- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
KEYPLUS
-
Model Number:
-
HT-R6
-
Material:
-
Zinc Alloy
-
Color:
-
Black/Silver
-
Warning Power:
-
<4.8v
-
Unlock Ways:
-
Card/Mechenical keys
-
Registered Cards Number:
-
No Limitation
-
Reading Time:
-
<1s
-
Reading Range:
-
<3cm
-
Card Sensor Frequency:
-
13.56MHz
-
Working Voltage:
-
4PCS 1.5V AA Batteries
-
Door Thickness:
-
35-55 mm(Available for Others)
Quick Details
-
Door Type:
-
Wood door, Steel door, Stainless Steel door, Aluminum door, Brass door
-
Network:
-
TCP
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KEYPLUS
-
Model Number:
-
HT-R6
-
Material:
-
Zinc Alloy
-
Color:
-
Black/Silver
-
Warning Power:
-
<4.8v
-
Unlock Ways:
-
Card/Mechenical keys
-
Registered Cards Number:
-
No Limitation
-
Reading Time:
-
<1s
-
Reading Range:
-
<3cm
-
Card Sensor Frequency:
-
13.56MHz
-
Working Voltage:
-
4PCS 1.5V AA Batteries
-
Door Thickness:
-
35-55 mm(Available for Others)
Product Introduction
Description
HT-R6 is our latest "only-handle" design smart hotel lock, with a minimalist small body design, making a very small occupation on your door. Clear dual color LED light (green/red) indicates the lock authorization, with card reading zone hidden inside. Made of Zinc Alloy material, with high precision CNC machining process technology; smooth texture surface, achieved by advanced treatment. Strong EU standard stainless steel lock body 9370, compatible with ANSI mortise locks, meeting fire-proof rate and anti-theft requirements, complying with CE/FCC standard, perfect for hotels, campus and apartment use.
Features
1. Lock surface made by advanced IML technology, with minimalist modern design
2. USB emergency power supply to enable lower battery
3. ANSI standard mortise lock
4. Declaration of conformity CE
5. FCC/IC conformity
Functions
1. Opening with smart card
2. USB emergency power supply to enable lower battery
3. ANSI standard mortise lock
4. Declaration of conformity CE
5. FCC/IC conformity
Functions
2. Kaba key cylinder design
3. Alarming function for door not closed well
4. Emergency function
5. No need for Web connection
6. Three latch lock body safety design
7. USB Power for emergency situation
8. Management system
9. Opening records for checking
Technical Specifications
|
Product Name
|
Hotel Locks
|
|
Brand
|
KEYPLUS
|
|
Model Number
|
HT-R6
|
|
Ways to Unlock
|
Mifare Card/Mechenical keys
|
|
Size
|
H64mm*W64mm
Handle:133mm*51 |
|
Material
|
Zinc Alloy
|
|
Color
|
Black/ Gray/Gold
|
|
Registered Cards Number
|
No limitation
|
|
Reading Time
|
<1s
|
|
Reading Range
|
<3cm
|
|
Opening Records
|
1000
|
|
M1 Sensor Frequency
|
13. 56MHZ
|
|
Static Current
|
<15μA
|
|
Dynamic Current
|
<120mA
|
|
Lower Voltage Warning
|
<4. 8V (250 times at least)
|
|
Working Temperature
|
-10ºC~50ºC
|
|
Working Humidity
|
20%~80%
|
|
Working Voltage
|
4PCS LR6 Alkaline Batteries
|
|
Door Thickness Request
|
35mm~55mm (available for others)
|
|
Door Type
|
Wood door, Steel door, Stainless Steel door, Brass door
|
Product Detailed Pictures
Hotel Management System
|
Basic (necessary) components of hotel lock system include
|
|
|
|
Computer
|
It is used to install lock management software, prepared by hotel.
|
|
|
Software
|
Send you for free.It is management system. Work on window XP, 7, 8, and 10.Compatible with most of the common property management
systems(PMS) interface. |
|
|
Card Reader/Authorize Card
|
It is used to read and encode(issue) the card. USB port.
|
|
|
M1 Cards
|
One Lock need at least one pcs card, for open door.
|
|
|
Locks
|
Install on to the door. Independent, wireless, battery-operated. It stores latest 250 events.Perfect reading. Advanced security
performance. |
|
|
Optional components:
|
|
|
|
Handset
|
Data collector It is used to collect the unlocking records from the locks, and read on the computer.
|
|
|
Power-saving switch
|
Device allow the key card to turn on the lighting system and air controller of the room.
|
|
|
Elevator controller
|
Elevator using
|
|
