Quick Details
-
Horsepower:
-
251 - 350hp
-
Cargo Tank Type:
-
Van
-
Gross Vehicle Weight:
-
5001-10000 kg
-
Drive Wheel:
-
8X4
-
After-sales Service Provided:
-
Online support, Free spare parts
-
Brand Name:
-
SINOTRUK
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
sinotruk
-
Size:
-
11984*2496*3215 mm
-
Cargo Tank Dimension:
-
11984*2496*3215 mm
-
Product name:
-
China 8X4 Van/cargo/box Truck
-
Drive type:
-
8X4 LHD/RHD
-
Certificate:
-
CCC ISO BV
-
Chassis brand:
-
Sinotruk Howo
-
Wheelbase:
-
1456/1375
-
Product Keywords:
-
Diesel Pickup Truck
-
Name:
-
Van Cargo Food Truck
-
Transmission:
-
Manual Operation
-
Loading capacity:
-
35000kg
-
Brand:
-
Sinotruk Howo Cargo Transport
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Construction materials transportation
-
Horsepower:
-
251 - 350hp
-
Cargo Tank Type:
-
Van
-
Gross Vehicle Weight:
-
5001-10000 kg
-
Drive Wheel:
-
8X4
-
After-sales Service Provided:
-
Online support, Free spare parts
-
Brand Name:
-
SINOTRUK
-
Place of Origin:
-
Shandong, China
-
Engine Brand:
-
sinotruk
-
Size:
-
11984*2496*3215 mm
-
Cargo Tank Dimension:
-
11984*2496*3215 mm
-
Product name:
-
China 8X4 Van/cargo/box Truck
-
Drive type:
-
8X4 LHD/RHD
-
Certificate:
-
CCC ISO BV
-
Chassis brand:
-
Sinotruk Howo
-
Wheelbase:
-
1456/1375
-
Product Keywords:
-
Diesel Pickup Truck
-
Name:
-
Van Cargo Food Truck
-
Transmission:
-
Manual Operation
-
Loading capacity:
-
35000kg
-
Brand:
-
Sinotruk Howo Cargo Transport
Sinotruk New Design Howo Light/Heavy Cargo Truck 2T/3T/5T/6T/8T/10T/20T/30T/50T
Our Main Products Heavy Trucks and Construction Machinery. include Howo tractor trucks, dump trucks, trailer truck,Fire trucks, water tank trucks, concrete mixer trucks, special trucks,truck parts and Motor grader,wheel loader, roller loader. we can supply these for our clients with good quality and competitive price.
Product Description
Our cargo trucks are outlined with full and smooth lines, which better meets aerodynamic principles and greatly reduces the dragcoefficient, thus significantly improving fuel economy.
Specification
|
|
Model
|
HW70/HW76/HW79
|
|
|
|
|
|||||
|
Engine
|
Model
|
WD615.87
|
WD615.69
|
WD615.87
|
WD615.69
|
WD615.87
|
|||||
|
|
Rated power.
|
213/2200
|
247/2200
|
213/2200
|
247/2200
|
213/2200
|
|||||
|
|
Maximum torque, Nm/rpm
|
1160/1100-1600
|
1350/1100-1600
|
1160/1100-1600
|
1350/1100-4600
|
1160/1100-1600
|
|||||
|
|
Displacement, L
|
9.726
|
|
|
|
|
|||||
|
|
Type
|
Inl.nc 6 cylinders, 2 valves, rear supercharger, supercharged intcrcooling
|
|
|
|
|
|||||
|
Transmission
|
|
SINOTRUK HW series 10 speed transmission, main and auxiliary transmission structure, main transmission with double countershaft,
auxiliary transmission with planetary reducer. Standard HW1571O for WD615.87 engine, standard HW19710 for WD615.47 engine. |
|
|
|
|
|||||
|
Front axle
|
|
HF7 rated load of 7tr drum-type; HF9 for heavy truck, rated load of 9t. drum-type
|
|
|
|
|
|||||
|
Drive axle
|
|
ST16 double reduction, speed ratio: 3.93, 4.42,4.8; HC16 double reduction for heavy truck, speed ratio: 4.8,5.73.
|
|
|
|
|
|||||
|
Suspension
|
|
Front and rear leaf spring suspension, front suspension with shock absorber and transverse stabilizer, rear suspension is
disconnected type with transverse stabilizer. |
|
|
|
|
|||||
|
Steering system
|
|
ZF8098 steering gear, ZF steering oil pump, system pressure of 18MPa
|
|
|
|
|
|||||
|
Tyre
|
|
12.00R20; optional 12R22.5,12.00R24 and 12.00-24
|
|
|
|
|
|||||
|
Tank volume, L
|
|
300
|
|
|
|
|
|||||
|
Gross mass, kg
|
|
31000kg
|
|
|
|
|
|||||
|
Dimensions
|
|
11984*2496*3215 mm
|
|
|
|
|
|||||
All the bodies adopt integral steel-framed structure, hard and firm, allowing high collision resistance and external force
resistance.
resistance.
Wide-angle rear view mirror The luxury wide-angel rear view mirror provides the drive with unobstructed all-around visibility,further assuring driving safety.
It’s suitable for Logistics business, for transport all kinds of goods, such as machine, equipment, coal and so on .
It’s suitable for Logistics business, for transport all kinds of goods, such as machine, equipment, coal and so on .
1 Factory price, more competitive than agent price.
2 Quality: With SINOTRUK group inspection system, a series inspections are well done before the exportation.
3 Warranty: One year or 100 000k which comes to the first for the engine, gear box, and axles.
4 After-sales: Professional after-sales team sovle your difficult or special questions within 3
working days or 5 working days, and all spare parts are available for your urgent use.
5 Transportation: Professional logistics team work with international shipping company for your truck shipment successfuly.
