Quick Details
-
Door:
-
Steel Door
-
Wall and Roof:
-
EPS or glass wool panel
-
Floor:
-
PVC Floor
-
Main structure:
-
Galvanized Light Steel Frames
-
Purlin:
-
Q235 Galvanized
-
Packing:
-
8 units can be fully fitted in a 40'HQ
-
Color:
-
Customized Color
-
Product Size:
-
5800mm(L)*2400mm(W)*2896mm(H)
-
Certification:
-
CE
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Type:
-
Flat Pack
-
Door:
-
Steel Door
-
Wall and Roof:
-
EPS or glass wool panel
-
Floor:
-
PVC Floor
-
Main structure:
-
Galvanized Light Steel Frames
-
Purlin:
-
Q235 Galvanized
-
Packing:
-
8 units can be fully fitted in a 40'HQ
-
Color:
-
Customized Color
-
Product Size:
-
5800mm(L)*2400mm(W)*2896mm(H)
-
Certification:
-
CE
Products Description
|
Accessories Name
|
Description
|
|
Ground Beam
|
14#/16# H-beam, 12# channel steel;100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube;120*120*3.0 / 150*150*3.0 bending
parts
|
|
Pillar/Column
|
100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube;120*120*3.0 / 150*150*3.0 bending parts
|
|
Floor beam
|
100*100*3.0 / 150*75*3.0 / 120*60*3.0 / 60*60*2.0 galvanized steel tube;60*60*3.0 / 120*120*3.0 / 150*150*3.0 bending parts
|
|
Floor Purlin
|
8# channel steel;80*80*2.0 / 50*100*2.0 / 40*80*2.0 galvanized steel tube
|
|
Stairs
|
150*30 C-type steel
|
|
Walkway Board
|
anticorrisive woods
|
|
External Wall
|
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board;0.46mm pre-painted galvanized steel board
|
|
Internal Wall
|
0.46mm / 0.36mm / 0.26mm pre-painted galvanized steel board
|
|
Roof Panel
|
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board;0.46mm pre-painted galvanized steel board
|
|
Edge
|
PVC capping seal, bamboo and woods fiber capping seal
|
|
Floor
|
Glass magnesium board, PVC composition tile, ceramic tiles
|
|
Window
|
Sliding window, casement window, hanging window, double-glazed glass window（thickness can be customized)
|
|
Door
|
Security door, plastic steel door, steel door, stainless steel door
|
Product Features
Fast installation - an average of 4 workers can complete the installation of a single box in 3 hours, or the whole
container can be moved and relocated after assembly, which is convenient and fast.
Safe and durable - the service life is more than 15 years, the seismic intensity is 8 degrees, the wind resistance is 11,
and the snow bearing capacity is about 1.5 meters.
Save on shipping costs - After flattening and compressing, every 4 sets is equivalent to the size of a standard 20-foot
container, saving 3/4 of shipping costs; 1 40-foot high container can ship 8 sets.
container can be moved and relocated after assembly, which is convenient and fast.
Safe and durable - the service life is more than 15 years, the seismic intensity is 8 degrees, the wind resistance is 11,
and the snow bearing capacity is about 1.5 meters.
Save on shipping costs - After flattening and compressing, every 4 sets is equivalent to the size of a standard 20-foot
container, saving 3/4 of shipping costs; 1 40-foot high container can ship 8 sets.
|
Flat Pack Container-
Circuit
|
Product installation
|
Insulation Capability
|
λ=0.048W/m·K
|
|
|
|
Wind Resistance
|
0.60kN/㎡
|
||||
|
Soundproof Capability
|
≥30dB
|
|
|
|
Fire Resistance
|
A
|
||||
|
Waterproof Capability
|
Rain≥16mm/min, 360° bite occlusion design
|
|
|
|
Earthquake Resistance
|
8 level
|
||||
|
Floor Loading
|
2.0 kN/㎡
|
|
|
|
Roof Loading
|
1.0 kN/㎡
|
||||
|
PRODUCT
|
SPECIFICATION
|
|
|
Q'TY/ SET
|
Unit price/ USD
|
Amount/ USD
|
||||
|
|
|
|
|
|
|
|
||||
|
Flat-pack Container
5800*2400*2896mm
|
Flat-pack Container
|
|
|
|
|
|
||||
|
|
Frame
|
|
|
Bottom Beam: 2.3mm; 160*160mm Galvanized Steel Tube
Buttom Purlin: 1.8mm; C100*50mm*9pcs Galvanized Steel Tube |
|
|
||||
|
|
|
|
|
Column: 2.75mm; 210*160mm Galvanized Steel Tube
|
|
|
||||
|
|
|
|
|
Roof Beam:2.5mm; 160*160mm Galvanized Steel Tube
Roof Purlin:1.5mm; 80*40mm Galvanized Steel Tube With extra steel brace: 0.326mm |
|
|
||||
|
|
Wall Board
|
|
|
Rock Wool Wall Board: 75mm, Width 1150mm, density 80kg/m³
Sandwich Panel: 0.476mm color steel plate with PE film Fireproof level: A Level |
|
|
||||
|
|
Ceiling
|
|
|
External Panel: 0.476mm color steel plate
Insulation Layer: 40mm glass wool, density 14kg/m³ Interior Panel: 0.326mm color steel plate-Type 831 wave tile Ceiling Tile: 0.476mm color steel plate-Type 831 wave tile |
|
|
||||
|
|
Floor
|
|
|
Cement Board: 18mm
PVC Floor Leather: 2.0mm |
|
|
||||
|
|
Door
|
|
|
Stainless Steel Door Size≥ W840×H2040mm
|
|
|
||||
|
|
Decoration Line
|
|
|
PVC Skirting: 0.5mm (Default Brown Color)
Column Line: 0.5mm color bending steel Roof Corner Line: 0.5mm color bending steel |
|
|
||||
|
|
Electricity
|
|
|
LED Light Bar:15W*2set
Socket:10A*3pcs, 16A*1pcs for Air-condistioner One-touch Switch: 1pcs Distributor box: 1pcs with concealed wiring |
|
|
||||
|
Optional Equipment
|
Rooftop frame with handrail
Size: 5800*2400mm |
|
|
||
|
|
Stair with handrail
Size: 6000*1200mm |
|
|
||
|
|
Bar Counter only
Size: 250*50*110cm Size can be customized |
|
|
||
|
|
Awning Size：6.0*1.5m
|
|
|
||
|
|
5+9A+5 Floor Glass Door
|
|
|
||
|
Other Engineering Case Reference Design & Application
|
|
Guizu Group, a modular container house manufacturer from China.
|
With 12 years experience since company established in 2008, we've been dedicated ourselves to prefabricated structure buildings for countless number of local and international clients.
Guizu Group offers a complete solution for the prefabricated container houses including design, production, installation,after-sales service with multiple application such as: container office, worksite container camp, accommodation containers, storage containers, staff dormitory, Shopping mall, stores, coffee shop, display showroom container, multiple unit bathroom, portable toilet, swimming pools, etc.
