Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
JIAYOU
-
Model Number:
-
BVR Electrical wire
-
Rated voltage:
-
300/500V
-
Product name:
-
electric wire acbles
-
Insulation:
-
PVC Insulation Cable
-
Standard:
-
JB/T 8734.5-2016
-
MOQ:
-
1000 meters+
-
Material:
-
99.995% Pure Copper
-
Length:
-
50M;100M
-
Usage:
-
Building Wire Home Appliances
-
Color:
-
Customer's Requirement
-
Size:
-
2.5mm;4mm
Quick Details
-
Application:
-
house wiring/Building construction
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Flexible
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
JIAYOU
-
Model Number:
-
BVR Electrical wire
-
Rated voltage:
-
300/500V
-
Product name:
-
electric wire acbles
-
Insulation:
-
PVC Insulation Cable
-
Standard:
-
JB/T 8734.5-2016
-
MOQ:
-
1000 meters+
-
Material:
-
99.995% Pure Copper
-
Length:
-
50M;100M
-
Usage:
-
Building Wire Home Appliances
-
Color:
-
Customer's Requirement
-
Size:
-
2.5mm;4mm
Products Description
|
Product Name
|
Multiple strandard copper conductor PVC insulated wire
|
|
|
Material
|
Copper+PVC
|
|
|
Colour
|
red/yellow/blue/green/yellow green
|
|
|
Adaptable Voltage (v)
|
450/750
|
|
|
Specification
|
2.5㎟--70㎟
|
|
|
MOQ
|
100m
|
|
|
|
||
Copper conductor BVR cables and wires are a common type of power cable, primarily composed of multiple strands of copper wire,
which provide excellent electrical conductivity and mechanical strength. The insulation material for BVR cables is usually
polyvinyl chloride (PVC), known for its excellent abrasion resistance, acid and alkali resistance, and oil resistance. Below is a detailed introduction to the functions, uses, and application scenarios of BVR cables:
polyvinyl chloride (PVC), known for its excellent abrasion resistance, acid and alkali resistance, and oil resistance. Below is a detailed introduction to the functions, uses, and application scenarios of BVR cables:
Functions
1. Electrical Conductivity: BVR cables use multi-strand copper wire as the conductor, offering excellent conductivity
1. Electrical Conductivity: BVR cables use multi-strand copper wire as the conductor, offering excellent conductivity
suitable for various power transmission and distribution systems.
2. Flexibility: The multi-strand copper wire structure makes BVR cables more flexible compared to single-core cables,
facilitating installation and wiring, especially in scenarios requiring frequent bending and movement.
3. Insulation Protection: The PVC insulation layer provides excellent electrical insulation performance, ensuring the safety
2. Flexibility: The multi-strand copper wire structure makes BVR cables more flexible compared to single-core cables,
facilitating installation and wiring, especially in scenarios requiring frequent bending and movement.
3. Insulation Protection: The PVC insulation layer provides excellent electrical insulation performance, ensuring the safety
and stability of the cables during use.
Useage
BVR cables are mainly used for low-voltage power transmission and wiring, and are widely applied in the following fields:
1. Home Decoration: Used for indoor wiring, such as power lines for lighting and appliances.
2. Industrial Equipment: Provides power connections for various industrial equipment, such as machine tools, electric
BVR cables are mainly used for low-voltage power transmission and wiring, and are widely applied in the following fields:
1. Home Decoration: Used for indoor wiring, such as power lines for lighting and appliances.
2. Industrial Equipment: Provides power connections for various industrial equipment, such as machine tools, electric
motors, and control cabinets.
3. Construction Projects: Used in the power systems of buildings, including lighting systems and socket connections.
3. Construction Projects: Used in the power systems of buildings, including lighting systems and socket connections.
4. Product use A)The product is suitable for fixed wiring of power plant and electrical equipment with rated AC voltage up
to and including 450/750V.
B)The permissible continuous operating temperature of cables: BV-105 is not more than 150C, others are not more than
70℃
5.Manufacture length: A)Coil length of cable (wire) is 100m, filled reel length not less than 100m. Short length not
less than 10m can be delivered.
B)Any length can be delivered against agreement. Length error not more than +0.5% 3.Product structure, size and
reference data Construction and Dimension（ BVR） Rated Voltage:450/750V
Application Scenarios
1. Indoor Wiring: The flexibility and ease of handling of BVR cables make them ideal for indoor power wiring, whether in
residences, offices, or commercial buildings, providing reliable power supply.
2. Electrical Appliance Connections: In appliances that require frequent movement and installation (e.g., household
1. Indoor Wiring: The flexibility and ease of handling of BVR cables make them ideal for indoor power wiring, whether in
residences, offices, or commercial buildings, providing reliable power supply.
2. Electrical Appliance Connections: In appliances that require frequent movement and installation (e.g., household
appliances,mobile devices), BVR cables are widely used due to their good flexibility and durability.
3. Control Systems: In automated control systems, BVR cables are used to connect various control devices and sensors,
3. Control Systems: In automated control systems, BVR cables are used to connect various control devices and sensors,
ensuring stable and reliable signal transmission.
4. Industrial Installations: In industrial environments, BVR cables are often used for power distribution and control
4. Industrial Installations: In industrial environments, BVR cables are often used for power distribution and control
systems, capable of withstanding harsh working conditions such as high temperatures, humidity, and corrosive
environments.
Due to their excellent conductivity, flexibility, and durability, copper conductor BVR cables and wires are extensively used in a variety of applications, including residential, industrial, and commercial settings.
|
Nomnialcross-sectionakarea mm²
|
Construction of conductor No.ofwires/dia mm
|
Insulation thickness mm
|
Outer diameter mm
|
Max.d.c, resistance at 20℃ Ω /km
|
Min.insulation resistance at70℃ MΩ-km
|
Current ratingin air at 25℃ A
|
Approx.cable weight kg/km
|
|
2.5
|
19/0.41
|
0.8
|
4.2
|
7.41
|
0.011
|
34
|
33
|
|
4
|
19/0.52
|
0.8
|
4.8
|
4.61
|
0.009
|
45
|
49
|
|
6
|
19/0.64
|
0.8
|
5.6
|
3.08
|
0.0084
|
58
|
71
|
|
10
|
49/0.52
|
1
|
7.6
|
1.83
|
0.0072
|
79
|
125.5
|
|
16
|
49/0.64
|
1
|
8.8
|
1.15
|
0.0062
|
111
|
181
|
|
25
|
98/0.58
|
1.2
|
11
|
0.727
|
0.0058
|
146
|
302
|
|
35
|
133/0.58
|
1.2
|
12.5
|
0.524
|
0.0052
|
180
|
395
|
|
50
|
133/0.68
|
1.4
|
14.5
|
0.387
|
0.0051
|
225
|
544
|
|
70
|
189/0.68
|
1.4
|
16.5
|
0.268
|
0.0045
|
280
|
723
|
