Quick Details
-
Brand Name:
-
Andy
-
Model Number:
-
steel truss 1
-
Product name:
-
prefabricated steel truss structure
-
other name:
-
Prefabricated Steel Frame Metal Structure Church Building
Quick Details
-
Grade:
-
Hot Rolled Steel
-
Dimensions:
-
Customers' Requirement
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Andy
-
Model Number:
-
steel truss 1
-
Product name:
-
prefabricated steel truss structure
-
other name:
-
Prefabricated Steel Frame Metal Structure Church Building
Prefabricated steel truss structure
steel modelling, pipe truss, high strength material
|
Summary |
Project Name: |
Prefabricated steel truss structure airport |
|
Structure type: |
Bolted ball joint Space Frame |
|
|
Shape: |
Different Kinds of Airport |
|
|
Dimension: |
Length:1 10 0m, Wide:600 m, Height: 50 m |
|
|
Design details |
Design code: |
|
|
Wind load: |
2(200kph) |
|
|
Earthquake load: |
4(Z=0.4) |
|
|
Live load: |
50kg/sq.m |
|
|
Dust load: |
10kg/sq.m |
|
|
Temperature: |
+/-30°C Aircraft Hangar |
|
|
Snow load: |
None Storage |
|
|
Components |
Bolt ball: |
Steel #45, epoxy zinc primer with PU paint |
|
Tube: |
Steel Q235, epoxy zinc primer with PU paint |
|
|
High strength bolt: |
40 Cr, electro-galvanization |
|
|
Sleeve: |
Steel Q235 & #45, electro-galvanization |
|
|
Purlin: |
Steel Q235, galvanization Space Frame Storage |
|
|
Roof & Wall panel: |
Sandwich panels Space Frame Storage Space Frame Storage Steel Hangar |
