Quick Details
-
Row Distance(mm):
-
0 - 2000 mm
-
Place of Origin:
-
China
-
Brand Name:
-
Top Brand
-
Dimension(L*W*H):
-
6440*2850*3280 mm
-
Weight:
-
4750 KG
-
Marketing Type:
-
New Product 2023
-
Drive Type:
-
self-propelled
-
Color:
-
Customers' Requirements
-
Rotating Speed:
-
2700 r/min
-
oil tank:
-
200L
-
grain tank:
-
2cbm
-
working speed:
-
3.5-7.5km/h
-
Port:
-
shanghai port
-
Supply Ability:
-
3 Piece/Pieces per Day
-
Productivity:
-
0.2 to 0.4 hm2/h
Quick Details
-
Number of Rows:
-
4
-
Working Width(mm):
-
2000 mm
-
Tractor Power(HP):
-
25 - 190 HP
-
Row Distance(mm):
-
0 - 2000 mm
-
Place of Origin:
-
China
-
Brand Name:
-
Top Brand
-
Dimension(L*W*H):
-
6440*2850*3280 mm
-
Weight:
-
4750 KG
-
Marketing Type:
-
New Product 2023
-
Drive Type:
-
self-propelled
-
Color:
-
Customers' Requirements
-
Rotating Speed:
-
2700 r/min
-
oil tank:
-
200L
-
grain tank:
-
2cbm
-
working speed:
-
3.5-7.5km/h
-
Port:
-
shanghai port
-
Supply Ability:
-
3 Piece/Pieces per Day
-
Productivity:
-
0.2 to 0.4 hm2/h
Products Description
Wheeled combine harvester is a newly designed combines which is New for corn harvesting and by changing some special parts, it can harvest wheat, rice, oilseed rape, soybeans and so on. The combines have such characteristics as high efficiency and excellent cleaning system and comfortable driving.
Specification
|
Product Model
|
|
|
AF88G
|
||
|
Overall dimensions
|
Length(mm)
|
|
5160
|
||
|
|
Width(mm)
|
|
2750
|
||
|
|
Height(mm)
|
|
2750
|
||
|
Weight(kg)
|
|
|
2970
|
||
|
Engine
|
Model
|
|
Dachai-DEUT ZCA498Z-09T2/01
|
||
|
|
Structure type
|
|
Four-stroke,water-cooled,
turbocharged diesel engine |
||
|
|
Rated power(kW)
|
|
65/88HP
|
||
|
|
Rated speed(rpm)
|
|
2400
|
||
|
|
Fuel type
|
|
Diesel(0#)
|
||
|
|
Fuel tank(L)
|
|
95
|
||
|
Walking part
|
Track
|
Specification link
|
500*90*51
|
||
|
|
Min ground clearance(mm)
|
|
325
|
||
|
|
Gearbox type
|
|
HST
|
||
|
|
Transmission type
|
|
(HST+3-gear) continuously
variable-speed |
||
|
|
Theoretical traveling speed(km/h)
|
|
Low speed 0-3.96,Standard 0-5.14,
Walk speed 0-7.37 |
||
|
Header system
|
Header width(mm)
|
|
2000
|
||
|
Threshing part
|
Threshing type
|
|
Vertical type axial-flow
bar tooth type |
||
|
|
Threshing cylinder
|
Outer diameter(mm)
|
φ620*1790
|
||
|
|
|
Rotate speed(r/min)
|
580
|
||
|
Grain unloading part
|
Grain tank capacity(L)
|
|
1400
|
||
|
|
Unloading grain rotation range(Degree)
|
|
270
|
||
|
|
Unloading grain height range(mm)
|
|
920-4200
|
||
|
Electrolyte and others
|
Battery
|
Voltage(V)
|
12
|
||
|
|
Starting relay
|
Rated current(A)
|
50
|
||
|
|
|
Vilotage(V)
|
12
|
||
|
|
Hydulic oil tank volume
|
|
21
|
||
|
Hourly production(hm2/h)(Vertical dry field crops environment)
|
|
|
0.3-0.7
|
||
