We have a modern factory and a domestic first-class production line.
The sales and service network covers more than 50 countries in Africa, Mid Asia and Southeast Asia,
the company has developed rapidly and gained an excellent market reputation.
Please contact me if necessary.
- Product Details
- {{item.text}}
Quick Details
-
Product name:
-
Car Carrier Semi Trailer
-
Axle:
-
2/3/4 Axle
-
Function:
-
Transport Heavy Duty Equipment
-
Suspension:
-
Mechanical Suspension
-
Color:
-
Customers Optional
-
Keywords:
-
Car Carrying Trailer
-
Tire:
-
12R22.5
-
Brake System:
-
ABS
-
Loading capacity:
-
30T ~ 100T
-
Landing Gear:
-
Standard 28Ton
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
>30000 kg
-
Place of Origin:
-
China
-
Product name:
-
Car Carrier Semi Trailer
-
Axle:
-
2/3/4 Axle
-
Function:
-
Transport Heavy Duty Equipment
-
Suspension:
-
Mechanical Suspension
-
Color:
-
Customers Optional
-
Keywords:
-
Car Carrying Trailer
-
Tire:
-
12R22.5
-
Brake System:
-
ABS
-
Loading capacity:
-
30T ~ 100T
-
Landing Gear:
-
Standard 28Ton
Product Description
Please trust us and choose us
Product Show
Specification
|
Total Weight
|
39500 kg
|
|
Rated Load
|
31000 kg
|
|
Tare Weight
|
8500 kg
|
|
Wheel Base
|
5350+1310+1310, 5000+1310+1310 (mm)
|
|
Tyre Specifications
|
11.00R20 12PR
12R22.5 12PR(Vacuum tyre or rail tyre) |
|
No. Of the Tyres
|
12
|
|
Axle Brand
|
FUWA (BPW optional)
|
|
No. Of the Axles
|
3
|
|
Axle-load
|
24000 kg
|
|
Pieces of leaf-spring
|
10 (8) (4)
|
|
Suspension
|
Independent stamping steel rigid suspension ( air suspension)
|
|
Departure Angle
|
17
|
|
Front/Rear Overhang
|
1830 mm
|
|
Outside Dimensions (LxWxH)
|
11000,10500X2500X 3950,3750,3550,3350 (mm)
|
|
Interior Dimensions (LxWxH)
|
10800,10300X2350X 2400,2200,2000,1800 (mm)
|
|
Material of the Main Beam
|
Q235B manganese plates, automatic submerged arc welded
|
|
Brake Chamber
|
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TAIYUE brand); One piece of 45L air tanks
|
|
ABS system
|
optional
|
|
Light
|
Tail lamp with turn signal, brake light & reflector, side lamp etc
|
|
Tool box
|
1 sets(waterproof type)
|
|
Spare tire carrier
|
1 sets(Patent type)
|
|
Painting
|
Complete Chassis sand blasting to clean rust, 2 coat of anticorrosive primer, 2 coats of final paint
|
|
Packing
|
Polish with wax before shipping
|
Packing&Shipping
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
