Quick Details
-
Brand Name:
-
Keysight
-
Model Number:
-
N2840A
-
Product name:
-
N2840A passive probe
-
Bandwidth:
-
50MHz
-
Attenuation ratio:
-
10:1
-
Input resistance:
-
10 MΩ
Quick Details
-
Warranty:
-
3 years
-
Customized support:
-
Customization is not supported
-
Place of Origin:
-
American
-
Brand Name:
-
Keysight
-
Model Number:
-
N2840A
-
Product name:
-
N2840A passive probe
-
Bandwidth:
-
50MHz
-
Attenuation ratio:
-
10:1
-
Input resistance:
-
10 MΩ
Product Description:
N2840A passive probe
N2840A passive probe, 10:1, bandwidth 50 MHz, 1.2 m, with large 10 MΩ input resistance, adjustable for low and high frequency compensation
|
Bandwidth
|
DC to 50 MHz
|
|
|
|
|
Rise time
|
7 ns
|
|
|
|
|
Attenuation ratio
|
10:1
|
|
|
|
|
Input Resistance (1 MΩ Load Termination)
|
10 MΩ
|
|
|
|
|
Maximum input voltage
|
300 V RMS (or > 400Vpk) CAT I and CAT II
|
|
|
|
