Quick Details
-
Voltage:
-
customized
-
Power:
-
16kw
-
Dimension(L*W*H):
-
10000x4000x3000
-
Front Door Size:
-
2000*2000 mm(W*H)
-
Basement:
-
installed on concrete floor directly
-
Wall Panel:
-
50mm thick with EPS insulation, density is 14kgs/m3
-
Air Intake:
-
air capacity is 28000 m³/h
-
Air Exhaust:
-
air capacity is 28000 m³/h
-
Ceiling Lights:
-
8units*4pcs=32pcs*16W LED lights
-
Heating Method:
-
G20 diesel burner, 200000Kcal/h
-
Heat Exchanger Material:
-
2.0mm thick #201 stainless steel
-
Certification:
-
CE
Quick Details
-
Machine Type:
-
painting equipment, Spray Booths, Painting Equipment, Pre-treatment Equipment, Drying Oven, Curing oven, Coating Equipment, Sandblasting Machine
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Captain
-
Voltage:
-
customized
-
Power:
-
16kw
-
Dimension(L*W*H):
-
10000x4000x3000
-
Front Door Size:
-
2000*2000 mm(W*H)
-
Basement:
-
installed on concrete floor directly
-
Wall Panel:
-
50mm thick with EPS insulation, density is 14kgs/m3
-
Air Intake:
-
air capacity is 28000 m³/h
-
Air Exhaust:
-
air capacity is 28000 m³/h
-
Ceiling Lights:
-
8units*4pcs=32pcs*16W LED lights
-
Heating Method:
-
G20 diesel burner, 200000Kcal/h
-
Heat Exchanger Material:
-
2.0mm thick #201 stainless steel
-
Certification:
-
CE
| Inside Dimension for Painting Room | 4000×3000×3000 mm(L×W×H) |
| Outside Dimension for Painting Room | 4100x4300x3450mm(LxWxH) |
| Inside Dimension for Baking Room | 6000x3000x3000mm(L×W×H) |
| Outside Dimension for Baking Room | 6060x3100x3450mm(LxWxH) |
| Front Door for Painting Room, Baking Room and Middle Door |
Size: 2800×2800 mm(W×H), 2 folds Material: double sides 0.5mm galvanized color steel, without aluminum frame, pressed sheet metal inside to stengthen. 5mm tempered glass for watching window color: white, blue, red, orange |
| Wall Panel | Material: 50mm thick EPS for insulation, density is 14kgs/m², 950 or 1150mm wide. It is with double sides 0.4mm thick color steels, tongue and groove interlock structure. Advantages: High strength, flame retardant, easy installation |
| Basement System | No steel basement, installed on concrete floor directly. |
| Air Intake | 2sets 1.1kw top fan for air intaking, air capacity is 25000 m³/h; The fan is with pre filter cotton to stop large dust particle. |
| Air Exhaust | 2 sets 3kw axial fans installed on the water curtain for exhausting, air capacity is 20000 m³/h; Size for water curtain is 3m long, 2m wide and 1.2m deep. The water curtain and water tank are made of #201 stainless steel. |
| Ceiling Lights | Ceiling Lights: 4units×2pcs=8pcs×36W anti explosion LED lights. illumination≥800Lux. |
| Heating System | Infrared lamps, 3kw x 6 groups of fixed short infrared lamps on both sides, total is 18kw. |
| Pre-filter Cotton | Pre-filter: installed on the air inlet to prevent large dust particles larger than 10µm and other impurities; Recommended time for changing: 60-80 working hours |
| Ceiling Filter Cotton | Ceiling filter: installed on the ceiling frame to prevent much smaller dust, make sure the air is clean. Recommended time for changing: 400-450 working hours |
| Control Panel | It includes the button: spray&baking switch, time setting, lighting switch, temperature controller, power supply switch, emergency stop, breakdown alarm, etc. All electrical parts are from SCHNEIDER. Function: Spraying, Baking, Heat Spraying, automatic temperature control Protection: Overload protection, phase-break protection |
Designed draw--we will give you designed draw for confirmation
Production----every step we do is according to our draw, we have all kinds of advanced machines to make production precise
Package and Delivery----every package has a lable, we put part name and number on it. If 3 sets in one high container, we will have 3 different colors of lable for differentiate every ste.
Installation----We can give you installation draw to guide you assemble step by step, and we also have installation vedio on Youtube.
Parts
High desensity wall panel, two men stand on it, it will not bend.
High desensity wall panel, two men stand on it, it will not bend.
Water Curtain for filtering Paint Mist
Stainless steel heat exchanger, we make ourself, our worker is professional, there is no leaking and strong enough.
Our control box is with SCHNEIDER parts
Different Colors for your choice
Workshop----
pictures for our workshop and stock, you can see we have standard workshop and machine for producing, and enough stock for ensuring fast delivery
