Quick Details
-
Power:
-
0.6KW
-
Weight:
-
120
-
Dimension(L*W*H):
-
580*650*750mm
-
Name:
-
Centrifuge Separator
-
Function:
-
Liquid Soild Centrifuge
-
Description:
-
Food Chemical Industry
-
Application:
-
Food Chemical Industry
-
Capacity:
-
100L/h based on water
-
Material:
-
Stainless Steel 304/316L
-
Operation:
-
Manual Solid Discharge
-
Rotating Speed:
-
28000rpm
-
Drum Diameter:
-
45mm
Quick Details
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Zonelink
-
Voltage:
-
380V
-
Power:
-
0.6KW
-
Weight:
-
120
-
Dimension(L*W*H):
-
580*650*750mm
-
Name:
-
Centrifuge Separator
-
Function:
-
Liquid Soild Centrifuge
-
Description:
-
Food Chemical Industry
-
Application:
-
Food Chemical Industry
-
Capacity:
-
100L/h based on water
-
Material:
-
Stainless Steel 304/316L
-
Operation:
-
Manual Solid Discharge
-
Rotating Speed:
-
28000rpm
-
Drum Diameter:
-
45mm
Product Description
Main Application
GQ type tubular centrifuge
is mainly used for separating all kinds of suspension difficult to be separated,
especially suitable for separation of solid-liquid suspension with light concentration,
heavy viscosity,fine particles and very small differential gravity of the two phases.For example clarifying all kinds of oil fluid, radix soghorae tonkinensis, coal tar and graphite
Painted ink
separation
Food separation
Silicon powder
separation
Structure & Principle
|
Tubular centrifuge separator is high speed centrifuge with strong capacity. The main parts: machine body, driving part,bowl,
liquid collecting pan, liquid-in bearing seat.The material is sprayed onto the bowl from the inlet on the bottom and strong
centrifuge force is formed when the bowl rotates with the material and that makes the material flow upper along the wall of the
bowl and then separated because of the different gravity by the centrifuge force.
GQ-for clarification: Heavy solid is deposited on the inner wall of the bowl,and forms the sludge. And it will be discharged by manual after the machine stops. The clear liquid flows out of outlet from the top of the bowl.The motor connect with the big pulley and delivery the power to the spindle through the belt, tensioner and small pulley and rotate with the bowl in high-speed as the clockwise. |
