- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
SCG22052004
-
Type:
-
kite pole glass fibre rods
-
Color:
-
Customized Colors
-
Feature:
-
Corrossion Resistance
-
Length:
-
Customized Length
-
Size:
-
Customized Welcomed
-
Advantage:
-
Light Weight/anti-aging
-
Diameter:
-
Various from 1.5mm to 51.5mm
-
Usage:
-
solid glass fiber rod kite rod
Quick Details
-
Material:
-
FRP, Fibreglass Reinforced Plastic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sanchuang
-
Model Number:
-
SCG22052004
-
Type:
-
kite pole glass fibre rods
-
Color:
-
Customized Colors
-
Feature:
-
Corrossion Resistance
-
Length:
-
Customized Length
-
Size:
-
Customized Welcomed
-
Advantage:
-
Light Weight/anti-aging
-
Diameter:
-
Various from 1.5mm to 51.5mm
-
Usage:
-
solid glass fiber rod kite rod
|
Features:
|
|
|
|
High strength yet light weight:
|
Helps save on transportation
|
|
|
Corrosion resistant:
|
Won’t rot, rust or corrode
|
|
|
Fire-retardant and nonconductive:
|
Helps create a safer environment
|
|
|
Dimensionally stable:
|
Won’t shrink, swell, warp or bow
|
|
|
Virtually maintenance-free:
|
Durable and weather-resistant for a longer life cycle
|
|
|
Easy to fabricate and install:
|
Can be cut, drilled and assembled with standard tools
|
|
|
Non-leaching:
|
Does not require environmentally hazardous preservatives
|
|
|
Testing results for physical properties:
|
|
|
|
|
||||
|
(No.)
|
Testing items
|
Unit
|
Testing results
|
Testing standard
|
||||
|
1
|
Density
|
g/cm3
|
1.85-1.9
|
ASTM D792
|
||||
|
2
|
Water absorption
|
%
|
0.57
|
ASTM D570
|
||||
|
3
|
Flexural strength
|
MPa
|
302
|
ASTM D790
|
||||
|
4
|
Flexural modulus
|
GPa
|
18.6
|
ASTM D790
|
||||
|
5
|
Tensile strength
|
MPa
|
210
|
ASTM D638
|
||||
|
6
|
Tensile modulus
|
GPa
|
22
|
ASTM D638
|
||||
|
7
|
Flame retardant rating
|
|
V0/V1
|
UL94
|
||||
|
8
|
Dielectric breakdown voltage
|
KV
|
14.98
|
ASTM D149-09
|
||||
|
Notes: The above testing results are based on ordinary materials, if any special requirements, feel free to contact with us.
|
|
|
|
|
||||
|
Technical Parameters:
|
|
|
|
|||
|
Diameter(mm)
|
Min Bending Radius(mm)
|
Max Pulling Force(kN)
|
Metal Tips Min Pulling Force(kg)
|
|||
|
5.0
|
130
|
0.4
|
500
|
|||
|
11.0
|
300
|
12
|
|
|||
|
12.0
|
400
|
12
|
|
|||
|
13.0
|
500
|
20
|
|
|||
|
14.0
|
750
|
30
|
|
|||
|
15.0
|
800
|
40
|
|
|||
|
The above listed are just for some normal sizes.
|
|
|
|
|||
Q: Are you Trading Company or Manufacturing Factory?
A: We are the leading manufacturer in Guangdong area for 10 years, our products have competitive price and quality guarantee. Welcome to send your inquiry.
Q: I am interested in your products, could I get sample for free?
A: We can supply a few pieces FREE samples if we have some in stock, and you only need to pay the freight cost by yourself. Welcome to send your inquiry for FREE samples.
Q: How about the delivery time?
A: 10-15days after receiving the deposit based on the MOQ. Normally, 30-35days to finish the order for a 20ft container. Of course, we can also meet the urgent delivery time if the production schedule is not tight. Welcome to ask for the detailed delivery time according to your order quantity.
Q: How can you guarantee the product quality?
A: We have the quality control system ISO9001:2008, and it’s been followed strictly. We also have the professional QC team, and each our package worker will be in charge of the final inspection according to the QC instruction before packing.
Q.What certificates do you have?
A:Yes,ISO,SGS and ROHS are available now.Others also can be made as you request.
Q.Is the third party quality test acceptable?
A:Sure,it will be our great honor.They are always welcome.
Q.What's the life time of the FRP profiles?
A:Normally,it is about 15 years.
Q.How to make them with UV resistant?
A:Adding some UV resistant material.Sometimes,if it is in high demands,we will consider UV painting.
Q: I'd like to know your payment terms.
A: Basically, the payment terms are T/T, L/C at sight. Western Union, Paypal, Moneygram, Alipay, Credit card are acceptable for sample order.
For more information, please contact us.
