:
-
10-15 days
-
Torque (Nm):
-
347
-
Inner Race Max. Overrunning (rpm):
-
1300
-
Thickness (mm):
-
19
-
Weight (Kg):
-
0.495
Technical Datas
| Item | TSS Series |
| Material | GCr15 |
| Bore dia. | 8-60 mm |
| Outer dia. | 24-110 mm |
| Width | 8-22 mm |
| Torque capacity | 6.7-649 N.m |
| Weight | 0.014-0.95 kg |
| Package | Carton box, wooden box or as your requirements |
.
Dimensions and Capacities
|
MODEL |
Torque capacity (N-m) |
Max Overrunning Clutch (r/min |
Drag Torque (N-m) |
Bore size (H7) |
Keyway |
A |
B |
C |
D |
E |
F |
Weight (g) |
|
|
Inner race |
Outer race |
||||||||||||
|
TSS8 |
6.7 |
6000 |
3000 |
0.005 |
8 |
2x1.0 |
8 |
24 |
22.2 |
11.4 |
0.6 |
0.6 |
14 |
|
TSS10 |
12 |
4500 |
2300 |
0.007 |
10 |
3x1.4 |
9 |
30 |
27 |
15.6 |
0.6 |
0.6 |
27 |
|
TSS12 |
17 |
4000 |
2000 |
0.009 |
12 |
4x1.8 |
10 |
32 |
29.5 |
18 |
0.6 |
0.6 |
31 |
|
TSS15 |
22 |
3500 |
1800 |
0.01 |
15 |
5x1.2 |
11 |
35 |
32 |
20.6 |
0.6 |
0.6 |
39 |
|
TSS20 |
41 |
2600 |
1300 |
0.01 |
20 |
6x1.6 |
14 |
47 |
40 |
26.7 |
0.8 |
0.8 |
115 |
|
TSS25 |
56 |
2200 |
1100 |
0.02 |
25 |
8x2.0 |
15 |
52 |
45 |
32 |
0.8 |
0.8 |
140 |
|
TSS30 |
105 |
1800 |
900 |
0.03 |
30 |
8x2.0 |
16 |
62 |
55 |
40 |
0.8 |
1.0 |
215 |
|
TSS35 |
136 |
1600 |
800 |
0.03 |
35 |
10x2.4 |
17 |
72 |
63 |
45 |
0.8 |
1.0 |
300 |
|
TSS40 |
296 |
1400 |
700 |
0.18 |
40 |
12x2.2 |
18 |
80 |
72 |
50 |
0.8 |
1.0 |
425 |
|
TSS45 |
347 |
1300 |
650 |
0.21 |
45 |
14x2.1 |
19 |
85 |
75.5 |
57 |
1.2 |
1.0 |
495 |
|
TSS50 |
403 |
1200 |
600 |
0.22 |
50 |
14x2.1 |
20 |
90 |
82 |
62 |
1.2 |
1.0 |
545 |
|
TSS60 |
649 |
910 |
460 |
0.33 |
60 |
18x2.3 |
22 |
110 |
100 |
80 |
1.2 |
1.5 |
950 |
Notes:
1. T max = 2 × T KN
2. Inner race overruns
3. Outer race overruns
Keyway to DIN 6885.1
Mounting
Installation and Usage
1. The TSS Series Cam Clutch is designed for press fit installation.
Correct interference dimensions must be maintained to obtain maximum clutch performance.
The internal diameter of the housing should meet the H7 tolerance. Refer to item 8 in the installation
and usage of BB Series Cam Clutch for information on the installation method.
2. Make sure the housing has enough strength to withstand the pressure required for the press fitting
installation of the clutch.
3. When installing the clutch, mount it with a type 62 bearing to avoid radial force, since this clutch does
not have any bearing support.
4. Confirm the direction of rotation before installation.
5. The recommended shaft tolerance is h7, and the key profile should be in accordance with the following
standard.
6. Suitable surface pressure of the key should be selected according to your company design standards.
Lubrication
1. Oil lubrication is recommended.
2. Do not use greases or lubricants with EP additives.
