Quick Details
-
Operating System:
-
Android 7.1.2
-
Type:
-
Tablet PC
-
Processor Main Frequency:
-
1.1GHz
-
Weight:
-
810g
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
3Rtablet
-
Model Number:
-
VT-7
-
Camera:
-
2.0M+8.0M
-
Brightness:
-
800cd/m2
-
Power:
-
DC8-36V
-
Battery:
-
5000mAh/3.7V Li-ion
-
Touch Panel:
-
Capacitive Multi-touch
-
Build-in Module:
-
GPS,WiFiL,TE 4G,NFC
-
Interface:
-
RS232USB/GPIO/ACC/CAN
-
GPU:
-
Adreno 304
-
Reliability:
-
MIL-STD-810G, IP67 Water & Dust-Proof, 1.5m drop resistance
Quick Details
-
Screen Size:
-
7"
-
Memory Capacity:
-
2 GB LPDDR3
-
Display resolution:
-
1280x800
-
Operating System:
-
Android 7.1.2
-
Type:
-
Tablet PC
-
Processor Main Frequency:
-
1.1GHz
-
Weight:
-
810g
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
3Rtablet
-
Model Number:
-
VT-7
-
Camera:
-
2.0M+8.0M
-
Brightness:
-
800cd/m2
-
Power:
-
DC8-36V
-
Battery:
-
5000mAh/3.7V Li-ion
-
Touch Panel:
-
Capacitive Multi-touch
-
Build-in Module:
-
GPS,WiFiL,TE 4G,NFC
-
Interface:
-
RS232USB/GPIO/ACC/CAN
-
GPU:
-
Adreno 304
-
Reliability:
-
MIL-STD-810G, IP67 Water & Dust-Proof, 1.5m drop resistance
Product Description
Specification
|
CPU
|
Qualcomm Quad-core processor, Cortex-A7,1.1GHz
|
|
Operating System
|
Android 7.1.2
|
|
RAM
|
2GB
|
|
ROM
|
16 GB eMMC (support 64 GB TF card for expansion
|
|
LCD
|
7" HD (1280x800), sunlinght readable 800 nits
|
|
Touch Screen
|
Multi-touch capacitive touch screen
|
|
Camera (optional)
|
Front 2.0 MP + Rear 8.0 MP with LED light
|
|
BT
|
BT4.2 LE
|
|
WLAN
|
IEEE 802.11a/b/g/n; 2.4GHz/5GHz
|
|
Mobile Broadband
|
LTE,HSPA+,UMTS,EDGE,GPRS,GSM(Data and Voice)
|
|
GNSS
|
GPS/GLONASS
|
|
NFC (optional)
|
Read/Write Mode:ISO/IEC 14443 A&B up to 848 kbit/s, FeliCa at 212&424 kbit/s
|
|
|
MIFARE 1K, 4K, NFC Forum type 1, 2, 3, 4,5 tags, ISO/IEC 15693All peer-to-peer modes
|
|
|
Card Emulation Mode (from host): NFC Forum T4T (ISO/IEC 14443 A&B） at 106 kbit/s
|
|
Sound
|
Built-in speaker 2Wx1 85dB
|
|
|
Internal microphones x 1
|
|
Interfaces
|
Type-C, USB 2.0 (For charging and data transfer: support OTG)
|
|
|
Docking connector x 1 (POGO-PIN x 24)
|
|
|
Headset jack x 1
|
|
Sensors
|
Acceleration sensors, ambient light sensor
|
|
Power Supply
|
DC Input Voltage: DC 8-36V (ISO 7637-2 compliant)
|
|
|
Type-C charge: 5V 2A
|
|
|
Battery: 3.7V, 5000mAh Li-ion (Replaceable)
|
|
|
Battery operating time: 5h (Typical)
|
|
Power Consumption
|
Normal Mode: 5W
|
|
Physical Dimensions (WxHxD)
|
200Wx130Hx28.5D; 207.4Wx137.4Hx30.1Dmm(With cornor protection)
|
|
Weight
|
810g
|
|
Reliability
|
Gravity drop resistance test : 150cm
|
|
|
Vibration test: MIL-STD 810G
|
|
|
Dust resistance test: IP6x
|
|
|
Water resistance test: IPx7
|
|
|
Operating temperature: -10°C~65°C
0°C~55°C （charging)
|
|
|
Storage temperature: -20°C~70°C
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
