Quick Details
-
Dimension(L*W*H):
-
5m*5m*21.5m
-
Weight:
-
18.51 KG
-
Key Selling Points:
-
easy transportation, installation and disassembly
-
Product name:
-
grain silo homes for sale
-
Model number:
-
300T
-
Discharging Height:
-
2m-6m
-
Type:
-
Bolted silo
-
Color:
-
customized
-
Application:
-
Clinker
-
Working life:
-
20-50years
-
Silo accessories:
-
Dust conveyor,level indicator,etc.
-
Shape:
-
ground or squire(customized)
Quick Details
-
Core Components:
-
carbon steel
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Luwei
-
Dimension(L*W*H):
-
5m*5m*21.5m
-
Weight:
-
18.51 KG
-
Key Selling Points:
-
easy transportation, installation and disassembly
-
Product name:
-
grain silo homes for sale
-
Model number:
-
300T
-
Discharging Height:
-
2m-6m
-
Type:
-
Bolted silo
-
Color:
-
customized
-
Application:
-
Clinker
-
Working life:
-
20-50years
-
Silo accessories:
-
Dust conveyor,level indicator,etc.
-
Shape:
-
ground or squire(customized)
Clinker bolted steel grain silo homes for sale grain silo homes for sale
1.Reliable design
All of our product designs are provided by prestigious Tongji University, the strength of silo,resistance coefficient of the typhoon and the bending resistance data are perfectly calculated by experts.
2.State of the art manufacturing technology
Every parts of the grain silo are manufactured by advanced cutting and drilling technology, they are implemented with unique surface cleaning procedure then painted with fine coating.
3.Short production period
Our grain silo is in modular production, every components are produced by stream-lined workshop, in this way, we can significantly reduce the production cycle, so as to ensure fast delivery.
4.Excellent sealing condition
Between every junctions, we insert special silicone rubber and compress them from 5mm into 1mm, the strong elasticity effect will automatically fill in every possible leaks, we also use glass cement to seal the surface of the junction, so as to re-ensure the sealing condition and prevent any infiltration of moisture.
5.Easy delivery and installation
Our grain silos are produced in parts, they can be easily packed into containers regardless of the size, since all the manufacturing process are finished in factory, all you need to do is to assemble the parts of silos after delivery, that will save you quite amount of time.
Technical index (for reference)
|
Serial number |
Model and size |
Diameter (mm) |
number of layers |
Leg distance (mm) |
Theoretical capacity (M3) |
|
1 |
PG50T |
3100 |
3 |
2020 |
40.67 |
|
2 |
PG60T |
3100 |
4 |
2020 |
52.13 |
|
3 |
PG100T |
3100 |
7 |
2020 |
86.52 |
|
4 |
PG150T |
3300/3800 |
6/8 |
2180/2570 |
111.74/114.96 |
|
5 |
PG200T |
4500 |
6 |
3010 |
164.27 |
|
6 |
PG300T |
5000 |
7 |
3290 |
234.85 |
|
7 |
PG400T |
5700 |
8 |
2640 |
348.14 |
|
8 |
PG500T |
6500 |
8 |
3015 |
458.36 |
|
9 |
PG800T |
8000 |
8 |
3660 |
700 |
Note:
The above sizes are just for reference. We are able to design and produce grain silos according to client's requirements.
Here are our delivery details:
Q1:What are the After-Sales service you provide?
A:We can provide engineers available to service machinery overseas.
Q2;What is you company?
A:We are a factory.
Q3:What is your terms of payment ?
A: 30% TT in advance, 70% balance by sight LC.
