Quick Details
-
Place of Origin:
-
Guangxi, China
-
Displacement:
-
7.5L
-
type of diesel engine:
-
vertical, in-line, water-cooled, four-stroke
-
number of cylinders:
-
6
-
bore x stroke:
-
108 x 135
-
induction system:
-
turbocharged and intercooled
-
starting mode:
-
electric start
-
fuel supply system:
-
HPCR (high pressure common rail)
-
rated power/speed:
-
265 (360hp)/2400
-
overload power/speed:
-
295 (400hp)/2500
-
dry weight of engine:
-
500kg
Quick Details
-
Dimensions (L x W x H) (mm):
-
1160x860x1155
-
Brand Name:
-
Yuchai
-
Model Number:
-
YCD6Q33C6-400
-
Place of Origin:
-
Guangxi, China
-
Displacement:
-
7.5L
-
type of diesel engine:
-
vertical, in-line, water-cooled, four-stroke
-
number of cylinders:
-
6
-
bore x stroke:
-
108 x 135
-
induction system:
-
turbocharged and intercooled
-
starting mode:
-
electric start
-
fuel supply system:
-
HPCR (high pressure common rail)
-
rated power/speed:
-
265 (360hp)/2400
-
overload power/speed:
-
295 (400hp)/2500
-
dry weight of engine:
-
500kg
Product Description
Specification
|
market positioning: suitable for 10-12m leisure fishing boats, official business boats and patrol boats.
|
|
|
|
item
|
value
|
|
|
Condition
|
New
|
|
|
Engine
|
4 Stroke
|
|
|
Fuel Type
|
Diesel
|
|
|
Cylinders
|
6
|
|
|
Displacement (L)
|
7.5
|
|
|
Engine Position
|
Inboard
|
|
|
Dimensions (L x W x H) (mm)
|
1160*860*1155
|
|
|
Brand Name
|
Yuchai
|
|
|
Model Number
|
YCD6Q33C6-400
|
|
|
Place of Origin
|
China
|
|
|
|
Guangxi
|
|
|
type of diesel engine
|
vertical, in-line, water-cooled, four-stroke
|
|
|
bore x stroke
|
108 x 135
|
|
|
induction system
|
turbocharged and intercooled
|
|
|
starting mode
|
electric start
|
|
|
fuel supply system
|
HPCR (high pressure common rail)
|
|
|
rated power/speed
|
265 (360hp)/2400
|
|
|
overload power/speed
|
295 (400hp)/2500
|
|
|
dry weight of engine
|
≤760kg
|
|
|
fuel consumption rate at fixed point(g/kWh)
|
≤200
|
|
|
oil consumption rate (g/kWh)
|
≤0.9
|
|
|
steady-state speed governing rate (%)
|
≤10
|
|
|
transient speed regulation (%)
|
≤12
|
|
|
speed fluctuation rate (%)
|
≤1
|
|
|
emission
|
phase Ⅱ
|
|
Design Features
|
1. New creation through strong cooperation with FEV of Germany
|
|
2. Automatic tensioning V-ribbed belt gear train, realizing large wrap angle and high reliability
|
|
3. High-flow oil pump, cooler with high cooling capacity and engine body with a large oil passage, ensuring sufficient lubrication
|
|
4. Sufficient engine power and good stability
|
|
5. Use of intake preheating device, meeting the low-temperature cold start capability
|
|
6. Integrated "water-cooled exhaust pipe + heat exchanger" modules
|
|
7. Integrated "air intake pipe + intercooler" modules
|
