Quick Details
-
Brand Name:
-
SHCET
-
Model Number:
-
SH419G
-
Rated Current:
-
16-63A
-
Frequency:
-
50/60Hz
-
Pole:
-
1P/2P/3P/4P
-
Certificates:
-
CE
-
Current:
-
16A /20A/ 25A /32A/ 40A/ 63A
-
Color:
-
White
-
Name:
-
20 amp manual changeover switch
-
Voltage:
-
AC220V-240V
-
Mechanical life:
-
8500
-
Origin:
-
China
-
Mounting:
-
DIN Rail
Quick Details
-
Type:
-
Series Changeover Switches
-
Number of Pole:
-
4
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SHCET
-
Model Number:
-
SH419G
-
Rated Current:
-
16-63A
-
Frequency:
-
50/60Hz
-
Pole:
-
1P/2P/3P/4P
-
Certificates:
-
CE
-
Current:
-
16A /20A/ 25A /32A/ 40A/ 63A
-
Color:
-
White
-
Name:
-
20 amp manual changeover switch
-
Voltage:
-
AC220V-240V
-
Mechanical life:
-
8500
-
Origin:
-
China
-
Mounting:
-
DIN Rail
Product Description
|
Standard
|
IEC/EN60947-3
|
|
Rated voltage
|
240/415V
|
|
Rated current
|
16A 20A 25A 32A 40A 63A
|
|
Rated frequency
|
50/60Hz
|
|
Number of poles
|
1, 2, 3, 4P
|
|
Contact form
|
1-0-2
|
|
Electrical Life
|
1500
|
|
Mechanical Life
|
8500
|
|
Protection degree
|
IP20
|
|
Ambient Temperature
|
-5ºC…40ºC
|
|
Terminal/Cable size
|
16
|
|
Mounting
|
On DIN rail EN60715(35mm) by means of fast clip device
|
Top rating socomec electrical modular din rail 1-0-2 manual mcb mini changeover switch 4p 20 amp 63a 100a supplier from SHCET
