Quick Details
-
Application:
-
Garage & Shed
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
PYTT
-
Model Number:
-
PD1200
-
Product name:
-
automatic garage door operator
-
Power supply:
-
AC 220V or AC110V
-
Keyword:
-
automatic door operator
-
Function:
-
Waterproof
-
Feature:
-
Easy Install
-
Certificate:
-
CE ISO
-
Material:
-
Stainless Steel
-
Max.gate weight:
-
130 KG
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Onsite Inspection, Free spare parts, Other
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Others
-
Application:
-
Garage & Shed
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
PYTT
-
Model Number:
-
PD1200
-
Product name:
-
automatic garage door operator
-
Power supply:
-
AC 220V or AC110V
-
Keyword:
-
automatic door operator
-
Function:
-
Waterproof
-
Feature:
-
Easy Install
-
Certificate:
-
CE ISO
-
Material:
-
Stainless Steel
-
Max.gate weight:
-
130 KG
Product Description
PD800/PD1000/PD1200
DETAILED PRODUCT DESCRIPTION
Automatic safety reverse is designed to protect your children and propeties.
Soft start-Soft stop function makes for quieter operations
Auto-Close function keeps your house by automatically closing the door upon entering or exiting the garage.
Self-learning open and close obstruction force.
Electronic limit, simple adjustment.
Available terminal for Photo beams & Extra receivers & Wire or wireless wall switch &
Caution light & Pass door protection device.
Energy saving - L.E.D courtesy light. Battery backup available.
Self-Lock in gear motors.
Lower headroom: Can be flush mounted for low headroom applications with as little as 30mm space range required.
|
Unit Model
|
PD800
|
PD1000
|
|
PD1200
|
|||
|
Power supply
|
220V,50Hz;110V,60Hz
|
|
|
|
|||
|
Motor Power
|
DC24V,100W
|
|
DC24V,120W
|
|
|||
|
Open and close force
|
800N
|
1000N
|
|
1200N
|
|||
|
Door area
|
12 Sq.m
|
16 Sq.m
|
|
20 Sq.m
|
|||
|
Door moving speed
|
16 cm/sec
|
|
|
|
|||
|
Limit Switch
|
Electronic limit switch
|
|
|
|
|||
|
Decoding / Frequency
|
Rolling code / 433.92MHz
|
|
|
|
|||
|
Extra remote control
|
25
|
|
|
|
|||
|
Remote control range
|
≥30 m
|
|
|
|
|||
|
Working temperature
|
-20°C~50°C
|
|
|
|
|||
|
Transformer
|
80w
|
100w
|
|
120W
|
|||
