Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Mingshi, OEM
-
Model Number:
-
S-1
-
Heat Conductivity:
-
0.43
-
Specification:
-
12/14/15/16/18/20/22/25/26/32/40/50/63
-
Linear Expansion Coefficient:
-
0.025
-
Outer Diameter:
-
12/14/15/16/18/20/22/25/26/32/40/50/63
-
Thickness:
-
2.0-6.0mm
-
Standard:
-
ISO21003
-
Color:
-
White/ black/ yellow/ red/ blue/ orange
-
Application:
-
Gas/ Water/ UFH underfloor heating
-
Certification:
-
AENOR, WRAS, CSTB, SKZ, WATERMARK, ACS
-
Welding:
-
Buttwelding/ Overlapped
-
MOQ:
-
10,000mts
-
Working Temperature:
-
Max.95℃
-
working pressure:
-
Max.10bar
-
Colors:
-
White/ Black/ Orange/ Blue/ Red
-
Coil length:
-
25m-500m
-
Diameter:
-
9-63mm
-
Crosslink degree:
-
≥65%
Quick Details
-
Material:
-
PEX-Al-PEX
-
Length:
-
4/5/6/10/25/50/100/200m
-
Processing Service:
-
Moulding
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Mingshi, OEM
-
Model Number:
-
S-1
-
Heat Conductivity:
-
0.43
-
Specification:
-
12/14/15/16/18/20/22/25/26/32/40/50/63
-
Linear Expansion Coefficient:
-
0.025
-
Outer Diameter:
-
12/14/15/16/18/20/22/25/26/32/40/50/63
-
Thickness:
-
2.0-6.0mm
-
Standard:
-
ISO21003
-
Color:
-
White/ black/ yellow/ red/ blue/ orange
-
Application:
-
Gas/ Water/ UFH underfloor heating
-
Certification:
-
AENOR, WRAS, CSTB, SKZ, WATERMARK, ACS
-
Welding:
-
Buttwelding/ Overlapped
-
MOQ:
-
10,000mts
-
Working Temperature:
-
Max.95℃
-
working pressure:
-
Max.10bar
-
Colors:
-
White/ Black/ Orange/ Blue/ Red
-
Coil length:
-
25m-500m
-
Diameter:
-
9-63mm
-
Crosslink degree:
-
≥65%
|
Multilayer PEX-AL-PEX/ PERT-AL-PERT Pipe
|
|
|
|
Warranty
|
More than 10 years
|
|
|
Certification
|
AENOR, WRAS, CSTB, ACS, WATERMARK, SKZ
|
|
|
Application
|
Water/ Gas/ Underfloor heating (UFH)
|
|
|
Customized support
|
OEM, ODM
|
|
|
Place of Origin
|
China, Zhejiang
|
|
|
Brand Name
|
OEM/MINGSHI/MSP
|
|
|
Model Number
|
S-1
|
|
|
Standard
|
ISO 21003/ other
|
|
|
Welding types
|
Buttwelding/ Overlapped
|
|
|
OD (mm)
|
15/ 16/ 18/ 20/ 22/ 25/ 26/ 28/ 32/ 40/50/63
|
|
|
Colors
|
White/ Black/ Red/ Blue/ Yellow/ Orange
|
|
|
Working pressure
|
Max. 10 bars
|
|
|
Working temperature
|
Max. 95℃
|
|
|
Crosslinking degree
|
≥65
|
|
1. For Plumbing water(cold & hot)/gas / underfloor heating systems, Composed of 5 layers:
-External Plastic/external Glue/Aluminum/internal Glue/internal Plastic
2. Certificates we have: AENOR, CSTB, SKZ, ACS, WATERMARK, JASWIC, ISO9001
3. Material: CONSTAB/ Other PEX
4. QC: Including materials checking and test, spot inspection on production lines, and all the tests required by each standard done on the finished products in our lab rooms
5. Overlapped/buttwelding
-Spec. (mm)
16*2.0
18*2.0
20*2.0
20*2.25
25*2.5
26*3.0
32*3.0
40*4.0
50*4.5
63*6.0
6. Lead time: 15-30days
7. Main makets: Europe, South Africa, South America, Asia, Australia
8. Applications:
-Cool & Hot Water Pipe System
-Housing Gas Pipe System
-Under floor heating System
-Solar Energy & Air-conditioning Matching Pipe System
-Medical, Foodstuff & Chemical Industry Pipe System
9. Characters & Advantages:
-Wide range working temperature(-10C~95C), Hi-pressure resistance
-30% more flow than metal pipe
-50 year working life
-Non-corrosive, scale-free
-Hygiene, no oxygen permeability, no growth of Microorganism
-Non-inflammable, non-static
-Easy bending but never spring back
-Light in weight, easy to carry and store
-Few pipe fitting applying leading to little leakage
-Economical price.
-External Plastic/external Glue/Aluminum/internal Glue/internal Plastic
2. Certificates we have: AENOR, CSTB, SKZ, ACS, WATERMARK, JASWIC, ISO9001
3. Material: CONSTAB/ Other PEX
4. QC: Including materials checking and test, spot inspection on production lines, and all the tests required by each standard done on the finished products in our lab rooms
5. Overlapped/buttwelding
-Spec. (mm)
16*2.0
18*2.0
20*2.0
20*2.25
25*2.5
26*3.0
32*3.0
40*4.0
50*4.5
63*6.0
6. Lead time: 15-30days
7. Main makets: Europe, South Africa, South America, Asia, Australia
8. Applications:
-Cool & Hot Water Pipe System
-Housing Gas Pipe System
-Under floor heating System
-Solar Energy & Air-conditioning Matching Pipe System
-Medical, Foodstuff & Chemical Industry Pipe System
9. Characters & Advantages:
-Wide range working temperature(-10C~95C), Hi-pressure resistance
-30% more flow than metal pipe
-50 year working life
-Non-corrosive, scale-free
-Hygiene, no oxygen permeability, no growth of Microorganism
-Non-inflammable, non-static
-Easy bending but never spring back
-Light in weight, easy to carry and store
-Few pipe fitting applying leading to little leakage
-Economical price.
Product details
|
Essential details
|
|
|
|
|
||||
|
Place of Origin:
|
Zhejiang,China
|
Material:
|
Pex
|
|
||||
|
Specification:
|
16-63MM
|
Length:
|
25/50/ 100/200/300/500 or OEM
|
|
||||
|
Thickness:
|
2.0, 2.5, 3.0, 4.0, 4.5, 6.0
|
Standard:
|
AENOR,SKZ,WRAS,WATERMARK
|
|
||||
|
Processing Service:
|
Cutting
|
Product name:
|
Pex-Al-Pex pipe
|
|
||||
|
Application:
|
Gas system,Water system,
Under floor heating. |
Type:
|
Plastic Building Material
|
|
||||
|
Raw Material:
|
Pex, Aluminum
|
Colors:
|
White,Red,Blue,Orange,Red or OEM
|
|
||||
|
Logo:
|
Support custom logo
|
Features:
|
Corrosion Resistant,fire resistant,high pressure
|
|
||||
|
MOQ:
|
10000m
|
Shape:
|
Round
|
|
||||
|
Advantage:
|
Flexible,easy to install
|
|
|
|
||||
|
Supply Ability
|
|
|
|
|
||||
|
Supply Ability:
|
3000000 Meters per month
|
3000000 Meters per month
|
|
|
||||
|
Packing&Delivery
|
|
|
|
|
||||
|
Packing Details:
|
With craft paper, then plastic film outside/Plastic bag
|
With craft paper, then plastic film outside/Plastic bag
|
|
|
||||
|
Port:
|
Ningbo or Shanghai
|
Ningbo or Shanghai
|
|
|
||||
|
International Standards
|
|
|
|
|
||||
|
1
|
EN ISO 21003
|
Multilayer piping systems for hot and cold water installations inside buildings
|
|
|
||||
|
2
|
AS 4176.2 & 3
|
Multilayer piping systems for hot and cold water plumbing applications- PIPES & FITTINGS
|
|
|
||||
|
3
|
ISO17484-2:2009
|
Multilayer Plastics piping systems for indoor gas installations
|
|
|
||||
|
International Certificates
|
|
|
|
|
||||
|
1
|
AENOR
|
refers to EN ISO 21003 ，UNE-EN ISO 53007
|
|
|
||||
|
2
|
CSTB
|
refers to EN ISO 21003
|
|
|
||||
|
3
|
ACS
|
refers to XP P41-250
|
|
|
||||
|
4
|
Watermark
|
refers to AS 4176.2 & 3
|
|
|
||||
|
5
|
WRAS
|
refers to Regulators’ Specification
|
|
|
||||
|
6
|
ISO 9001:2015
|
Quality management system
|
|
|
||||
